FujiFilm FinePix F601 Zoom Service Manual

U/e/eg-model
Hide thumbs Also See for FinePix F601 Zoom:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual

DIGITAL CAMERA

FinePix F601 Zoom
SERVICE MANUAL
U/E/EG-Model
WARNING
THE COMPORNENTS IDENTIFIED BY THE MARK "
" ON THE SCHEMATHIC
DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR SAFETY.
PLEASE REPLACE ONLY BY THE COMPORNENTS SPECIFIED ON THE SCHMATHIC
DIAGRAMAND IN THE PARTS LIST.
IF YOU USE WITH PART NUMBER UN-SPECIFIED, IT MAY RESULT IN A FIRE AND AN
ELECTORICAL SHOCK.
Ref.No.:ZM00430-103
FUJI PHOTO FILM CO.,LTD.
Printed in Japan 2002.2(T.S.)
