Enlarged version
Manual de Instrucciones
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en le-
siones graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2002 Electrolux Home Products, Inc.
Instruction Manual
Manuel d'Instructions
S31SNG
530163733
11/11/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Snapper S31SNG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snapper Snapper S31SNG

Summary of Contents for Snapper Snapper S31SNG

  • Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907 Copyright E2002 Electrolux Home Products, Inc. 530163733 11/11/02...

  • Page 2: Safety Rules

    UL CLASSIFIED PRODUCT NOTICE Only the following Gasoline Powered Combination Gardening Appliance powerhead models and their respective attachments have been Classified by Underwriters Laboratories, Inc., in accordance with the applicable safety requirements. Powerhead including trimmer attachment ......S31SNG Optional blower attachment .
  • Page 3 normal swellings. Prolonged use in cold UNIT / MAINTENANCE SAFETY weather has been linked to blood vessel dam- S Disconnect the spark plug before perform- age in otherwise healthy people. If symptoms ing maintenance except carburetor adjust- occur such as numbness, pain, loss of ments.
  • Page 4 S Never place any object in air intake opening EDGER SAFETY as this could restrict proper air flow and cause damage to the unit. WARNING: Inspect the area to be S Never use for spreading chemicals, fertiliz- edged before each use. Remove objects ers, or other substances which may contain (rocks, broken glass, nails, wire, etc.) which toxic materials.
  • Page 5 terial when the blade is in motion. Make sure WARNING: Only use brushcutter at- the switch is in the OFF position, the spark tachments that provide a metal shield with plug wire is disconnected, and the blade has proboscis nose. stopped moving before removing jammed material from the cutting blade.
  • Page 6 WARNING: Never lean over dis- charge chute. Rocks or debris could be thrown into the eyes and face and cause seri- ous injury or blindness. WARNING: Inspect the area where the unit is to be used. Remove objects that could be thrown or damage the unit. Some WARNING: To prevent serious inju- objects may be hidden by fallen snow -- be...

  • Page 7: Adjusting The Handle

    ASSEMBLY WARNING: WARNING: If received assembled, Make sure the locking/ repeat all steps to ensure your unit is properly release button is locked in the primary hole assembled and all fasteners are secure. and the knob is securely tightened before op- erating the unit.

  • Page 8: Operation

    OPERATION KNOW YOUR TRIMMER READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR UNIT. Compare the illustrations with your unit to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. Assist Handle Coupler Tube Trimmer...

  • Page 9: Starting A Cold Engine

    Choke ON/OFF Switch position decal HOW TO START YOUR UNIT 8. Pull starter rope sharply until engine runs, but no more than 6 pulls. If the engine WARNING: The trimmer head will doesn’t start after 6 pulls (at the HALF turn while starting the engine.
  • Page 10 If the unit still doesn’t start, refer to Coupler Primary Hole TROUBLESHOOTING TABLE call Guide Recess 1-800-554-6723. OPERATING THE COUPLER This model is equipped with a coupler which enables optional attachments to be installed. The optional attachments are: Locking/ Attachment Upper MODEL: Release...

  • Page 11: Cutting Methods

    Always tap the trimmer head on a grassy make contact. Do not force trimmer line into area. Tapping on surfaces such as concrete work area. or asphalt can cause excessive wear to the Trimming trimmer head. If the line is worn down to 2 in. (5 cm) or less, more than one tap will be required to obtain the most efficient line length.

  • Page 12: Service And Adjustments

    INSPECT AND CLEAN UNIT AND LA- Air Filter Button BELS S After each use, inspect complete unit for loose or damaged parts. Clean the unit and labels using a damp cloth with a mild deter- Air Filter gent. Cover S Wipe off unit with a clean dry cloth. CLEAN AIR FILTER A dirty air filter decreases engine perform- REPLACE SPARK PLUG...

  • Page 13: Seasonal Storage

    S Turn idle speed screw counterclockwise to decrease engine speed if trimmer head or any optional attachment moves or spins at idle. Air Filter Cover WARNING: Recheck the idle speed after each adjustment. The trimmer head or any optional attachment must not move or spin at idle speed to avoid serious injury to the Idle Speed operator or others.

  • Page 14: Troubleshooting Table

    TROUBLESHOOTING TABLE WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE REMEDY Engine will not 1. Move ON/OFF switch to ON. 1. ON/OFF switch in start.

  • Page 15: Limited Warranty

    This warranty is not transferable and does not APPLY TO YOU. cover damage or liability caused by improper The policy of ELECTROLUX HOME PROD- handling, improper maintenance, or the use UCTS, INC., is to continuously improve its of accessories and/or attachments not spe- products.
  • Page 16 2 years. Any warranted part which RANTY SERVICE: Warranty services or re- is scheduled for replacement as required pairs shall be provided at all ELECTROLUX maintenance shall be warranted for the period HOME PRODUCTS, INC., service centers. of time up to the first scheduled replacement Call 1--800--554--6723.
