PORTABLE EXTRACTOR
MODELS:
411-222HMO
10070290
411-225HMO
10070310
AB
86038700 05/14/09
PRV NO. 98872
Read these instructions before using the machine
Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 411-222HMO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ninja 411-222HMO

Summary of Contents for Ninja 411-222HMO

  • Page 1 PORTABLE EXTRACTOR Operating Instructions MODELS: 411-222HMO 10070290 411-225HMO 10070310 Read these instructions before using the machine 86038700 05/14/09 PRV NO. 98872...

  • Page 2: Machine Data Log/Overview

    For the name and address of your dealer contact: Windsor Industries Phone Number: _________________________________________________________________________________________ OVERVIEW The Ninja is an electric powered carpet extractor intended for commercial use. This appliance applies a cleaning solution to the carpet and then vacuums the soiled water back into the recovery tank.

  • Page 3: Table Of Contents

    Priming the Pump ..........3-3 Emptying & Cleaning Tanks......3-4 MAINTENANCE Daily Maintenance..........4-1 Periodic Maintenance...........4-1 Monthly Maintenance ...........4-1 Semi-annually ............4-1 Lubrication............4-1 Storage..............4-1 Vacuum Motor Replacement .......4-2 Solution Pump Replacement........4-2 Pump Replacement Kits........4-3 Pressure Regulator ..........4-4 Machine Troubleshooting........4-5 NINJA W/ HEAT 86038700 03/27/07...

  • Page 4: How To Use This Manual

    NOTE: If a service or option kit is installed on your machine, be sure to keep the KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. SERIAL # TAG NINJA W/ HEAT 86038700 03/27/07...

  • Page 5: Important Safety Instructions

    This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices for more than normal housekeeping purposes. Maintenance and repairs must be done by qualified personnel. If foam or liquid comes out of machine, switch off immediately. SAVE THESE INSTRUCTIONS NINJA W/ HEAT 86038700 03/27/07...

  • Page 6: Hazard Intensity Level

    Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. NINJA W/ HEAT 86038700 03/27/07...

  • Page 7: Safety Label Location

    NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible, promptly replace them. -WARNING- LABEL WARNING 86242230 PRV NO. 500009 LABEL HEATER MATE WARNING TAG 86200000 PRV NO. 170-31 LABEL CIRCUIT INTERRUPTER 86200570 PRV NO. 170-41 NINJA W/ HEAT 86038700 03/27/07...

  • Page 8: Grounding Instructions

    Whenever the adaptor is used, it must be held in place by a metal screw. NINJA W/ HEAT 86038700 03/27/07...

  • Page 9: Technical Specifications

    200 lbs (440 kg) Height 36 inches (91.44 cm) Length 29 inches (73.66 cm) Width 19.5 inches (49.53 cm) Power cord 22 feet (6.71 m) Heater 1850 watt LENGTH WIDTH HEIGHT CENTURY 400 PUMP VACUUM #1 VACUUM #2 NINJA W/ HEAT 86038700 04/24/09...

  • Page 10: Controls

    CONTROLS CENTURY 400 Pump Switch Vacuum #1 Switch Vacuum #2 Switch Heater Switch Heater Indicator Light NINJA W/ HEAT 86038700 03/27/07...

  • Page 11: Machine Operation

    7. Start cleaning. connection; front of machine) toward machine. 3. Do this for 30 seconds or until there is a steady flow of water flowing through the sight tube (located on right side of recovery tank.) NINJA W/ HEAT 86038700 04/24/09...
  • Page 12 When this occurs, empty the vacuum tank by opening the dump valve and dispose of the waste in a proper manner. 5. Once the vacuum tank has been emptied, you may once again proceed with cleaning NINJA W/ HEAT 86038700 03/27/07...

  • Page 13: Maintenance

    This heater will freeze and through the extractor, turning pump switch possibly crack voiding your warranty. on/off several times, flush with clean water. This will prevent build-up of alkaline residue in the system. NINJA W/ HEAT 86038700 03/27/07...

  • Page 14: Vacuum Motor Replacement

    Periodically check the length of the carbon brushes. Replace both carbon brushes when either is less than 3/8" (9.5mm) 8 [9.5mm] long. Periodically check the length of the carbon brushes. Replace both carbon brushes when either is less than 3/8" (9.5mm) long. NINJA W/ HEAT 86038700 03/27/07...

  • Page 15: Pump Replacement Kits

    PUMP REPLACEMENT KITS CAM & BEARING KIT 500 PSI 86201040 PRV NO. 250-73C MOTOR ONLY 86200800 PRV NO. 53262 VALVE & O-RINGS KIT (BOTH SIDES) 86201030 PRV NO. 250-73B PLUNGER & SEALS KIT 86201080 PRV NO. 250-75A NINJA W/ HEAT 86038700 03/27/07...

  • Page 16: Pressure Regulator

    5. Lubricate the piston and u-cup with Superlube. 6. Reassemble regulator. 7. With pump ON, re-adjust pressure regulator for normal operation. LUBRICATE U-CUP WITH SUPERLUBE MONTHLY. U-CUP SPRING RETAINER PLATE PISTON SPRING (BLUE- 200 PSI) (SILVER-500 PSI) NINJA W/ HEAT 86038700 03/27/07...
  • Page 17 Go over carpet with browning prevent only prevention Solution hose connection Check for positive connection Solution not flowing Faulty pump Repair or replace properly Faulty floor tool valve Repair or replace Faulty pump switch Repair NINJA W/ HEAT 86038700 03/27/07...

  • Page 18: Frame Group (200 Psi)

    FRAME GROUP (200 PSI) NINJA W/ HEAT 86038700 03/27/07...
  • Page 19 060-04A CORD 25’ BLK 14/3 SJTW/A PLUG 86199530 060-04 CORD 25’ BLK 12/3 SJTW/A PLUG 86202160 320-05 VELCRO STRAP 86274210 70129 SCR, 1/4-20 X 3 HHCS PLTD 86274040 70076 SCR, 10-32 X 1 PFHMS PLT NINJA W/ HEAT 86038700 03/27/07...

  • Page 20: Frame Group (500 Psi)

    FRAME GROUP (500 PSI) NINJA W/ HEAT 86038700 03/27/07...
  • Page 21 70663 SCR, 1/4 –20 X 3 1/4 HHCS PLTD 86274040 70076 SCR, 10-32 X 1 PFHMS PLT 86006830 70386 SCR, 10-32 X 1.0 PPHMS 86010650 87018 WASHER, #10 X 9/16 OD 86006350 67029 RECTIFIER, BRIDGE NINJA W/ HEAT 86038700 03/270/7...

  • Page 22: Pump And Heater Group (200 Psi)

    PUMP AND HEATER GROUP (200 PSI) NINJA W/ HEAT 86038700 03/27/07...
  • Page 23 HEATER ASM, NINJA COMPLT 86282310 39699 HOSE, 3/8 WIREBOUND X 35” 86197550 40014 HOSEBARB, 1/4MPT X 3/8 DL 86258970 84193 VALVE, KNGSTN 3” LVR 500 PSI 86197670 56023 NIPPLE, 1/4 X 1.5 86197760 78308 TEE, 1/4 STREET NINJA W/ HEAT 86038700 03/27/07...

  • Page 24: Pump And Heater Group (500 Psi)

    PUMP AND HEATER GROUP (500 PSI) NINJA W/ HEAT 86038700 03/27/07...
  • Page 25 HOSE, 3/8 WIREBOUND X 35” 86197550 40014 HOSEBARB, 1/4MPT X 3/8 DL 86258970 84193 VALVE, KNGSTN 3” LVR 500PSI 86197670 56023 NIPPLE, 1/4 X 1.5 86197760 78308 TEE, 1/4 STREET *INCLUDED IN 86005590 56014 NIPPLE, 1/4 CLOSE NINJA W/ HEAT 86038700 03/27/07...
  • Page 26 RECOVERY & SOLUTION TANK GROUP NINJA W/ HEAT 86038700 03/27/07...

  • Page 27: Recovery And Solution Tank Group

    FOAM TAPE, 1/8T X 3/4 1SDA 86273820 70019 SCR, 1/4-20 X 1.25 HHCS SS 86199900 110-26A GASKET NINJA LID 86201290 280-02 RIVET AL. 3/16 X 1/2 CLOSED 86090320 87257 WASHER, HOSEBARB 86237770 35256 GASKET, DUMP VALVE NINJA W/ HEAT 86038700 03/27/07 5-10...

  • Page 28: Vacuum Motor Group

    VACUUM MOTOR GROUP NINJA W/ HEAT 86038700 03/27/07 5-11...
  • Page 29 NUT, 1/4-20 HEX W/ STAR WASHER 86075210 20062 CLAMP, 3/8 NYLON MCHND 86282300 39698 HOSE, 3/8 CLR PLYURTHN X 24” 86003500 31076 ELBOW, 1/4MPT X 3/8 TUBE, QC 86197370 31017 ELBOW, 1/4 FPT X 1/4 FPT NINJA W/ HEAT 86038700 03/27/07 5-12...

  • Page 30: Wiring Group (200 Psi)

    WIRING GROUP (200 PSI) NINJA W/ HEAT 86038700 05/14/09 5-13...

  • Page 31: Wiring Group (500 Psi)

    WIRING GROUP (500 PSI) NINJA W/ HEAT 86038700 03/27/07 5-14...
