Videology D4T7L3.6IR Series Instruction Manual

IMAGING SOLUTIONS INC.
Original Equipment Manufacturer
Instruction Manual
4" Aluminum Day & Night
IR Dome Camera
D4T7L3.6IR Series
Information may change without notice.
This document provides technical information for the user.
Videology reserves the right to modify the information in
this document as necessary. The customer should make
sure that they have the most recent manual version.
Videology holds no responsibility for any errors that may
appear in this document.
Videology Imaging Videology Imaging
Solutions, Inc. USA Solutions, B.V. Europe
37M Lark Industrial Neutronenlaan 4
Parkway NL-5405 NH Uden,
Greenville, RI 02828 Netherlands
Tel: 401-949-5332 Tel: +31 (0) 413-256261
Fax: 401-949-5276 Fax: +31 (0) 413-251712
www.videologyinc.com
04/11/10 INS-D4T7L3.6IR Rev A
Warning
Before providing power to the camera, please
read this User Guide in detail.
Do not attempt to disassemble the camera.
If the camera does not work, please contact a
local distributor or Videology.
Warning
Explanation of Graphical Symbols
!
www.videology.nl
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the product.
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is intended to
alert the user to the presence of
non-insulated dangerous voltage
within the product's enclosure
that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
Introduction
Congratulations on your purchase of this IR
dome camera. We use the latest illumination &
sensor technology.
Some of the most attractive characteristics
include: vandal-proof, widely applicable to day
& night viewing and weather resistant.
In addition, it offers high definition and
stability along with rich and real color.
Ease of use and repair are convenient as well.

Camera Features

 1/3" SONY Super HAD CCD Sensor
 Built-in auto gain control (AGC) circuit. The
color camera can get high definition picture
in low Lux condition
 Built-in auto electronic shutter function. The
color camera's AES speed can reach
1/100,000s
 Camera gama characteristic is 0.45
 NTSC/PAL selectable
 0 Lux with IR LED on. High quality IR LEDs,
generating good night-vision effect
Connecting
