Invacare SC Rehab Seat Power Wheelchair Parts List

® ®
Invacare TDX SC Rehab Seat Power Wheelchair
Price List and Order Form
For ease of ordering, contact Customer Service Toll Free at:
800-333-6900 Fax: 800-678-4682
To order Literature: 800-828-6282
Company Name ______________________________________________________Account # ____________________________________________
Phone ________________________ P.O. # ________________________________Date_________________________________________________
Ship to Name & Address ____________________________________________________________________________________________________
HCPCS codes are not intended to be, nor should be considered billing or legal advice. Providers are responsible for determining the appropriate billing codes
when submitting claims to the Medicare Program and should consult an attorney or other advisor to discuss specific situations in further detail.
CHAIR TYPE
TDXSC TDX SC with MK6i
TDXSCSEAT TDXSC Seat Only ................................................ 755.00
Group 3 – K0848
Basic Package
TDX SC with MK6i and Adjustable Rehab Seat
250 lb Weight Capacity
DW1053FF 10.5"X 3.5" Flat Free Tires.........................Standard
2 Pole Motors...................................................................Standard
Flip Back Fixed Height Arm ...........................................Standard
MK660ACC 60 Amp Controller.....................................Standard
SPJ+ Single Drive Joystick .............................................Standard
70NHD 70° Swingaway Footrests .................................Standard
8 Amp Off Board Battery Charger .................................Standard
1515 Push Button Style Seat Positioning Strap .............Standard
* TRANSPORT TIE-DOWN
TRRO includes four factory-installed transport brackets and a wheelchair
anchored pelvic belt. TRRO has been crash-tested in accordance with
ANSI/RESNA WC Vol 1.Section 19 Front Impact Test requirements for
Wheelchairs with a 168 lb crash dummy, which corresponds to a person with a
weight of 114 lbs to 209 lbs.
TRBKTS includes four factory-installed wheelchair transport brackets.
TRBKTS has not been crash-tested in accordance with WC19. Use these
transport brackets only to secure an unoccupied wheelchair during transport.
As of this date, the Department of Transportation has not approved any tie-down
systems for transportation of a user while in a wheelchair, in a moving vehicle
of any type. It is Invacare's position that users of wheelchairs should be
transferred into appropriate seating in vehicles for transportation and use be
made of the restraints made available by the auto industry. Invacare cannot and
does not recommend any wheelchair transportation systems.
* Transport Tie-Down option is not retrofittable to existing models and is not
field serviceable.
FOOTNOTES
1
TDXSC comes standard with: 250 lb user weight capacity, 4.8 mph top speed,
2-pole motor package & MK6i SPJ
Quiet Stability Lock. Base width is 24".
Effective May 18, 2009
™
(K0848)......................... 5,720.00
™
+ Joystick, MK660ACC Controller, and
NOTE: All specifications and dimensions are approximate.
For the most current pricing information go to www.invacare.com.
www.invacare.com
Special Note
1
TRRO FEATURES FOR TDX SC
Features Required for TRRO
•
TDXSC
•
70° Swingaway, 70° Tapered
(70NHD or 70STAPER) or Manual
Center Mount Front Riggings
•
Any Arm Style
•
Adjustable Rehab Seat with
Adjustable Seat Tilt & Back Angle
•
Sectional or Straight Rear Uprights
or No Push Handles
•
10.5" x 3.5" Tires with Foam Filled
Inserts
•
90° or 95° Back Angle
•
18" - 24" ASBA Back Height
•
Any Seat Width
•
Any Seat Depth
•
250 lb user weight limit
•
Low Seat-to-Floor Height
•
Any Color Frame Finish
Please note that all TRRO chairs are set at a 5° seat angle
TRANSPORT TIE-DOWN
TRRO Transport Ready Option ....................................... 300.00
TRBKTS Wheelchair Transport Brackets ............................ 250.00
USER WEIGHT LIMIT
UW250 User Weight <250 lb........................................ Standard
WHEEL OPTION (PAIR)
DW10535FF 10.5" x 3.5" Flat Free Tires ............................. Standard
WHEEL OPTION (PAIR)
DW10535FF 10.5" x 3.5" Flat Free Tires ............................. Standard
FORK OPTION
FKPKG One-Sided Fork Package ...................................... 500.00
FOOTNOTES
2
Not available with elevating seat.
Optional Features for TRRO
•
Adjustable Angle Flip Up
Footplates, Flip-Up Composite
Footplates or Aluminum
Footplates-Deluxe
•
Wheel Locks
•
Calf Strap
•
Heel Loops w/Ankle Straps
•
Impact Guards
•
One Sided Fork Package
•
SPJ+, MPJ+ Joystick
•
All PSR+ / PSF+ Joysticks
•
Proportional Attendant Control
•
"T" Handle Flexible Joystick
Ext.
•
Left Hand Mounted Joystick
•
Straight Handle Flexible
Joystick Ext.
•
Easy Remote Programmer
•
Reinforced Back Upholstery
•
U1 Batteries
BASE
2
