Product No.
FES355EBD
37954335E5064 37954335E5014
Series
30" slide-in
Color
black
Market
North America
Wiring Diagram
318271906
Owner's Guide
318203821
Installation Instructions 318201611
Timer Guide
318200184
Publication No.
5995534442
09/03/03
(EN/SERVICE/ECL)
377
FES355ESD
30" slide-in
white
North America
318271906
318203821
318201611
318200184
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
FES355E
©
Copyright
2009 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Electrolux Frigidaire FES355E
Summary of Contents for Electrolux Frigidaire FES355E
- Page 1 30-INCH SLIDE-IN FES355E.eps CFED355ESD.eps BFES355ESD.eps LA20CT0045.eps D79046592501.eps ELECTRIC RANGE 318271906.eps Electrolux Major Appliances Model No. North & Latin America FES355E P.O. BOX 212378 AUGUSTA, GA 30917 Publication No. 5995534442 09/03/03 (EN/SERVICE/ECL) © Copyright 2009 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995534442 FES355E BACKGUARD 03/09...
- Page 3 FES355E Publication No: 5995534442 BACKGUARD Model Index: A FES355E (FES355ESD) B FES355E (FES355EBD) POS. NO PART NO. DESCRIPTION 14 # 318293901 Light, indicator, 125v, (2) 318299100 Console, assy., white 318299102 Console, assy., black 5304447071 Clip, console, (2) 318235187 Panel, control, white 318235188 Panel, control, black 318224401...
- Page 4 Publication No: 5995534442 FES355E BODY 03/09...
- Page 5 FES355E Publication No: 5995534442 BODY Model Index: A FES355E (FES355ESD) B FES355E (FES355EBD) POS. NO PART NO. DESCRIPTION 318259220 Back, main 318225110 Panel, main back, upper 318258902 Shield, insulation, upper 318225210 Panel, bodyside, upper RH 318225211 Panel, bodyside, upper LH 318073906 Panel, subtop 318175508...
- Page 6 Publication No: 5995534442 FES355E BODY 03/09...
- Page 7 FES355E Publication No: 5995534442 BODY Model Index: A FES355E (FES355ESD) B FES355E (FES355EBD) POS. NO PART NO. DESCRIPTION 318317100 Adapter Assembly, vent tube, w/converter 318272901 Box, vent 318003000 Plate, shield 318225810 Box, extension 318322600 Plate, shield 165A 318326501 Shield, heat 318298410 Bracket, base support, (2) 166A...
- Page 8 Publication No: 5995534442 FES355E TOP/DRAWER 03/09...
- Page 9 FES355E Publication No: 5995534442 TOP/DRAWER Model Index: A FES355E (FES355ESD) B FES355E (FES355EBD) POS. NO PART NO. DESCRIPTION 318107105 Drawer 318298906 Panel, drawer, white, front 318298908 Panel, drawer, black, front 318332200 Roller, nylon 318298601 Bracket, drawer support, (2) 318018100 Channel, drawer, RH 318018101 Channel, drawer, LH 15 #...
- Page 10 Publication No: 5995534442 FES355E DOOR D79046592501 03/09...
- Page 11 FES355E Publication No: 5995534442 DOOR Model Index: A FES355E (FES355ESD) B FES355E (FES355EBD) POS. NO PART NO. DESCRIPTION 318260201 Trim, oven door, black, upper 318260401 Trim, oven door, side, (2) 318261301 Glass Assy., oven door, white, outer, w/trim 318261300 Glass Assy., oven door, black, outer, w/trim 318260522 Baffle, door 318372000...
-
Page 12: Wiring Diagram
Publication No: 5995534442 FES355E WIRING DIAGRAM 03/09...
