NEC MultiSync LCD1970NX Service Manual page 79

For Europe
SYMBOL
(NPG Part Number)
B434 80000991
B435 80000991
B436 HM017021
B437 HM017021
B439 HM017021
B442 HM017021
*** ELECTRICAL PARTS & MISCELLANEOUS PARTS ***
3A684091
LCD
(NMV Part Number)
P402 RA805152
X401 E8100131
XD1002 RE010091
XD1007 RG030051
XD1010 R3201481
XD1011 R3201471
*** APPEARANCE PARTS ***
LABEL 15004111
M-CONN 17002721
XD1000 10107371
XD1001 10107611
XD1003 12001211
XD1004 11700781
XD1008 12302271
XD1009 14900221
*** PRINTED & PACKING MATERIALS ***
BAG-1 13700483
CARTON 13204921
MANUAL 15503533
WRNTY1 15802261
WRNTY2 15802161
XD1005 13401781
XD1006 13401771
*** RESISTORS ***
F401 FM100000
F402 FM100000
R401 FM010103
R403 FM010103
R404 FM010103
R405 FM010103
R406 FM010000
R407 FM010103
R408 FM010103
R409 F8012490
R410 FM010103
R411 FM010103
DESCRIPTION
BEAD WBR6H-3T-R7K-B5
BEAD WBR6H-3T-R7K-B5
L BEAD SMD MCB1608S121G
L BEAD SMD MCB1608S121G
L BEAD SMD MCB1608S121G
L BEAD SMD MCB1608S121G
TFT LM190E02-A4K5
CN MINI-D-SUB 15P SIDE
OSC X'TAL 49US 14.318MHZ
CABLE VIDEO BLK DSUB-DSUB
PW CORD EU 2M BLK WANSHIN
WIRE CC12P 1571#30L180
WIRE CC30P 1589#30L220
LABEL RATING LCD1970NXH B
PAD,L194,LPL
BACK L194RJ (N) BK
BEZEL WH(N) BC L194RJ
CHASSIS BASE 1970NXH,(LPL
COVER UNIT BK L194RJ
SHIELD 1970VH/NXH
STAND UNIT L194R BK
BAG LCD1960NX EPE
CARTON BOX LCD1970NX B
MANUAL ASSY LCD1970NX B
SHEET CAUTION PISA19 B
SHEET SETUP LCD1970NX/V B
FILLER B L194R,(A,B,C,)
FILLER T L194R,(A,B,C,)
CHIP 1/8W(T) 5% 0 H
CHIP 1/8W(T) 5% 0 H
CHIP RES 1/10W(T) 5% 10KO
CHIP RES 1/10W(T) 5% 10KO
CHIP RES 1/10W(T) 5% 10KO
CHIP RES 1/10W(T) 5% 10KO
CHIP RES 1/10W(T) 5% 0OHM
CHIP RES 1/10W(T) 5% 10KO
CHIP RES 1/10W(T) 5% 10KO
R SMD METAL 1/10W 249 F 0
CHIP RES 1/10W(T) 5% 10KO
CHIP RES 1/10W(T) 5% 10KO
8-11
