Page 1: Service Manual
SERVICE MANUAL AUTOMATIC WASHING MACHINE PWMA602PM PWMA1002PM PWMA1202PM... -
Page 2: Table Of Contents
TABLE OF CONTENTS 1. SAFETY PRECAUTION......................1.1 Safety Precaution......................... 2.2 Waring..........................2.TROUBLESHOOTING......................2.1 Malfuction and solution....................2.2 Fault tree..........................2.3 Not turn or one-way turn when wash................2.4 Abnormal downtime midway.................... 2.5 Abnormal noise and big vibration..................2.6 No bilging and bilging intermittent................... 2.7 Water does not stop...................... -
Page 3: Safety Precaution
1. SAFETY PRECAUTION 1.1 Safety Precaution „ To prevent injury to the user or other people and property damage, the following instructions must be followed. „ Incorrect operation due to ignoring instruction will cause harm or damage. „ Before service unit, be sure to read this service manual at first. 1.2 Warning ¾... -
Page 4: Troubleshooting
2.TROUBLESHOOTING 2.1 Malfuction and solution Symptoms Daily inspection method Is the fuse damaged or do the fuse box contact badly? Do the power cord plug insert normally？ Not running Do you turn on the tap？ Do you put down the drain hose？ Undrained Is the drain hose blocked？... -
Page 5: Fault Tree
2.TROUBLESHOOTING 2.2Fault tree 1.All operation failure Having Press the power switch After the power switch lighti and connect the water voltage connects，the lumine Change water inlet inlet valve, Whether the water inlet valve scence tubes are light water inlet valve moves or not or not Not having ac... -
Page 6: Not Turn Or One-Way Turn When Wash
2.TROUBLESHOOTING 2.3 Not turn or one-way turn when wash Start anhydrous program, Inspect the drive no water washing and system carefully confirm the motor is no action Whether Bearing department locks the Clutch body is normal or not Please confirm The Motor heating Measure the voltage protects work or not? -
Page 7: Abnormal Downtime Midway
2.TROUBLESHOOTING 2.4 Abnormal downtime Midway Change a Retractor Retractor damage Put down the Drain Hose Drain Hose was not put down Dredge Drain Hose There is water in Drain Hose is blocked the washing beck. Adjust Drain Hose Drain Hose is too long, too high Change Drain Pump Drain Pump damage Dredge Drain Valve... -
Page 8: Abnormal Noise And Big Vibration
2.TROUBLESHOOTING 2.5 Abnormal Noise and Big Vibration When washing Is the motor noisy? Change a motor Is the motor Fasten the motor fastened firmly? Whether clutch Change clutch body body gear is fit Adjust clearance between Impeller rubs Spin Tub the Impeller and Spin Tub When spinning Is the motor noisy? -
Page 9: No Bilging And Bilging Intermittent
2.TROUBLESHOOTING 2.6 NO BILGING and BILGING INTERMITTENT Water Inlet Valve Clear Water Inlet Water Inlet Valve with Filtering Bag is blocked Valve Filtering Bag “hum” sound or not Whether voltage on Water Inlet Valve damage Change Water Inlet Valve the Water Inlet Valve Ventilation tube bending Change Ventilation tube Use water level sensor... -
Page 10: Water Does Not Stop
2.TROUBLESHOOTING 2.7 Water does not stop Whether Water Inlet Valve bilging when turn Change Water Inlet Valve on the tap before switch on the power Whether Water Inlet Valve bilging when Change Controller Board switches on the power before Press the start button Then confirm whether Water Inlet Valve is in good condition... -
Page 11: No Drainage
2.TROUBLESHOOTING 2.8 NO DRAINAGE Dredge Drainage road Drainage road is blocked Change Drain Hose Drain Hose deformation Dredge Drain Valve Drain Valve is blocked Whether there is Dredge Drain Hose Drain Hose is blocked a tractor moves put down Drain Hose was not put down Drain Hose Drain Pump is blocked Dredge Drain Pump... -
Page 12: No Spinning
2.TROUBLESHOOTING 2.9 NO SPINNING Drainage road is blocked Dredge Drainage road Drain Hose deformation Change Drain Hose Drain Valve is blocked Dredge Drain Valve Whether Drainage is normal Drain Hose is blocked Dredge Drain Hose Drain Hose were not put down Put down Drain Hose Drain Pump is blocked Dredge Drain Pump... -
Page 13: Leaking
2.TROUBLESHOOTING 2.10 Leaking Drain Valve is clogged. Dredge the Drain Valve Corrugated pipe was out of shape. Change corrugated pipe Drain Hose Leaking Retractor damage. Change Retractor Drain Hose is not been hung up . Reinstall the Drain Hose Drain Pump is clogged Dredge the Drain Pump The quantity of washing Choose appropriate... -
Page 14: Oily Shape Dirt Adherent
2.TROUBLESHOOTING 2.11 Oily shape dirt adherent Common in use laundry powder Black dirt is latched Spin Tub inside Clean Spin Tub inside onto Spin Tub inside Impeller inside or Impeller inside Or Impeller inside... -
Page 15: Anomaly Alarm
2.TROUBLESHOOTING 2.12 Anomaly alarm Turn on the tap Water inlet is Pressure is too low, not normal Try to increase water Close the washing machine Cover Cover is not closed check the hang system Imbalance alarm Put down the Drain hose , Not draining Try to clear the obstruction... -
Page 16: Unpacking Ways Of Main Parts
3.UNPACKING WAYS OF MAIN PARTS 3. 1 Product disassembly precautions and steps： 1> General attention： 1.When you remove or repair, please you must unplug the power cord firstly 2.When you connect wire，you are sure to connect wire with wiring cap ，use the tool to press wiring cap for connecting firmly and use tape to make the line insulation fully. -
Page 17: Unpacking Ways Of Main Parts
3.UNPACKING WAYS OF MAIN PARTS 3> Product disassembly step-by-step instructions： Product steps serial number Product dissembling detailed steps Picture caption ①Remove the screws on the rear cover (Red circle part) and 1. Remove the screws on the rear cover, remove the drain then take out the rear cover. - Page 18 3.UNPACKING WAYS OF MAIN PARTS ①Pull out the front control panel screws (sometimes need to 4. Pull out the front control panel remove the hole cover) screws, and then remove the top cover screws. ②Remove the top cover front and back screws.
- Page 19 3.UNPACKING WAYS OF MAIN PARTS ①Remove the outer tub cover screws, and take 9. Remove the outer tub cover out the outer tub cover screws and the impeller screws , finally take out the outer tub cover and the ②Remove the impeller impeller.
- Page 20 3.UNPACKING WAYS OF MAIN PARTS ①Remove the motor screws, and 13. Turn the outer tub subordinate -subassembly, and remove the take out motor. ②Remove the bracket screws, motor screws， the bracket screws, the clutch body and take out bracket. subassembly screws, the ③Remove the clutch body retractor screws, and the drain pump screws ( or drain valve...
- Page 21 3.UNPACKING WAYS OF MAIN PARTS ①Remove the base subassembly 17. Remove the base subassembly for cabinet screws,and then for cabinet screws,and then take out the base subassembly take out the base subassembly for cabinet. for cabinet. ②Take out the cabinet.
-
Page 22: Circuit Diagram
4.CIRCUIT DIAGRAM 4.1 The electrical principle picture...
