Summary of Contents for Premium PWM700MG

  • Page 2: Table Of Contents

    CONTENTS 1． Safety notices---------------------------------------------------------------------------------------2 2． Function and technical instruction -----------------------------------------------------------3 3． Parts name -----------------------------------------------------------------------------------------4 4． installation-------------------------------------------------------------------------------------------5 5． Control panel -------------------------------------------------------------------------------------- 6 6． electrical schematic ------------------------------------------------------------------------------9 7． Troubleshooting display and diagnosis -----------------------------------------------------11 8． Troubleshooting display and service --------------------------------------------------------14 9． Dismounting guide-------------------------------------------------------------------------------18 10.

  • Page 3: Safety Notices

    Safety Notices  avoid harm or injure user and other’s life and property, the follow instructions about safety should be In order to seriously obeyed: ■ Ignore the content wrong to use, use the following mark to classify and express the possible harm or .

  • Page 4: Function And Technical Instruction

    Attention ●list as below may cause damage\deformation\collision. ⒈Remove all the water in the washer to avoid freezing. Do not climb or leave heavy things on the washer. ⒉Two persons are needed to move the washer. Bolts must be installed in advance before moving. ⒊The water should below 95℃...

  • Page 5: Parts Name

    ◆degerming More energy will be consumed to do washing or degerming for the clothes or interior of the machine. The function is not recommended. ◆foam check The defoaming procedure will start automatically if too much foam happens. No-foam or little-foam washing powder is recommended.
  • Page 6 installation 4.2.1、 ●Inlet hose connection ●Make sure rubble sealing washer inside the joint of valve. ●Connect the inlet hose closely, prevent leaking. Inspection operation 4.2.2、 ① ②press power supple ③press Plugged in plug, connect inlet hose “start/pause” ④confirm inflow water ⑤confirm automatic corotation and reverse ⑥Close power, open power again, choose dewatering, then press”start/pause”.

  • Page 7: Control Panel

    5．Control panel XQG72-A112P、XQG72-DA112P series control panel XQG70-A210P、XQG70-A212P series control panel XQG72-A312P、XQG72-DA312P control panel...
  • Page 8 XQG70-A410P、XQG70-A412P series control panel XQG60-A208E/TE、XQG60-A210E/TE、XQG60-A212E/TE series control panel 1,function key 2. Reserve 3Start/pause 4.program knob XQG60-A508E/TE、XQG60-A510E/TE、XQG60-A512E/TE series control panel 1.spin speed 2.temperature 3. reserve 4. Function key 5. start/pause 6. Program knob...
  • Page 9 XQG60-A808E/TE/k/TK、XQG60-A810E/TE/K/、 XQG60-A812E/TE/K/TK series control panel 1.spin speed 2.temperature 3. reserve 4. Function key 5. start/pause 6. Program knob 6．circuit diagram XQG72-A112P、XQG72-A312P Serials circuit diagram...

  • Page 10: 6． Electrical Schematic

    XQG70-A210P、XQG70-A212P、XQG70-A410P、XQG70-A412P Serials circuit diagram XQG72-DA112P、XQG72-DA312P Serials circuit diagram...
  • Page 11 XQG60-A208/E/TE/K/TK、 XQG60-A508/E/TE/K/TK、 XQG60-A808/E/TE/K/TK Serials circuit diagram 7． Error indication & analysis 7.1、 XQG72-A112PR、 XQG72-DA112PR、 XQG72-A312PR、 XQG72-DA312PR Serials error indication. Error Code Checking/Reason Settlement 1.Push “Start” ●flooding water 5-10min. but haven’t reach 2.Open the inlet tube the appointed water level 3. unfreeze ●Is the water tap ON? flooding water E01（E1）...

  • Page 12: Troubleshooting Display And Diagnosis

    ● draining 5-10min still haven’t reach empty 1.Press “Start” knob. water level. 2.Clean the filter Draining error E03（E3） ●water pump filter is blocked by something. 3. Change draining ● Dose draining pump frosted or broken? pump. 1.Put the machine ●the machine is gradient. Unbalance balanced.
  • Page 13 7.3、XQG70-A210P、XQG70-A212P、XQG70-A410P、XQG70-A412P Serials error indication. Error Code Checking/Reason Settlement ●flooding water 5-10min. but haven’t reach 1.Push “Start” the appointed water level 2.Open the inlet tube ●Is the water tap ON? Pre-wash flooding 3. unfreeze ●Is the water tap frosted? water error 4.Get through the water.
  • Page 14 XQG60-A208/E/TE/K/TK Serials error indication. Error Code Checking/Reason Settlement ● If the water tap is 1 、 Checking the water tap is running water stream is too slow. running or not and the water steam. flooding ● water level sensor or 2．...

  • Page 15: Troubleshooting Display And Service

    8. Fault diagnosis and repair 8.1、Please de-energize (pull the plug or trip the breaker on) before diagnosis or repair 8.2、Ensure every wiring harness in the right connection. 8.3、Please repair the PC broad in the correct position 8.4、Please fully analysis and understand the fault before repair Power off Sequence Items...
  • Page 16 sequence Items Methods Has the fill hose bend or frozen Repair fill hose Clear pump and reconnect it Has the bilge pump clogged Has the wiring harness connected wiring harness Reconnect Has the bilge pump broken Change bilge pump PCB fault Change PCB Door lock fault sequence...
  • Page 17 2、 first valve inflow 3 second, second valve inflow 3 second, third valve inflow 3 second. second and third valve  inflow  till  1  grade  water  level  (  water  transducer  measure  the  water  level.  LED  or  LCD  display  show  1L‐2  when the    first valve inflow, stop inflow ‐‐‐‐‐‐‐‐ 18 SECOND  3、 Water transducer will measure the water temperature. Display show HXX 3sencond. XX means the current  water temperature, The temperature is in 0‐45  ℃  period. If over this and will come out the waning signal  E11 ‐‐‐‐‐‐‐‐‐‐‐‐      3S  4、 Heating pipe work 5 second  5、 washing motor work, foreword 3 second, pause 3 s, rollback 3s. if the motor do not work, it will have E05signal 6、...
  • Page 18 Prewashing light Rinse light Draining light Motor stop rotate i heating pipe detection: heating pipe work 5S Draining pump. motor(high speed)detection Press prewashing + avoid draining light, and then connect power after 3S into online detection condition b. Draining pump detection( light on), open draining pump, draining to 0 water level. draining fault show: Prewashing light Rinse light...

  • Page 19: Dismounting Guide

    the water into the heating water level, and then start heat up. heating time 5S 6) C06 motor direction of rotation detection(P07 position): spin speed 50rmp, fore ward 5S 7) C07 outer barrel leakage detection(P08 position): Judge the water level to washing 1 water level, if not, must fill the water in to washing 1 water level.
  • Page 20 admission valve ① Take of the admission valve’s connection    ② Remove  two  bolts  from  the  back  of  the  admission  valve  ③Remove the hose clip and hose Bottom dam-board ① Using corns or screwdriver to open the bottom dam-board(photo 5), remove the one bolt ③ （photo  6） 。Using  the  screwdriver  to  open  the  图５...
  • Page 21 the motor bush.(photo 14)  ③ Follow the arrow to take off the motor (photo 15)  图 14 图 15 ④Ensure the bush is in the motor holder while reset the motor ①Remove the fixed bolt from absorber. ②Take out the absorber ③Ensure tighten the fixed bolt while reset the absorber to avoid the noise from spin Clear draining pump filer ①...

  • Page 22: Exploded View

    ② Open top cover, control panel board, bottom 图 21 dam-board and front cover ② Remove eight bolt from the top bracing sheet and take off the front top bracing sheet (photo 21) ③Remove the bolt from the outer box.(photo 22) 图...
  • Page 23 XA1QG72D.6.2-2 distributary box XA1QG72D.6.2-3 distributary box cover XA1QG72D.6-1 EPDM hose 10.2、OUTER TUB ASSEMBLY Code Name Quantity Materail Remark XDQ10-01 pressure sensor X1QG60.1-8 suspension spring stopper XA6QG70E.7-4(127) 65Mn suspension spring XBJ01-02 65Mn hose clamp 13 XSL03-03 INLET HOSE AS XDQ02-01 inlet valve PLASTIC HOSE CLAMP XA1QG72D.12-7 X1QG60.9.2-1...
  • Page 24 XA1QG72D.1-8 door lock water retaining slice XA1QG72DE.9.2 drain pump XA1QG72D.9.1 electronic control box as XA1QG72D.7-3 drain tube EPDM XA1QG72D.7-11 Inner door seal clamp 65Mn XA1QG72D.9-5 door lock XA1QG72DE.7-9 door seal EPDM XA1QG72D.9.2-3 drain-pipe stopper XA1QG72D.4-2 pump cover XA1QG72D.4-1 lower panel XA1QG72D.1-3 front panel SPCD...
  • Page 25 AIIOY XA1QG72D.5-8 door handle XA1QG72D.5-10 door handle pin XA1QG72D.5-9 door handle spring SUS304 ZINC BASE XA1QG72D.5-7 door hook AIIOY 10.4、Control Panel AS Code Name Quantity Materail Remark XA1QG72D.3-1 control panel light display board 1 XA1QG72D.3-11 light display board 2 XA1QG72D.3-12 LCD display board XA1QG72D.3-13 LCD seal ring...
  • Page 26 Code Name Quantity Materail Remark XA1QG72D.7-3 drain tube EPDM XA1QG72D.7.2-3 Fixer SGCC X1QG60.7.6-11 XA1QG72D.7-7 lower balancer COCRETE+IRONSAND AS430 X1QG60.9-16 heater XA1QG72D.7.2-2 heater support front tub PP+30GF XA6QG70E.7.2-1(127) inlet tube EPDM XA1QG72D.7-4 XA6QG70E.7-1(127) upper balancer 1 cast iron exhaust hose EPDM XA1QG72D.7-8 tub seal XA6QG70E.7-3(127)
  • Page 27 0.6、Drying AS（PS：This picture only for the washer combine with dryer machine.） Code Name Quantity Materail Remark XA1QG72D.8-6 SGCC Drying supporting fixed plate XA1QG72D.8-3 supporter cover 2 XA1QG72D.8-5 Drying heat pipe hot air duct sealing strips XA1QG72D.8-4 XA1QG72D.9-1 Drying temperature controller Drying motor XDQ04-03 PA+15%GF...
  • Page 28 10.7、top board AS Code Name Quantity Materail Remark XA1QG72D.2 top board AS 10.8 、 XQG70-A210P 、 XQG70-A212P some parts exploded view. PS ： other parts refer to XQG72-A112P。...
  • Page 29 Code Name Quantity Materail Remark XA2QG70E.3-1(044) control panel DV60Q1E.3.1-1 knob XA2QG70E.3-1(044) knob support XA2QG70E.3.2-1(044) knob pin XA2QG70E.3-4(044) button 2 XA2QG70E.3-5(044) button support XA2QG70E.3-3(044) button 1 XA2QG70E.3-2(044) light guide XA2QG70E.3-1(044) light supporter XA2QG70E.3.1-1(044) XA2QG70E.3.1-1(044) pcb housing XA2QG70E.3.1-4(044) PCB AS 10.9 、 XQG70-A410P 、 XQG70-A412P some parts exploded view. PS ： other parts refer to XQG72-A112P。...
  • Page 30 XA4QG70E.3-2(062) light guide 1 XA4QG70E.3.1-5(062) light supporter 2 XA4QG70E.3-3(062) light guide 2 XA4QG70E.3-4(062) button XA4QG70E.3-1(062) control panel XA2QG70E.3.2-1(044) knob pin XA2QG70E.3.2-1(062) knob 10.10 XQG60-A208/E/TE/K/TK、XQG60-A508/E/TE/K/TK、XQG60-A808/E/TE/K/TK Every part exploded view Tub AS Code Name Quantity Materail Remark XA2QG60.6.2-1(167) detergent dispenser housing XA2QG60.6.1-1(167) detergent dispenser XA2QG60.6.1-2(167) siphon...
  • Page 31 X1QG60.1-8 suspension spring stopper XA2QG60.1-2(167) suspension spring 65Mn XA2QG60.1.1-2(167) cabinet left top frame SPCD XDQ10-04 pressure sensor XA2QG60.1-3(167) pressure sensor support PPT620 XA2QG60.1.1-3(167) cabinet right top frame SPCD XSL03-05 INLET HOSE XDQ02-01 inlet valve XA1QG72D.12-7 PLASTIC HOSE CLAMP XA2QG60.8-2(167) filter XDQ05-51 power cord XSL07-01...
  • Page 32 XA2QG60.7-4(167) drain tube DPDM XA1QG72D.7.2-3 SGCC Fixer XA2QG60.7-8(167) lower balancer COCRETE+IRONSAND XLD02-05 lower balancer bolt Q235-A GB/T96.2-2002 washer Q235-A XA2QG60.8-3(167) heater XA1QG72D.7.2-2 heater support SUS304 XA2QG60.7.2-1(167) front tub HG43 XA2QG60.7-3(167) inlet tube DPDM XA2QG60.7-2(167) exhaust hose DPDM XA2QG60.7-14(167) tub seal DPDM XA2QG60.7.1-1(167) lifter...
  • Page 33 Code Name Quantity Materail Remark XA1QG72D.5-6 door decorated ring XA1QG72D.5-4 transparency window 透明 ABS XA1QG72D.5-5 door glass GALSS XA1QG72D.5-3 door frame XA1QG72D.5-2 hinge cap ZINC BASE XA2QG60.5-3(167) door hinge AIIOY XA1QG72D.5-8 door handle XA1QG72D.5-10 door handle pin XA1QG72D.5-9 door handle spring SUS304 ZINC BASE XA1QG72D.5-7...
  • Page 34 Code Name Quantity Materail Remark XA2QG60.3-1(167) control panel DV60Q1E.3.1-1 knob DV60Q1E.3.1-2 knob support XA2QG60.3.2-1(167) knob pin XA2QG70E.3-4(044) button 2 XA2QG60.3-5(167) button support XA2QG70E.3-3(044) button 1 XA2QG60.3-2(167) light guide XA2QG60.3.1-2(167) XA2QG60.3.1-1(167) 阻燃 ABS pcb housing...
  • Page 35 Code Name Quantity Materail Remark XA2QG60.2-3（167） front frame XA2QG60.2-1(167) top board XA2QG60.2-2(167) rear frame...
