Instruction Manual
30x Outdoor Speed Dome
This document provides technical information for the user. Videology reserves the right to
modify the information in this document as necessary. The customer should make sure that
they have the most recent manual version. Videology holds no responsibility for any errors
that may appear in this document.
Videology Imaging Solutions, Inc. USA
37M Lark Industrial Parkway
Greenville, RI 02828
Tel: 401-949-5332
Fax: 401-949-5276
Doc # INS-20/21Z704T-PZ30
Revision: A
IMAGING SOLUTIONS INC.
20Z704T-PZ30
Information may change without notice.
Issue Date: 07/28/2008
Page 1 of 49
®
Videology Imaging Solutions, B.V. Europe
NL-5405 NH Uden, Netherlands
Tel: +31 (0) 413-256261
Fax: +31 (0) 413-251712
Neutronenlaan 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20Z704T-PZ30 and is the answer not in the manual?

Questions and answers

Related Manuals for Videology 20Z704T-PZ30

Summary of Contents for Videology 20Z704T-PZ30

  • Page 1 This document provides technical information for the user. Videology reserves the right to modify the information in this document as necessary. The customer should make sure that they have the most recent manual version. Videology holds no responsibility for any errors that may appear in this document.

  • Page 2: Table Of Contents

    Table Of Contents Document History....................3 Important Safety Instructions ................4 2.1. Precautions ....................4 Introduction ..................... 5 3.1. Features ....................5 3.2. Powerful Pan/Tilt Functions ................5 3.3. Preset, Pattern, Swing, & Group..............5 3.4. PTZ (Pan/Tilt/Zoom) Control................. 5 3.5.

  • Page 3: Document History

    6.9.3. Edit Group..................40 6.9.4. System Initialize ................43 6.9.5. Initial setting ..................44 Specifications....................45 7.1........................45 7.2. Dimensional Drawings ................47 Contact......................49 1. Document History Revision Issue Date Reason Rev A 06-25-08 Initial release 08-0135 Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 3 of 49...

  • Page 4: Important Safety Instructions

    2. Important Safety Instructions This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 5: Introduction

    3. Introduction 3.1. Features Camera Specifications: Image Pick-up Device: 1/4" Interline Transfer CCD Zoom Magnification: 30x Optical Zoom, 10x Digital Zoom (Max. 300x Zoom) Day & Night Function Focus Modes: Auto-Focus / Manual Focus / Semi Auto-Focus Independent & Simultaneous Camera Characteristic Setup in Preset operation 3.2.

  • Page 6: Osd (On Screen Display) Menu

    3.5. OSD (On Screen Display) Menu An OSD menu is provided to display the status of the camera and to configure the functions interactively. The information such as Camera ID, Pan/Tilt Angle, Alarm I/O and Preset can be displayed on screen. 3.6.

  • Page 7: Product & Accessories

    3.9. Product & Accessories Basic Components Other Components (available - ordered separately) Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 7 of 49...

  • Page 8: Parts Name & Functions

    Parts Name & Functions 1. Dome Cover Do not remove the protective vinyl from the dome cover before finishing the installation. This protects the dome cover from scratches and/or dust. 2. DIP Switch Sets the camera’s ID and protocol. 3. Main Body Cable Provides power and signal connections between the main body and the mounting bracket.

  • Page 9: Installation

    4. Installation 4.1. DIP Switch Setup Before installing the camera, you should set the DIP switches to configure the camera ID. Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 9 of 49...

  • Page 10: Address Id Setup

    4.2. Address ID Setup The ID number of the camera is set using a binary number. An example is shown below. The range of IDs are 1~255. Do not use 0 as camera ID. The factory default of the camera ID is 1. To control a certain camera, you must match the camera ID with the Cam ID setting of the DVR or Controller.

  • Page 11: Installation Using The Wall Mount

    4.4. Installation using the Wall Mount 1. Install the wall mount bracket. 2. Wire cables to the terminal blocks on the PCB. 3. Hook up "Drop Prevention Spring" on the main body to prevent the camera from unexpected drops and connect the main body cable to the main body connector. Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A...
  • Page 12 4. Line up the mold lines and assemble main body to the wall mount bracket. 5. Turn the main body on its axis CW (Clockwise) and after assembling, screw the main body to the wall mount bracket to protect from any vibration. 6.

  • Page 13: Installation Using The Pendant Mount

    4.5. Installation using the Pendant Mount 1. To pass cables to the ceiling, make a 2” – 3” (50~60mm) diameter hole on the ceiling panel and attach the ceiling mount bracket. 2. Wire the cables to the terminal blocks on the PCB. Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A...
  • Page 14 3. Hook up the "Drop Prevention Spring" on the main body to prevent the camera from unexpected drops and connect the main body cable to the main body connector. 4. Line up the mold lines and assemble the main body to the ceiling mount bracket. Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A...
  • Page 15 5. Turn the main body on its axis CW (Clockwise) and after assembling, screw the main body to the ceiling mount bracket to protect from any vibration. Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 15 of 49...

  • Page 16: Wire Connections

    4.6. Wire Connections Bracket Terminal Block Power Connection 4.6.1. The standard power for the system is 24VAC/2A. Please, check the voltage and current capacity of rated power carefully. Video Connection 4.6.2. Connect with a BNC coaxial cable. RS-485 Communication 4.6.3. For PTZ control, connect this line to the keyboard and DVR.

  • Page 17: Alarm I/O Connection

    4.7. Alarm I/O Connection Sensor input connection Before connecting sensors, check the driving voltage and output signal type of the sensor. Since the output signal type of the sensors are divided into a open collector and voltage output types in general, the cabling must be done properly. Also, the sensor type, i.e.

  • Page 18: Operation

    5. Operation 5.1. Check Points before Operation Before power is applied, please check the cables carefully. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading the DIP switches of the camera. If your controller supports multi-protocols, the protocol must be changed to match to that of the camera.

  • Page 19: Reserved Preset

    5.4. Reserved Preset Description Some Preset numbers are reserved to special functions. Function <Go Preset> [95] : Enters into OSD menu <Go Preset> [131~134] : Runs Pattern Function 1 ~ 4 <Go Preset> [141~148] : Runs Swing Function 1 ~ 8 <Go Preset>...

  • Page 20: Swing

    5.6. Swing Function By using the swing function, you can make the camera move between 2 Preset positions repeatedly. When the swing function runs, the camera moves from the preset assigned as the 1st point to the preset assigned as the 2nd point in a CW (Clockwise) direction. Then the camera moves from the preset assigned as the 2nd point to the preset assigned as the 1st point in a CCW (Counterclockwise) direction.

  • Page 21: Pattern

    5.7. Pattern Function Pattern Function is when a camera memorizes the path (mostly a curve path) by joystick of the controller and preset move functions for assigned time and repeats the path exactly as it memorized. 4 Patterns are available and a maximum of 1200 communication commands can be stored in a pattern.

  • Page 22: Group

    5.8. Group Function The group function allows a running sequence of Presets, Pattern and/or Swings. A max. of 8 groups can be stored. Each group can have a max. of 20 action entities which can be preset, pattern or swing. Preset speed can be set and the repeat number of Pattern &...

  • Page 23: Other Functions

    5.9. Other Functions Power Up Action This function resumes the last action executed before a power down. Most actions such as Preset, Pattern, Swing and Group are available for this function but Jog actions are not available to resume. Auto Flip If tilt angle exceeds 90°, the zoom module camera pans 180°...

  • Page 24: Osd Menu

    6. OSD Menu 6.1. OSD Display of Main Screen P/T/Z Information Current Pan/Tilt angle in degrees, zoom magnification and a compass direction. Camera ID Current Camera ID (Address). Action Title Following are possible Action Titles and their meaning. "SET PRESET xxx" When Preset xxx is stored "PRESET xxx"...

  • Page 25: General Rules Of Key Operation For Menu

    6.2. General Rules of Key Operation for Menu • The menu items surrounded with < > always have a sub menu. • For all menu levels, to go into a sub menu press NEAR. • To go up-one-level in the menu, press FAR. •...

  • Page 26: Display Setup

    6.4. Display Setup This menu Enable/Disable the OSD display on the Main Screen. If an item is set to be AUTO, the item is displayed only when the value of it is changed. CAMERA ID [ON/OFF] PTZ INFORMATION [ON/OFF/AUTO] ACTION TITLE [ON/OFF/AUTO] PRESET LABEL [ON/OFF/AUTO]...

  • Page 27: Compass Direction Setup

    Compass Direction Setup 6.4.1. Set North to assign the compass direction as criteria. Move the camera and press the NEAR button to save. Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 27 of 49...

  • Page 28: Camera Setup

    6.5. Camera Setup Setup the general functions of the 30x optical zoom camera module. FOCUS MODE [AUTO/MANUAL/SEMIAUTO] Sets camera focus mode. MAX ZOOM [x1 ~ x300] Sets the maximum zoom magnification. FLICKERLESS [ON/OFF] When an NTSC camera is used under 50Hz and PAL under 60Hz flickering may appear on the screen.

  • Page 29: White Balance Setup

    White Balance Setup 6.5.1. WB MODE [AUTO/MANUAL] In Manual mode, Red and Blue level can be set manually. RED ADJUST [0~255] BLUE ADJUST [0~255] Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 29 of 49...

  • Page 30: Auto Exposure Setup

    Auto Exposure Setup 6.5.2. BACKLIGHT [ON/OFF] Sets Backlight Compensation. DAY/NIGHT [AUTO/DAY/NIGHT] SLOW SHUTTER [OFF/ 2~128 Field] Activates the SLOW SHUTTER function when luminance of the image (signal) is too dark. It is possible to set the maximum number of fields stacked up one on another by the SLOW SHUTTER function.

  • Page 31: Motion Setup

    Note1) Shutter Speed Table he values are based on NTSC type Models. Value Shutter Value Shutter Value Shutter Value Shutter 1/60 sec 1/400 sec 1/1000 sec 1/2500 sec 1/125 sec 1/450 sec 1/1100 sec 1/2500 sec 1/150 sec 1/500 sec 1/1300 sec 1/3000 sec 1/200 sec...
  • Page 32 Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 32 of 49...

  • Page 33: Park Action Setup

    Park Action Setup 6.6.1. If Park Enable is set to ON, the camera runs assigned functions automatically (If there is no PTZ command during assigned "Wait Time"). PARK ENABLE [ON/OFF] PARK TIME [1 minute ~ 4 hours] The time is displayed with "hh:mm:ss" format and you can change this in 1 min.

  • Page 34: Preset Setup

    6.7. Preset Setup PRESET NO. [1~128] If a selected preset is already defined, the camera moves to a pre-defined position and preset characteristics such as Label and Relay Outputs show on the monitor. If a selected preset is not defined, "UNDEFINED" shows on the monitor. CLR PRESET [CANCEL/OK] Delete the current Preset data.

  • Page 35: Edit Preset Scene

    All Local WB/AE values should not change although the Global WB/AE values change. If "Local" is selected, the Menu to set and WB/AE shows on monitor. Edit Preset Scene 6.7.1. Using the Joystick, move the camera to the desired position. By pressing NEAR, it saves the current PTZ data.

  • Page 36: Edit Relay Out

    2. Using Left/Right/Up/Down of the joystick, move to an appropriate character from the Character se To choose that character, press the NEAR key. If you want to use blank, choose the Space character (" "). If you want to delete a previous character, use the backspace character ("...

  • Page 37: Swing Setup

    6.8. Swing Setup SWING NO. [1~8] Selects the Swing number to edit. If a selected Swing is not defined, "NOT USED" is displayed in the 1st and 2nd Positions. 1ST POS. [PRESET 1~128] 2ND POS. Set the 2 positions for the Swing function. If a selected preset is not defined, "UNDEFINED"...

  • Page 38: Pattern Setup

    6.9. Pattern Setup PATTERN NO. [1~4 ] Selects a Pattern number to edit. If a selected pattern number is not defined, "UNDEFINED" will be displayed under the selected pattern number. CLR PATTERN [CANCEL/OK] Deletes data in the current pattern. EDIT PATTERN Starts editing the pattern.
  • Page 39 2. Move the camera with the joystick or run the preset function to memorize the path (mostly curve path) in a selected pattern. The total memory size and the rest memory size is displayed in the form of bar. Maximum of 1200 communication commands can be stored in a pattern.

  • Page 40: Group Setup

    Group Setup 6.9.2. GROUP NO. [1~8] Selects a group number. If the selected number is not set, "UNDEFINED" will be displayed for the selected Group number. CLEAR GROUP [CANCEL/OK] Clears the current setting of a group. EDIT GROUP Starts the editing Group. Edit Group 6.9.3.
  • Page 41 3. Set Action, Dwell time and Option. Note that the selected item is displayed in reverse. Move the cursor Left/Right to select items and move the cursor Up/ Down to change each value. ACTION ### [NONE/PRESET/SWING/PATTERN] DWELL [0 sec~4 min] Sets the Dwell Time between functions.
  • Page 42 5. After finishing the Action setup, press NEAR to one-upper-level menu (Step 2). Move the cursor Up/Down to select the Action number and repeat Step 2 ~ 4 to edit the selected Group. 6. After finishing all Action setups, press FAR to exit. Then cursor should move to "SAVE".

  • Page 43: System Initialize

    System Initialize 6.9.4. CLEAR ALL DATA Deletes all configuration data such as display, camera, motion setup and so on. CLR DISPLAY SET Initializes Display Configuration. CLR CAMERA SET Initializes Camera Configuration. CLR MOTION SET Initializes Motion Configuration. CLR EDIT DATA Deletes Preset Data, Swing Data, Pattern Data and Group Data.

  • Page 44: Initial Setting

    Initial setting 6.9.5. Display Setting Camera Setting Camera ID Focus Mode SemiAuto PTZ Information AUTO Max Zoom X220 Action Title AUTO Flickerless Preset Label AUTO Color Alarm I/O AUTO Line Lock North Direction Pan 0 White Balance AUTO Backlight Motion Setting Day&Night AUTO Motion Lock...

  • Page 45: Specifications

    7. Specifications Video Signal NTSC Image Pick-up Device 1/4'' SONY Super HAD CCD Total Pixels 811(H) x 508(V) 410K 795(H) x 596(V) 470K Effective Pixels 768(H) x 494(V) 380K 752(H) x 582(V) 440K Horizontal Resolution 480 TV Lines S/N Ratio More than 48 dB Zoom 30x Optical Zoom, 10x Digital Zoom...
  • Page 46 Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 46 of 49...

  • Page 47: Dimensional Drawings

    7.2. Dimensional Drawings Main Body (without Sun-Shield) Main Body (Sun-Shield) Weight (Approx.): 3.8kg (8.37 lb) Weight (Approx.): 4.3kg (9.47 lb) Pendant Mount Bracket Weight (Approx.): 1.9kg (4.18 lb) Wall Mount Bracket Weight (Approx.): 1.2kg (2.64 lb) Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 47 of 49...
  • Page 48 Wall Mount Pendant Mount Doc # INS-20/21Z704T-PZ30 Issue Date: 07/28/2008 Revision: A Page 48 of 49...

  • Page 49: Doc # Ins-20/21Z704T-Pz30 Issue Date: 07/28/2008 Revision: A

    Fax: +31 (0) 413 251 712 Please visit our WEB-site at: http://www.videologyinc.com/ VIDEOLOGY IMAGING SOLUTIONS is an ISO 9001 registered video camera developer and manufacturer serving industrial, machine vision, biometric, security, and specialty OEM markets. Videology designs, develops, manufactures, and distributes video, image acquisition, and display technologies and products to OEMs worldwide.
