3.3.2 Description of each icon

Display
Function
RSSI Signal Strength Indicator
No signal
Rx Diversity available.
EVDO mode available
Battery Indicator
Battery Fully charged
Low Battery or Battery nil
USB connected
Charging USB
External Power
Connected to the Modem
Either the cable is disconnected to the modem
or improper port connection.
Internet connected
Internet disconnected
Connect to the Internet button.
Disconnecting from the Internet
Setup Zapp Online Express
Voice call menu (Not available with Z020 modem)
SMS menu (only received messages option)
