Model No. DTL44941
Serial No.
USER'S MANUAL
Serial Number
Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pro-Form Ultimate LX DTL44941
Summary of Contents for Pro-Form Ultimate LX DTL44941
- Page 1 Model No. DTL44941 Serial No. USER'S MANUAL Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory. TO AVOID DELAYS, PLEASE CALL DIRECT TO OUR TOLL- FREE CUSTOMER HOT LINE.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Failure to use a properly functioning surge that all users of this treadmill are adequately suppressor could result in damage to the con- informed of all warnings and precautions. - Page 4 21. When folding or moving the treadmill, make maintenance and adjustment procedures de- sure that the storage latch is fully closed. scribed in this manual. Never remove the motor hood unless instructed to do so by an 22. Inspect and properly tighten all parts of the authorized service representative.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new PROFORM ® CROSS- ing this manual, call our Customer Service Department TRAINER ULTIMATE LX treadmill. The CROSS- toll-free at 1-800-999-3756, Monday through Friday, 6 TRAINER ULTIMATE LX treadmill combines advanced a.m. until 6 p.m. Mountain Time (excluding holidays). technology with innovative design to help you get the To help us assist you, please note the product model most from your exercise in the convenience of your... -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 2. With the help of another person, carefully lower the Uprights (69) as shown. Note: It may be helpful to place one foot on one of the Extension Legs [63] as you tip the Uprights. Make sure that the Extension Legs remain in the Uprights.
- Page 8 4. Hold the Console Base (47) near the Left Handrail (71). Attach the end of the ground wire on the Console Base to the indicated small hole in the Left Handrail with the Ground 1/2” Ground Screw (75). Wire Small Hole 5.
- Page 9 7. Press the Upright Wire (42) into the slot in the underside of the Console Base (47) in the indicated area. Cover the Upright Wire with the Right Grip Plate (36). Be careful not to pinch the Upright Wire. Tighten three 1/2” Screws (49) into the Right Grip Plate and the Console Slot Ground...
-
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT an equipment-grounding conductor and a grounding plug. Plug the power cord into a surge suppressor, and plug the surge suppressor into an appropriate Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. -
Page 11: Console Diagram/Operation
CONSOLE DIAGRAM Displays Pulse Sensor Note: If there is a thin sheet Clip of plastic on the console, remove the plastic. Insert the key into the console. A tone will sound and CAUTION: the three displays will light. Test the clip by carefully Before operating the taking a few steps backward until the key is pulled console, read the following precautions. - Page 12 To stop the walking belt, press the Stop button. while inserting the key The Time/Distance display will begin to flash. into the console. An “E” for English miles or an Note: During the first few minutes that the treadmill “M” for metric kilometers will appear in the Speed is used, inspect the alignment of the walking belt, display.
- Page 13 HOW TO USE THE HAND WEIGHTS To exercise your upper body as you walk on the treadmill, hold the 2-pound weights at your sides or press the weights above your head. To increase the intensity of your exercise, use the 3-pound or 5-pound weights. The hand weights can be stored in the weight rack.
-
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill. - Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Press the storage latch to the left. Pivot the treadmill down until the frame and foot rail are past the storage latch. Storage Latch Catch...
-
Page 16: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the instructions below. If further assistance is needed, please call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 17 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.
-
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian. - Page 19 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
- Page 20 PART LIST—Model No. DTL44941 R1103A No. Qty. Description No. Qty. Description No. Qty. Description Hood Handrail Cap Belt Guide 3/4” Screw 5/32” Allen Wrench Belt Guide Screw Motor Belt Upright Wire Plastic Fastener Motor Tension Bolt Console Isolator Cushion Motor Tension Washer Wire Cover Frame Motor Star Washer...
- Page 21 EXPLODED DRAWING—Model No. DTL44941 R1103A...
-
Page 22: Limited Warranty
HOW TO ORDER REPLACEMENT PARTS To order replacement parts, call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: •...
