RISO HC5500
Universal V 1.0
Environmentally Friendly
Colour Capable Copier and Printer
HC5500 with Stacker
HC5500 with Finisher
Copying Quick Reference Guide
Service Helpdesk
020 8236 5832
Supplies (Ink & Staples)
0800 783 2086
Head Office
020 8236 5800

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HC5500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Riso HC5500

Summary of Contents for Riso HC5500

  • Page 1 RISO HC5500 Universal V 1.0 Environmentally Friendly Colour Capable Copier and Printer HC5500 with Stacker HC5500 with Finisher Copying Quick Reference Guide Service Helpdesk 020 8236 5832 Supplies (Ink & Staples) 0800 783 2086 Head Office 020 8236 5800...

  • Page 2: Table Of Contents

    Index Universal V 1.0 Page HC5500 Layout A4 / A3 Producing a copy Enlarging A4 to A3 Reducing A3 to A4 A4 Copying Single to Double Sided (Portrait Originals) A4 Copying Double to Double Sided (Portrait Originals) A4 & A3 Copying Single to Double Sided (Landscape Originals) A4 &...

  • Page 3: Hc5500 Layout

    HC5500 Layout Universal V 1.0 HC5500 with Stacker HC5500 with Finisher Standard Feed Tray (Default) Scanner featuring: A4-R (long edge first) Automatic Document Feeder Paper & Card up to 210gsm Glass for copying books Feed Tray 1 Staples 100 A4 (short edge first)
  • Page 4 A4 / A3 - Producing a Copy Universal V 1.0 Place A4 or A3 originals face up into the scanner Select FEED TRAY 2 for A3 Copies in the direction indicated above Ensure side guides are firm against the originals Select number of required copies PLEASE NOTE: If printing A4 go straight to step 4 Or select MANUAL...
  • Page 5 Enlarging A4 to A3 Universal V 1.0 Place A4 original SHORT EDGE first in the ADF Select STANDARD / ZOOM section of the Scanner. Ensure side guides of ADF are firm against originals. Select MANUAL then from the pop up Select A4 >...

  • Page 6: Select Manual Then From The Pop Up

    Reducing A3 to A4 Universal V 1.0 Select A3 > A4 Select MANUAL then from the pop up selection choose FEED TRAY 1 Select OK Select STANDARD / ZOOM...

  • Page 7: Universal V 1.0

    A4 - Single to Double (Portrait) (Simplex to Duplex) Universal V 1.0 Place A4 originals face up with the long edge of Select DUPLEX the sheet(s) feeding into the scanner. Ensure side guides are firm against the originals Select SIMPLEX TO DUPLEX Select STANDARD FEED TRAY Select LONG EDGE BINDING Select LAYOUT...
  • Page 8 A4 - Double to Double (Portrait) (Duplex to Duplex) Universal V 1.0 Place A4 originals face up with the long edge of Select DUPLEX the sheet(s) feeding into the scanner. Ensure side guides are firm against the originals Select DUPLEX TO DUPLEX Select STANDARD FEED TRAY Select BIND L-R Select LAYOUT...
  • Page 9 A4/A3 - Single to Double (Landscape) (Simplex to Duplex) Universal V 1.0 Place A4 or A3 originals face up into the scanner Select DUPLEX in the direction indicated above Ensure side guides are firm against the originals Select SIMPLEX TO DUPLEX Select MANUAL Select SHORT EDGE BINDING Choose STANDARD FEED TRAY for A4...
  • Page 10 A4/A3 - Double to Double (Landscape) (Duplex to Duplex) Universal V 1.0 Place A4 or A3 originals face up into the scanner Select DUPLEX in the direction indicated above Ensure side guides are firm against the originals Select DUPLEX TO DUPLEX Select MANUAL For A4 select BIND TOP-BOTTOM Choose STANDARD FEED TRAY for A4...

  • Page 11: Deleting A Job

    Deleting a Job Universal V 1.0 Select the green coloured PRINT / PAUSE Press and highlight the job you wish to delete button on the printer to halt the job Select the DELETE button to delete job Press COPY to return to copy screen Select the RESET button Select JOB MANAGER on the Touch Screen Finally press the PRINT/PAUSE button on the...

  • Page 12: Select Ok

    Multi-up same image on one page Universal V 1.0 Select MANUAL then from the pop up Select MULTI - UP (SINGLE) selection choose the feed tray with the size of Then choose one of 2 / 4 / 8 PAGE options paper you wish to print on.
  • Page 13 Multi-up – different images on one page Universal V 1.0 Select MANUAL then from the pop up Select MULTI - UP (PLURAL) selection choose the feed tray with the size of Then choose one of 2 / 4 / 8 PAGE options paper you wish to print on.

  • Page 14: Hole Punching

    Hole Punching – on Left or Right Side Universal V 1.0 The functions shown on this page are only possible with the optional Finisher fitted to the Riso HC5500 Ensure STANDARD FEED TRAY (default) Select LEFT or RIGHT side selected when Punching on the LEFT or RIGHT...
  • Page 15 Left or Right Side (Portrait Originals) Universal V 1.0 The functions shown on this page are only possible with the optional Finisher fitted to the Riso HC5500 Ensure STANDARD FEED TRAY (default) Select LEFT or RIGHT side selected when Stapling on the LEFT or RIGHT...
  • Page 16 Left Top Corner (Landscape Originals) Universal V 1.0 The functions shown on this page are only possible with the optional Finisher fitted to the Riso HC5500 Ensure FEED TRAY 1 is selected Select LEFT side Originals placed short edge into the scanner...
  • Page 17 Originals for booklets must be single pages, these Select LAYOUT can be single or double sided. When booklet making the HC5500 will place these Select BOOKLET in the correct page order to create a booklet Choose paper tray for required booklet size:...
  • Page 18 Booklets / Print, Fold & Staple Universal V 1.0 The functions shown on this page are only possible with the optional Finisher fitted to the Riso HC5500 ORIGINALS BOOKLET Originals for booklets must be single pages, these can be single or double sided.
  • Page 19 Saving a Job in Storage Universal V 1.0 Select START and job will be saved to Storage Select COPY AND STORAGE or STORAGE Job will be saved as “DIRECT” followed by a The chosen job settings and copy count will sequential number.

  • Page 20: Collate / Non Collate

    Collate / Non Collate Universal V 1.0 COLLATE = NON COLLATE = Select EXTENTIONS Select PRINTER COLLATE Select COLLATE (this is the default) Or NON COLLATE...

  • Page 21: Offset Stacking

    Offset Stacking Universal V 1.0 HC5500 with HC5500 with Stacker Finisher Select EXTENTIONS Select EXTENTIONS Select OFFSET OUTPUT to activate Select PAPER RECEIVING TRAY Choose STACKING TRAY Select OFFSET DISCHARGE (stacking) ON OFFSET STACKING...

  • Page 22: Essential Things To Remember

    Essential Things to Remember Universal V 1.0 CLEANING THE LOADING PAPER SCANNER GLASS Ensure both sections of scanner glass (shown here Always ensure the guides on the paper tray are in blue) are kept clean to avoid marks on copies firm against the paper.
  • Page 23 Essential Things to Remember Universal V 1.0 SWITCHING PAPER ON / OFF The Riso HC5500 should only be switched on or off When reloading always use complete reams of using the illuminated button found on the main fresh paper. panel of the machine.
