Dry Ironing; Self-Clean Function; Storing The Iron - Elba ESI-A2230S Owner's Manual

DRY IRONING

To iron without steam-dry ironing, turn the dry dial (3) to "0" position (no steam).
CLEANING

Before cleaning the iron in any way, make sure that the appliance plug is not connected
to the wall outlet.

Any deposits, starch residue or size left on the soleplate can be removed using a damp
cloth or an unabrasive liquid detergent.

Avoid scratching the soleplate with steel wool or metallic objects.
The plastic parts can be cleaned with a damp cloth then wiped over with a dry cloth.

SELF-CLEAN FUNCTION


The self-clean feature helps to cleans inside the plate, removing impurities. We
recommend using it every 10-15 days.

Directions:
 Fill the water tank (10) according to the maximum water level indicator.
 Connect the plug into a standard 220-240V AC electrical outlet near a sink, turn
the temperature control dial (11) to the MAX position. Rest the iron in vertical
position and stable surface and allow it to heat until the indicator light (9) goes
off.
 Hold the iron horizontally over the sink and press the self-clean button (14) [Fig.
7]. Boiling water and steam will be released from the soleplate (13), taking
impurities with them. Move the iron forward and backward until the water tank
is empty. Then, turn the steam dial (3) to "0" position and the temperature
control dial to MIN. Disconnect the plug from the wall outlet and let the iron to
cool down.
 If it appears that more self-clean is necessary (e.g., if impurities can still be seen),
repeat above steps until the soleplate and water tank are clean. Dry thoroughly
until impurities are totally cleaned.
 When the soleplate has cooled down, you can clean it with a damp cloth.

STORING THE IRON


Disconnect the plug of the iron from the wall outlet.

Empty the water tank (10) by moving the iron forward and backward.

Leave the iron to cool down completely.

Roll up the supply cord [Fig. 8].

Always put the iron in a vertical position.
6
