ViewSonic ViewPanel VE170 User Manual
Viewpanel full 17.0" diagonal viewable screen
Hide thumbs
Also See for ViewPanel VE170:
- Service manual (35 pages) ,
- User manual (23 pages) ,
- Specifications (2 pages)
Related Manuals for ViewSonic ViewPanel VE170
Summary of Contents for ViewSonic ViewPanel VE170
- Page 1 ® VE170/ ViewPanel VE170b User Guide Guide de l’utilisateur Bedienungsanleitung Manual de Instrucciones Guida per l'utente Guia do usuário Användarhandbok Руководство пользователя Polski Full 17.0" Diagonal Viewable Screen...
-
Page 2: For Your Records
__________________ Product disposal at end of product life ViewSonic is concerned about the preservation of our enviornment. Please dispose of this product propersly at the end of its useful life. Your loacal waste disposal company may provide information about proper disposal. -
Page 3: Table Of Contents
CE Conformity ......... 20 *To meet your future needs, and to receive any additional product information as it becomes available, please register your monitor's warranty on the Internet at: http://www.viewsonic.com. ViewSonic VE170/VE170b... -
Page 4: Getting Started
Getting Started Congratulations on your purchase of a ViewSonic VE170/VE170b color ® ViewPanel Save the original box and all packing material for future shipping needs. ® NOTE: The word "Windows " in this user guide refers to the following ®... -
Page 5: Before Using The Viewpanel
ViewPanel off and call your dealer The ViewPanel should be facing away or ViewSonic. It is dangerous to from direct sunlight to reduce glare. continue using the ViewPanel. •... -
Page 6: Quick Installation
1 Connect video cable (INF and ICM files) ® Make sure that both the ViewPanel (1) Insert the ViewSonic Wizard CD- the computer are powered OFF. ROM into your computer's CD- Connect the video cable from the back ROM drive. -
Page 7: Using The Viewpanel
Setting the Timing Mode The timing mode consists of the resolution and refresh rate (vertical frequency). ® After setting the timing mode, use the ViewSonic OnView controls in this section ® to make adjustments. The recommended timing mode for this ViewPanel 1280 x 1024 @ 60Hz. -
Page 8: Adjusting The Screen Image
Shortcut: The [L] button goes directly to the BRIGHTNESS control screen, then button [2] toggles to the CONTRAST control screen. Button [2] Use this to select a control you wish to adjust. Power on/off ® ViewSonic VE170/VE170b Using the ViewPanel... - Page 9 Then, press the [2] button to go to the control Submenu (sample) screen. Press [M] or [L] to make adjustments. After making adjustments, press the [1] button to save changes and exit the screen. ® Using the ViewPanel ViewSonic VE170/VE170b...
-
Page 10: Main Menu
CONTRAST adjusts the difference between the image background (black level) and the foreground (white level). [M] decreases contrast, [L] increases contrast. BRIGHTNESS adjusts background black level of the screen image. [M] decreases brightness, [L] increases brightness. ® ViewSonic VE170/VE170b Using the ViewPanel... - Page 11 Phase minimizes the video distortion. Press[M] or [L] to adjust to your preference. Zoom expands and contracts the entire screen image. [M] Expands the screen image. [L] Contracts the screen image..continued ® Using the ViewPanel ViewSonic VE170/VE170b...
- Page 12 [2] to it. To adjust a highlighted color, press [M] or [L]. The number next to the status bar changes accordingly. To save your adjustment and exit a color, press button [1]. ® ViewSonic VE170/VE170b Using the ViewPanel...
-
Page 13: Advanced Menu
NOTE: See the Preset Timing Modes chart on page 6. Example: ® VESA 1280 x 1024 @ 60Hz (recommended) means that the resolution is 1280 x 1024 and the refresh rate is 60 Hertz. ® Using the ViewPanel ViewSonic VE170/VE170b... -
Page 14: Setup Menu
The controls affected by MEMORY RECALL are: CONTRAST, BRIGHTNESS, H (Horizontal) POSITION, V (Vertical) POSITION, H (Horizontal) SIZE, PHASE, ZOOM, OSD TIME OUT, and OSD POSITION. NOTE: MEMORY RECALL does not affect changes made with the USER COLOR control. ® ViewSonic VE170/VE170b Using the ViewPanel... -
Page 15: Other Information
® , DOC-B, CB, NERGY CE, TUV/ERGO (covers ISO 13406-2 & MPRII), TCO '99 for VE170, TCO '95 for VE170b, E2000, TUV/GS, VCCI, BSMI, NEMKO, SEMKO, DEMKO, FIMKO, B-Mark, NOM, PCT + HYGENIC, IRAM, S-Mark, C-Tick, CCIB, CCEE Power saving... -
Page 16: Troubleshooting
Make sure video input signals are within the ViewPanel's specified frequency range. • Try the ViewPanel with another power source, graphics card, or computer system. • Connect the video cable securely. Control buttons do not work • Press only one button at a time. ViewSonic VE170/VE170b Other Information... -
Page 17: Customer Support
F: 65 273 1566 viewsonic.com Asia Other Asia/Pacific viewsonic.com.tw T: 886 2 2246 3456 service.ap@ countries F: 886 2 8242 3668 viewsonic.com South Africa viewsonic.com/asia T: 886 2 2246 3456 service.ap@ F: 886 2 8242 3668 viewsonic.com Other Information ViewSonic VE170/VE170b... -
Page 18: Cleaning The Viewpanel
ViewPanel screen or case. Chemical cleaners have been reported to damage the screen and/or case of the ViewPanel. Further, ViewSonic does not recommend applying pressure when wiping the ViewPanel screen clean. ViewSonic will not be liable for damage resulting from use of liquid cleaners or resulting from applying pressure to the screen. -
Page 19: Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components. -
Page 20: Appendix
If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you have purchased your ViewPanel. Table A Cord Type Size of Conductors In Cord Maximum Current Rating of Unit 18AWG 10Amps 16AWG 12Amps 14AWG 12Amps 18AWG 10Amps 17AWG 12Amps ViewSonic VE170/VE170b Appendix... -
Page 21: Fcc Information
CE Conformity The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility”, and 73/23/EEC as amended by 93/68/EEC Art. 13 with regard to “Safety”. Appendix ViewSonic VE170/VE170b... - Page 22 ® ViewSonic Corporation...
