PRODUCT NO.
KSPZ25V9CS0
MARKET
Export
WIRING DIAGRAM - 240420906
OWNER'S GUIDE - 240417300
SERVICE DATA SHEET - 240420906
International
3 Parkway Center
Pittsburg, PA 15220
KELVINATOR INTERNATIONAL
BASE MODEL NO.
SERIES
R134a System
KSPZ25V9C
Publication No.
EK30503990
COLOR
stain/blk
041222
JAD
©2003 Electrolux Home Produst, Inc.
All rights reserved
FACTORY
PARTS CATALO
VOLTS
220
SIDE BY SIDE
REFRIGERATOR
Model No.
KSPZ25V9C
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KSPZ25V9C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kelvinator KSPZ25V9C

Summary of Contents for Kelvinator KSPZ25V9C

  • Page 1 KELVINATOR INTERNATIONAL FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS R134a System stain/blk KSPZ25V9CS0 KSPZ25V9C MARKET Export WIRING DIAGRAM - 240420906 OWNER’S GUIDE - 240417300 SERVICE DATA SHEET - 240420906 SIDE BY SIDE International 3 Parkway Center...

  • Page 2: Freezer Door

    Publication No. KSPZ25V9C EK30503990 FREEZER DOOR 05/03...
  • Page 3 KSPZ25V9C Publication No. EK30503990 FREEZER DOOR POS. NO PART NO DESCRIPTION 240390608 Gasket-frzr door,black ,magnetic 240367302 Bin-door,frzr-upper 240359002 Bin-door 240358402 Bin-door, frzr-dispenser 240554215 Door-frzr, stainless steel, complete assy 240537106 Door Stop, black, frzr 218756505 Handle-door, stainless steel, with insert & set screw 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile...

  • Page 4: Refrigerator Door

    Publication No. KSPZ25V9C EK30503990 REFRIGERATOR DOOR 05/03...
  • Page 5 KSPZ25V9C Publication EK30503990 REFRIGERATOR DOOR POS. NO PART NO DESCRIPTION 240390607 Gasket-refr door,black ,magnetic 240363702 Bin-door,2-liter 240338309 Door-dairy 240578001 Label-nameplate -KIC 240537105 Door Stop,black ,ref 240451971 Door-refr, stainless steel, complete assy 218756505 Handle-door, stainless steel, with insert & set screw 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile...
  • Page 6 Publication No. KSPZ25V9C EK30503990 CABINET 05/03...
  • Page 7 KSPZ25V9C Publication EK30503990 CABINET POS. NO PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 14 # 240505801 Switch,light/lamp 14A# 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701 Screw-#10-32 x 1/4 flat hd 240335501 Bolt-roller adj,hex washer head, 1/4-20 x 4.020, (2), special...
  • Page 8 Publication No. KSPZ25V9C EK30503990 SHELVES 05/03...
  • Page 9 KSPZ25V9C Publication EK30503990 SHELVES POS. NO PART NO DESCRIPTION 240434603 Trim-basket 240338801 Shelf-freezer,flip-up 240338703 Shelf-freezer,fixed wire 240350642 Shelf-freezer,glass 240355230 Shelf-"Spill-Safe",fixed 240350124 Shelf-"Spill-Safe",cantilever ,sliding 240354502 Cover-crisper pan,upper 240362101 Clip-slide,cover-crisper 240354602 Cover-crisper pan,lower 240354711 Pan-crisper,upper 240349801 Clip-slide,pan-crisper 240351101 Control-humidity 240354812 Pan-crisper,lower 240430705...
  • Page 10 Publication No. KSPZ25V9C EK30503990 CONTROLS 05/03...
  • Page 11 KSPZ25V9C Publication EK30503990 CONTROLS POS. NO PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 13 # 240419601 Motor-evap fan,220V 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 218814400 Light Bulb/Lamp 218971501 Socket-light/lamp 240374903...
  • Page 12 Publication No. KSPZ25V9C EK30503990 SYSTEM 05/03...
  • Page 13 KSPZ25V9C Publication No. EK30503990 SYSTEM POS. NO PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240449501 Cord-electric power 240392503 Harness-wiring,machine compt 240439901 Wiring Harness,controls 240447101 Bracket,strain relief 240447201 Clamp,strain relief 240449601 Harness-wiring 240451501 Screw, ind hex wshr hd, 8-32 x 0.375, thread rolling...
  • Page 14 Publication No. KSPZ25V9C EK30503990 DISPENSER 05/03...
  • Page 15 KSPZ25V9C Publication EK30503990 DISPENSER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304422012 Cover-module, black 5304422013 Module-dispenser 5304421626 Spring-torsion 240323937...

  • Page 16: Ice Container

    Publication No. KSPZ25V9C EK30503990 ICE CONTAINER 05/03...
  • Page 17 KSPZ25V9C Publication No. EK30503990 ICE CONTAINER POS. NO PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container 5304404337 Bar-drive 5304404359 Gate 218814400 Light Bulb/Lamp 5303289050 Socket-light/lamp 5304404345 Drive Blade 18 # 240326910 Motor-auger...

  • Page 18: Ice Maker

    Publication No. KSPZ25V9C EK30503990 ICE MAKER 05/03...
  • Page 19 KSPZ25V9C Publication No. EK30503990 ICE MAKER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve to ice maker...

  • Page 20: Wiring Schematic

    Publication No. KSPZ25V9C EK30503990 WIRING SCHEMATIC 05/03...

  • Page 21: Wiring Diagram

    KSPZ25V9C Publication No. EK30503990 WIRING DIAGRAM # = Fast-moving Parts 05/03 * = Non-Illustrated Parts...
