- Page 1 CX-5100AH HDMI with Audio Amplifier Operation Manual CX-5100AH...
- Page 2 Revision History Revision Date Summary of Change 20080926 Preliminary Release Precaution Failure to follow the precautions described below may cause damage to Digital HDMI AV Receiver and void the warranty. DO NOT open the case. Doing so will void the warranty. If you find ...
-
Page 3: Table Of Contents
Table of Contents Introduction …………………………………………........ Application......…………………………………………… Contents ......………………………………………………. System Require ......……………………………………….. Features ......……………………………………………….. Installation ......…………………………………………….. Front View ......…………………………………………….. Remote Control......……………………………………….. LCM Operation ......………………………………………. 9.1 LCM Menu 1..................9.2 LCM Menu 2..................9.3 LCM Operation Table ..............Audio Input & Output Diagrm............. Audio Output Format Table.............. -
Page 4: Introduction
1. Introduction Thank you for purchasing Digital HDMI AV Receiver with Audio Amplifier. When HDMI products fill out the market speedily, many follow devices are still yet catching up. How to enjoy a full HDMI solution with limited cost and space is the most urgent request now in the market. -
Page 5: System Require
4. System Requirements Front LR/Rear LR/Center/Subwoofer speakers, Amplifier, Optical / Coaxial cables, DVD player, HDMI/LCD TV and other audio equipment(s). 5. Features Compliant with HDMI 1.2, HDCP 1.1 and DVI 1.0 specifications. Full HD 1080p supported. Supports a wide range of PC and HDTV resolutions from VGA to UXGA ... -
Page 6: Installation
6. Installation Follow the step-by-step instruction below to install your Digital HDMI AV Receiver Get familiar with the housing and connections of your new Digital HDMI AV Receiver. HDMI INPUT HDMI OUT DIGITAL DIGITAL 5.1CH AMP OUTPUT REAR FRONT CENTER SUBWOOFER OPTICAL COAXIAL... -
Page 7: Front View
7. Front View Home Video In Audio In VOLUME Power Menu 4 5 6 Power indicator: When power on, the LED will indicate in Green color. When power off, the LED will indicate in Red color. Power switch: Turn the system ON/OFF. IR sensor. -
Page 8: Remote Control
8. Remote Control 1. Power: Press to turn ON/OFF the system. When POWER POWER power on the LED will indicate in Green color, HDMI IN HDMI IN when power off the LED will indicate in Red MUTE MUTE color. 2. Mute: Press to mute the audio, press again to turn ON the audio. -
Page 9: Lcm Operation
↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓... -
Page 11: Lcm Operation Table
9.3 LCM Operation table Function Level Suggestion level Bass -6 ~ +6 Treble -6 ~ +6 Loudness -6 ~ +6 LipSync LR 0 ~ 16 LipSync C 0 ~ 16 Default Off/On LipSync can delay120ms +/- 5% for each mono channel. ... -
Page 12: Audio Output Format Table
11. Audio output format table Output Jacker & Format HDMI_1 HDMI_2 6 RCA OPT Out COAX Out Line Out HDMI_1 PCM 5.1 PCM 5.1 PCM 2 CH PCM 2 CH Real 5.1 (Downmix) (Downmix) HDMI_2 PCM 5.1 PCM 5.1 PCM 2 CH PCM 2 CH Real 5.1 5.1 CH... - Page 13 PCM 2 CH / 5.1 CH PCM 2 CH Virtual 5.1 OPT_1 In (Audio PCM 2 CH PCM 2 CH / 5.1 CH from HDMI PCM 2 CH / 5.1 CH PCM 2 CH Virtual 5.1 OPT_2 In (Audio PCM 2 CH PCM 2 CH / 5.1 CH from HDMI 2 CH...
-
Page 14: Specification
11. Specifications Video Input Ports 3 x HDMI Digital Audio Input Ports 2 x Coaxial, 2 x Optical Analog Audio Input Ports 4 x Audio R/L Video Output Ports 2 x HDMI HDMI Format V1.2 Support Resolution 480i/1080i, 1080p 50/60, 1080p 24, VGA/UXGA HDMI Audio Format PCM2, PCM5.1, Dolby 5.1 (PS3 Setting) HDMI Cable in/out... - Page 16 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20080902 MPM-CX5100AH...
