PlayActive B28 Owner's Manual

Playactive b28 children's electronic toy car
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CHILDREN'S
ELECTRONIC TOY CAR
• Suitable for 37~96 months
• Maximum user weight: 30kgs
• Adult assembly required
OWNER'S MANUAL
Read and understand this entire manual before using!
Please keep this manual for future reference as it contains important
information.
Before first time use, charge the battery for at least 4-6 hours.
Products features may vary
from the pucture above.

Advertisement

Table of Contents
loading

Related Manuals for PlayActive B28

Summary of Contents for PlayActive B28

  • Page 1 CHILDREN'S ELECTRONIC TOY CAR Products features may vary from the pucture above. • Suitable for 37~96 months • Maximum user weight: 30kgs • Adult assembly required OWNER'S MANUAL Read and understand this entire manual before using! Please keep this manual for future reference as it contains important information.
  • Page 2 118 x 66 x 52CM 3~5KM/H 3KM/H Suitable age: Speed: 37~96 months Input: depend on local voltage Average Approximately Charger: Output: DC 6V800mA or DC6V1A battery life: 300 times or DC12V1A Charge time: 8-12 Hours Power way: Charging type VER:SMS-B28-EN-130226...

  • Page 3: Parts List

    Parts List Q’ty (pcs) REMARKS PART NAME Vehiclebody Steeringcolumn 4 pcs placed on the front axle, Ø12Washer 4 pcs placed on the rear axle. 2 pcs placed on the front axle, Ø10Locknut 2 pcs placed on the rear axle. Steeringwheel M5x50machinescrew Placed on the steering wheel.

  • Page 4: Parts Diagram

    Parts Diagram Tools Required Screwdriver(not included) Pliers(not included) Spanner...

  • Page 5: Assembly Steps

    Assembly Steps • Your new vehicle requires adult assembly. Please set aside at least 40 minutes for assembly. Children can be harmed by small parts, sharp edges and sharp points in the vehicle's unassembled state. Care should be taken in unpacking and assembly of the vehicle.
  • Page 6 Assembly Steps ● Fit the gear box onto the rear axle Driving wheel from the left side (Standing at the rear of the Ø10 Locknut vehicle body). And make the motor on the Gear box gear box pass through the hole in the vehicle body.
  • Page 7 Assembly Steps Ø10 washer Ø10 washer Split pin Steering shaft ● Turn the vehicle body on its side. ● Slide a 10 washer onto the steering shaft from the straight end(PIC 4-1). Ø ● Insert the straight end of steering shaft up through the hole on the front of vehicle body from bottom side, and out through the hole in dash.

  • Page 8: Battery Information

    Assembly Steps BATTERY INFORMATION Batteries may leak fluids that can cause chemical burn injury or ruin your product. To avoid battery leakage: ● Do not mix old and new batteries. ● Do not mix different types of batteries: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium). Insert batteries as indicated inside the battery compartment.
  • Page 9 Assembly Steps ● Fit the motor hood on the motor. ● Tighten four Ø4x12 screws to secure it. Motor hood Ø4x12 screw ● Fit the motor hood on the motor. ● Tighten four Ø4x12 screws to secure it. ● Repeat for the other side. Seat M5x20 machine ●...

  • Page 10: How To Operate Your Vehicle

    How To Operate Your Vehicle WARNING! PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • Never use in roadways, near cars, on or near steep inclines or steps, swimming pools or other bodies of water.

  • Page 11: Advanced Use

    How To Operate Your Vehicle Use Operation Sounds buttons IMPORTANT! Audio input Always stop vehicle when changing the speed or direction to Forward-backward avoid damage the gears switch and motor. Foot pedal Power switch Use Operation B H/L SPEED ADVANCED USE - Sounds buttons Audio input High speed Drive...

  • Page 12: Charging Your Vehicle

    Charging Your Vehicle ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or the charger with another brand. Using another battery or charger my cause a fire or explosion. - Do not use the battery or charger for any other product.

  • Page 13: Driving Wheel)

    Charging Your Vehicle 1. Counterclockwise rotate the cover of socket , and remove it;(The cover is ABOVE THE DRIVING WHEEL). 2. Plug the charger port into the input socket; 3. Plug the charger plug into a wall outlet. The battery will begin charging. WARNING! This product with CHARGING PROTECTION: When charging, all the functions will be cut off!

  • Page 14: Troubleshooting Guide

    Troubleshooting Guide ■ PROBLEM: The vehicle does not run PROBLEM CAUSE: The battery may low on power. After each use, or once a month minimum, charge the battery for a full 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Thermal fuse has tripped.

  • Page 15: Maintaining Your Vehicle

    Troubleshooting Guide ■ PROBLEM: The vehicle does not run very long. POSSIBLE CAUSE: Battery may be undercharged. You may not be charging the battery long enough. After each use, or once a month minimum, charge the battery for 8 to 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Battery is old.
  • Page 16 Disposal Of Battery Disposal Of Batter y ● Your sealed lead-acid battery must be recycled or disposed of in an environmentally sound manner. ● Do not dispose of your lead-acid battery in a fire. The battery may explode or leak. ●...
