Summary of Contents for Cypress CX-5100AH
- Page 1 CX-5100AH HDMI with Audio Amplifier Operation Manual CX-5100AH...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction ..................2. Features ....................3. Remote Control ................... 4. Hardware Descriptionl ............... 4.1 Front View..................4.2 Rear View ..................5. LCM Operation ..................5.1 LCM Menu................... 5.2 LCM Menu 1................5.3 LCM Operation table..............6. Audio output format table..............7. -
Page 3: Introduction
1. Introduction This is the most advanced solution for HDMI with Audio Amplifier. That supports three HMDI input and two HDMI output, also supports Analog/Digital audio input/output. Simply select from the LCM menu or remote control to select desire combination. 2. -
Page 4: Hardware Descriptionl
4. Hardware Description 4.1 Front View Home Video In Audio In VOLUME Power Menu 4 5 6 1 Power indicator: When power on the LED will indicate in Green color, when power off the LED will indicate in Red color. 2 Power switch: Turn the system ON/OFF. -
Page 5: Rear View
4.2 Rear View HDMI INPUT HDMI OUT 5.1CH AMP DIGITAL DIGITAL OUTPUT FRONT REAR CENTER SUBWOOFER OPTICAL COAXIAL OPTICAL COAXIAL L/Lt R/Rt (TOTAL) CENTER DC 12V FRONT REAR ANALOG INPUT 5.1CH OUTPUT 1 5.1CH AMP out: Connect the Front/Rear/Center/Subwoofer to the Speakers. 2 Optical 1/2 in: Connect the Optical input ports to the Optical output port of your source equipments. -
Page 6: Lcm Operation
↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓... -
Page 8: Lcm Operation Table
5.3 LCM Operation table Function Level Suggestion level Bass -6 ~ +6 Treble -6 ~ +6 Loudness -6 ~ +6 LipSync LR 0 ~ 16 LipSync C 0 ~ 16 Default Off/On LipSync can delay120ms +/- 5% for each mono channel. ... - Page 9 PCM 2 CH PCM 2 CH Virtual PCM 2 CH PCM 2 CH OPT_1 In / 5.1 CH / / 5.1 CH / 5.1 CH / / Mute / Mute Mute Mute Mute PCM 2 CH PCM 2 CH Virtual PCM 2 CH PCM 2 CH OPT_2 In...
-
Page 10: Connection And Installation
7. Connection and Installation 8. Specifications Video input ports 3 x HDMI Digital audio input ports 2 x Coaxial, 2 x Optical Analog audio input ports 4 x Audio R/L Video output ports 2 x HDMI Digital audio output ports 1 x Coaxial, 1 x Optical Analog audio output ports 5.1 channels output clips...
