Page 2: Package Contents
IP65/66/67 warranty. Package Contents Quick Installation Guide / Warranty IP8364-C Card / Alignment Sticker Software CD L-type Hex Key Wrench / Dessicant Bag / Screws / Rubber seal... -
Page 3: Physical Description
Physical Description Front Panel Lens IR LEDs Rear Panel Reset Button MicroSD/SDHC Card Slot Connectors General I/O Terminal Ethernet 10/100 RJ45 Plug Block EN-2... -
Page 4: Hardware Installation
Hardware Installation If you prefer installing a MicroSD card as onboard storage: 1. Loosen the waterproof connector, and then remove the rubber seal, and the waterproof connector. 2. Loosen and open the rear cover. 3. Install a MicroSD/SDHC card. 4. Tear down the aluminum foil vacuum bag and take out the dessicant bag. Attach the supplied dessicant bag to the inner side of the Network Camera. - Page 5 6. Install and tighten the camera's rear cover. 7. Tighten the rubber seal, seal clamp, and cap nut of the waterproof connector. 8. Pass the cables through the center of the ball swivel mount bracket, one at a time. 9. Fasten the bracket to the camera using 3 hex socket screws. NOTE: The camera weighs up to 1.28 kgs.
- Page 6 10. Loosen the fastening ring on the mount bracket, and aim the camera at the area of your interest. When done, tighten the fastening ring. Fastening ring 75º Tilt 360º Pan 11. Secure the Network Camera to a wall or ceiling. Ceiling Mount Wall Mount EN-5...
-
Page 7: Network Deployment
Network Deployment Power over Ethernet (PoE) When using a PoE-enabled switch The Network Camera is PoE-compliant, allowing transmission of power and data via single Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable. PoE Switch When using a non-PoE switch Use a PoE power injector (optional) to connect between the Network Camera and... -
Page 8: Assigning An Ip Address
2. The program will conduct an analysis of your network environment. After your network is analyzed, please click on the "Next" button to continue the program. 3. The program will search for VIVOTEK Video Receivers, Video Servers or Network Cameras on the same LAN.
