Page 1: Operation Manual
DVD MULTIMEDIA RECEIVER 6.5" TOUCH SCREEN DISPLAY NAVIGATION READY MULTIZONE P R E O U T S A/V - iPod - ™ OPERATION MANUAL TY-6300SD... -
Page 2: Table Of Contents
Table of Contents Safety Information ..................3 Care and Installation ..................4 Wiring Diagram ..................... 5 Controls ......................6 Main Remote Control ..................7 Multi-Zone Remote Controls ................8 Monitor Operation ..................9-10 General Operation ..................11 Main Access Menu ..................12 General Set Up Menu .................. -
Page 3: Safety Information
Please read all instructions prior to installation and operation It is highly recommended to have a professional installer or an authorized dealer install your TY-6300SD multimedia reciever. This product is only for use in vehicles with 12VDC negative ground only. -
Page 4: Care And Installation
Care and Installation Care and Maintenance To clean the monitor or front panel, wipe only with a dry silicone cloth or soft cloth and neutral detergent. Do not use a stiff cloth, or volatile solvents such as paint thinner and alcohol. They can scratch the surface of the panel and/or remove the printing. -
Page 5: Wiring Diagram
Wiring Diagram Wiring Notes: Additional hardware and accessories may be required for installation such as CAN or LAN adapters or wiring harnesses (Not Included) * Steering wheel controls may not work with some vehicles * If opting to NOT use the CAN or LAN adapters, an IGN wire must be run from the radio to the fuse box. We recommend tapping into at least a 15A amp IGN fuse at the fuse box if using this procedure. -
Page 6: Controls
Controls Reset Button Button Operation - Press S to select desired POWER / MUTE PREVIOUS - Press to turn unit on, press and hold to turn unit off. Press once to parameter within each different mode. Press MUTE audio, press again to return audio. to SEEK TUNE in Tuner Mode. -
Page 7: Main Remote Control
Remote Control Mode - Press once to select between TUNER, Main Remote Buttons DVD, AV1, CAMERA, XM, NAV, BLUETOOTH and iPod inputs. Pull the battery insulation tape out before using IR remote Mute - Press once to MUTE or restore Audio Open/Close - Open or Close Monitor Power-Power ON/OFF Volume Up - Increase volume... -
Page 8: Multi-Zone Remote Controls
Multi-Zone Remote Multi-Zone Remote Buttons Pull the battery insulation tape out before using IR remote R-SRC - Selected playing sources Mute - Toggle on/off audio output GOTO search - Search function in the VCD/ DVD disc Root - Main DVD disc menu Up/Down/Left/Right - Navigating system for selection. -
Page 9: Monitor Operation
Monitor Operation Safe Monitor Operation • The vehicle must be in park and the parking brake applied to view video on the in-dash monitor. • The video display of the in-dash unit will not operate while the vehicle is moving. As a safety feature, a blue “PARKING”... -
Page 10: Monitor Operation
Monitor Operation Monitor Movement Mechanism • Do not attempt to move the monitor up/down by hand - severe damage will occur. Use the front panel buttons or the remote control only. • The unit will stop automatically during open/close if an obstacle is detected. If this occurs, remove the obstacle and press OPEN again to resume the monitor open/close sequence. -
Page 11: General Operation
General Operation Power On / Off Press once to turn on the unit. Once on, press to MUTE sound, press again to restore sound. To turn off, press and hold. Volume Adjustment Adjust the Volume using the Vol/Smart Dial knob or the remote to adjust the volume to the desired listening level. -
Page 12: Main Access Menu
Main Access Menu Main Access Menu The MAIN menu can be access by pressing the MENU button on the remote or by touching the Area A (upper left hand side) on the monitor. Touch Access Buttons Touch to access AM/FM TUNER mode. Touch to access CD/DVD mode, CD/DVD must be inserted. -
Page 13: General Set Up Menu
General Set Up Menu GENERAL Setup Menu Table Settings Default Options Function Korea S-AMER1 China Radio Set to appropriate setting for your Country S-AMER2 Arabia Europe Clock adjust HH:MM See adjusting the clock for more details 12Hr PM 6:00 Clock Mode 12Hr 24Hr 18:00... -
Page 14: Adjusting The Clock
Adjusting the Clock correct hour. 12 or 24 Hour Clock Mode Touch Area A of screen Touch arrow to EXIT setup Touch GENERAL setup button If you desire 24Hr format, select 24Hr from CLOCK MODE Touch AM or PM to set Touch OK. -
Page 15: Screen Setup
Screen Setup Screen Setup Functions Settings Options Function fault Press the < / > buttons on the remote or touch the (-) or Brightness 0 to +20 (+) buttons on the screen or rotate the SMART DIAL to adjust the BRIGHTNESS to the desired setting Screen Saver Select to activate the screen saver,... -
Page 16: Audio Signal Processing (Asp)
Audio Signal Processing (ASP) ASP Configuration Menu Settings Default Options Function Bass Freq 60 Hz 60Hz, 80Hz, 100Hz, Select the desired frequency to obtain the 130Hz, 150Hz, 200Hz best bass effect. Treble Freq 15KHz 10KHz, 12.5KHz, Select the desired frequency to obtain the 15KHz, 17KHz best bass effect. -
Page 17: Am/Fm Tuner Operation
AM/FM Tuner Operation AM / FM Tuner Screen Current souce MODE. Touch to access Up for SEEK TUNE MAIN menu. TUNER, DVD, XM*, iPod*, SD, CAMERA, Bluetooth, NAVi*, AUX are Down for SEEK TUNE indicated in the OSD (On Screen Display). Press AS/PS (Auto store / Preset Scan) for 1 sec to start station PRESET SCAN function, Current PRESET station indicator. - Page 18 AM/FM Tuner Operation Auto Seek Tuning Press the button to auto SEEK up the next strongest station. button to auto SEEK down the next strongest station. Press the Manual Tuning Press the button to manually tune up one step at a time. Press the button to manually tune down one step at a time.
-
Page 19: Dvd Information
Some DVD discs can be played only in certain playback modes according to the intentions of the software. As the TY-6300SD plays discs according to their intentions, some functions may not work as intended. Please be sure to read the instructions provided with each disc. This player has been designed to play back DVD software that has been encoded for specific region areas. -
Page 20: Initializing Parking Brake
ENGAGE EMERGENCY BRAKE TO ENJOY VIDEO Front Monitor Video Initialization Follow this two initialization procedure carefully to allow video playback on TY-6300SD front panel monitor: There are usually two situations that start the PARKING BRAKE Sequence. Initializing Parking Brake Scenario 1... -
Page 21: Dvd Operation
DVD Operation DVD Loading Slot Eject button Insert CD/DVD with label facing upwards Notes: If PARENTAL Lock is activated and the disc inserted is not authorized, a 4-digit code must be entered and/or the disc be authorized.( see "RATING MENU") Only one disc can be inserted at one time. -
Page 22: Dvd Controls
Some DVD discs can be played only in certain playback modes according to the intentions of the software. As the TY-6300SD plays discs according to their intentions, some functions may not work as intended. Please be sure to read the instructions provided with each disc. -
Page 23: Dvd Search Function
DVD Search Function Searching a DVD Touch the search button in AREA F. Searching by Time, Title or Chapter Touch the in the TIME area. A touch keypad will now appear, enter your desired TIME to search. Enter OK. Direct Chapter / Track Selection During DVD and CD playback, you can use the numeric keypad on the IR remote to access tracks directly Viewing an Alternate Picture Angle (DVD Only) -
Page 24: Dvd Setup Menu - Language
DVD Setup Menu - Language USER 08:06 T: 4/16 DVD VIDEO 00:01:42 LOUD ON C: 1/20 Rear:OFF Indicates current source playing. Indicates the USER defined EQ levels or decoding mode when listening to a DVD Indicates that the fourth of sixteen title on with 5.1 surround sound. -
Page 25: Dvd Setup Menu - Video
DVD Setup Menu - Video Video Setup Menu With the monitor open in DVD mode and DVD disc inserted, press the AREA A (top left screen) to display the MAIN menu bar. Press DVD Setup to access the DVD setup menu. Press VIDEO icon to select from the following menus: NORMAL- 4:3 TV Shape... -
Page 26: Dvd Setup Menu - Ratings
DVD Setup Menu - Ratings Ratings Setup Menu With the monitor open in DVD mode and a DVD Disc inserted, press the AREA A (top left screen) to display the MAIN menu bar. Press DVD Setup to access the DVD setup menu. Press RATING icon to select from the following menus: Enable Parental Lock Password Press ---- to enter a your desired password. -
Page 27: Dvd Setup Menu - Audio
DVD Setup Menu - Audio Audio Setup Menu With the unit in DVD mode, press Area A to display the MAIN menu. Press DVD Setup to access the DVD setup menu. Press the AUDIO button to access the following menus: Audio Settings The Pink Noise generator is used to set the relative speaker levels for multi-channel playback. -
Page 28: Dvd Setup Menu - Speakers
DVD Setup Menu - Speaker Speaker Setup Menu With the unit in DVD mode, press Area A to display the MAIN menu. Press DVD Setup to access the DVD setup menu. Press the SPEAKER button to access the following menus: Settings Default Options... -
Page 29: Dvd Setup Menu - Surround I And Ii
DVD Setup Menu - Surrround I and II Speaker Setup Menu With the unit in DVD mode, press Area A to display the MAIN menu. Press DVD Setup to access the DVD setup menu. Press the SPEAKER button to access the following menus: Decode Mode Panorama Mode* Off = Default... -
Page 30: Cd/Dvd/Mp3/Wma Information
CD/DVD/MP3/WMA Information Media Compatibility • Valid characters for folder/file names are letters A-Z (all caps), numbers 0-9, and “_” (underscore). The following types of discs/files are compatible: Some characters may not be displayed correctly, • CD-ROM (ISO), CD-R, CD-RW, DVD+R/RW, depending on the character type. -
Page 31: Cd Operation
CD Operation 13 12 11 Current source indicator, touch AREA A to Touch to FAST FORWARD current track. access MAIN source menu Touch to FAST REVERSE current track. Disc title. Touch to PAGE up. Track title. Touch to PAGE down. Current TIME. -
Page 32: Mp3/Wma Operation
MP3/WMA Operation Current source indicator, touch AREA A to Touch to FAST FORWARD MP3 tracks, access MAIN source menu touch PLAY to deactivate. Disc title. Touch to activate / deactivate REPEAT: Single mode. Track title. Touch to activate / deactivate RANDOM Current TIME. -
Page 33: Sd Card Operation
SD Card Operation Accessing SD Card Mode • Press on the front panel to open up the Monitor and access the SD card slot. • Insert the SD Card in the slot and press the SRC button in the front panel or remote to switch to SD Card Mode Using the Touch Screen Controls Current source indicator. -
Page 34: Ipod Operation
iPod Operation To switch to iPod press the MODE button on the front panel or IR remote or from the MAIN source menu Current source indicator, touch AREA A to Touch to wait for iPod VIDEO or PHOTO. access MAIN source menu Touch to activate / deactivate REPEAT: Disc title. - Page 35 iPod Operation Notes: 1. PHOTO FILES are only compatible with NANO and G5 iPod 2. VIDEO FILES are only compatible with G5 iPod Playing Photo or Video File From iPod Make sure the following options through the iPod video settings menu are set to: TV Out = ON, Signal = NTSC and Widescreen = ON.* Touch VIDEO icon Press PLAY on your iPod, video should now...
-
Page 36: Xm Radio Operation
Activate your XM Satellite Radio service, log onto http://www.xmradio.com/activation or call 1-800-967-2346. Notes You will need to keep your TY-6300SD turned on for at least one hour after requesting activation to receive the full channel line-up. 12 11 indicator for XM MODE... - Page 37 XM Radio Operation Tuning Modes Touch to select between XM, XM1, XM2 and XM3 bands. Channel Slection Touch momentarily to select the next available channel. Storing and Recalling Preset Channel Up to 48 XM channels can be stored. To store a channel, select XM, XM1, XM2 or XM3 band and the desired channel.
-
Page 38: Bluetooth Operation
Bluetooth Operation Activating Bluetooth Operation Select Bluetooth option in the General Setup (see page 11 to access General Setup) and select ON to activate the Bluetooth feature. From the Main Menu, touch the Bluetooth icon on the screen. Displays current mode. Press 0 -9, *, # and + to enter phone number on the Keypad Interface. - Page 39 Bluetooth Operation Bluetooth Setup Pairing Access Bluetooth setup menu and press YES option on the screen, then "Wait Pairing..." will display. Now you can pair a mobile device with the unit. When prompted by your mobile device, enter 1234 for the PIN or pass code.
-
Page 40: Navigation
Navigating Operation Accessing Navigation Access the MAIN menu (touch Area A or the upper left hand corner of the screen) and select the NAVI button to enter the Navigation Operation interface. Notes: SAVANT SNAV-1 , SPiN3510 or SPiN3550 must be connected to access navigation mode. Navigation Operation Please refer to the SNAV-1 or P-NAVi navigation user manuals. -
Page 41: Muli-Zone Operation
Multi-Zone Operation Multi-Zone Operation Independent sources can be played simultaneously on the unit. For example, the AM/FM tuner can be selected for the front zone, while the DVD video is selected for the Mult-Zone source (for headrest monitors, overhead monitors, etc.) Multi-Zone Menu Access The MAIN menu can be access by pressing the MENU button on the remote or by touching the Area A (upper left hand side) on the monitor. -
Page 42: Multi-Zone Am/Fm Tuner
Multi-Zone AM/FM Tuner Indicator for MAIN ZONE Touching the PRESET SCAN/AUTO STATION STORE button will scan through all presets in the current band. Holding Displays current time on CLOCK this button for more than 2 seconds will INDICATOR automatically program the 12 strongest stations available into the presets in the Indicator for MULTI-ZONE current band. -
Page 43: Mulit-Zone Xm Radio
Multi-Zone XM Radio Indicator for MAIN ZONE Touching CATEGORY NEXT CHANNEL will select the next available channel in the current category Displays current time on CLOCK INDICATOR Touching CATEGORY PREVIOUS CHANNEL will select the previous available Indicator for MULTI-ZONE channel in the current category Displays the CHANNEL NAME Show which XM BANK is currently displayed... -
Page 44: Mulit-Zone Ipod Operation
Multi-Zone iPod Indicator for MAIN ZONE Touching REPEAT to repeat current song. Touch again to cancel. REP will change to green when the repeat function is active. Displays current time on CLOCK INDICATOR Touching STOP to stop the song where it is. STOP will change to green. -
Page 45: Limited One Year Warranty
Limited One Year Warranty Limited One Year Warranty Applies to Multimedia Headunits Who is covered? • Any product which has been adjusted altered PRIORITY AUDIO (the Company) extends this warran- or modified without SAVANT MOBILE AUDIO'S ty to the original retail purchaser of products purchased consent. -
Page 46: Troubleshooting
Troubleshooting Problem Cause Solution Yellow wire not connected or incorrect voltage Check connections for proper voltage (11~16VDC) Unit will not turn on Red wire not connected or incorrect voltage (no power) Black wire not connected Check connection to ground Fuse blown Replace fuse Speaker wires not connected Check connections at speakers... -
Page 47: Troubleshooting
Troubleshooting Problem Cause Solution The selected channel is not in service Try another channel OFF AIR appears on display The antenna cable is damaged Check for pinched or cut antenna cable This information may not be available for some No song title or artist name is This condition is normal, there is nothing wrong with music channels, news channels, or when there displayed... -
Page 48: Battery Replacement
Battery Replacement Problem Cause Solution Battery is covered with insulation tape Pull out the insulation tape Remote control does not Battery depleted Replace battery with new one function Battery installed incorrectly Remove battery and install correctly Multi-Zone Operation When using the remote for the first time, you must pull out the insulation tape. -
Page 49: Notes
Notes... -
Page 50: Notes
Notes... -
Page 51: Specifications
Apple Computer, Inc., registered in the U.S. and other countries. The Bluetooth trademark and logos are owned by Bluetooth Sig, Inc. All other trademarks are property of their respective owners. Printed in China OEM-02... - Page 52 OE RADIO Toll Free: 1-877-305-8972 www.oeradio.com ©2007 PRIORITY AUDIO All rights reserved.
