  • Page 2 Warning Before Installation Power off the Network Camera as Refer to your user's manual for the soon as smoke or unusual odors are operating temperature. detected. Contact your distributor in the event of occurrence. Do not touch the Network Camera Do not place the Network Camera on during a lightning storm.

  • Page 3: Package Contents

    Package Contents IP8362 Alignment Sticker Sun Shield Wrench / RJ45 Female/Female Coupler / Double-sided Tape / Screws Power Adapter Wall Mount Bracket Waterproof Connector (for backup Moisture Absorber use) Quick Installation Guide / Software CD Warranty Card EN-2...

  • Page 4: Physical Description

    Physical Description Light Sensor Lens IR LED Focus Controller Zoom Controller Reset Button General I/O Terminal Block General I/O Terminal Block SD/SDHC Card Slot AC 24V + AC 24V - When inserting an SD/SDHC card, note the orientation of the contacts. Ethernet 10/100 RJ45 Plug Power Cord Socket...

  • Page 5: Hardware Installation

    Hardware Installation 1. Attach the alignment sticker to the wall. Drill three holes into the wall. Then hammer the supplied plastic anchors into the holes and secure the plate with supplied screws. 2. Feed the cables through the front opening of the wall mount bracket. (If you want to use external devices such as sensors and alarms, please refer to the assembling steps on the next page.) 3.

  • Page 6: Waterproof Connector

    Waterproof Connector Components of the Waterproof Connector Pin Defi nition Rubber (A) Power +12V Digital Output Screw Nut (B) Digital Input Seal (C) Ground Seals (D) RS485 + Housing (E) RS485 - Ground Sealing Nut (F) Audio Input Ground Audio Output Assembling Steps 1.

  • Page 7: Network Deployment

    Network Deployment Power over Ethernet (PoE) When using a PoE-enabled switch The Network Camera is PoE-compliant, allowing transmission of power and data via a single Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable. PoE Switch When using a non-PoE switch Use a PoE power injector (optional) to connect between the Network Camera and a non-PoE...

  • Page 8: Assigning An Ip Address

    "Next" button to continue the program. Installation Wizard 2 3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras on the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one on the product label to connect to the Network Camera via Internet Explorer.

  • Page 9: Ready To Use

    Ready to Use 1. Access the Network Camera from the LAN. 2. Retrieve live video through a web browser or recording software. For further setup, please refer to the user's manual on the software CD. 3. Unscrew the zoom controller to adjust the zoom factor.
  • Page 10 5. Tighten the lens cover. 6. Replace the moisture absorber with a new one if you open the back cover during the installation procedure. Please tear down the aluminum foil vacuum bag and take out the moisture absorber, then attach the moisture absorber with the supplied double-sided tape.
