- Page 1 Philips multimedia projector bSure 1 / bSure 2 User guide English...
-
Page 2: Table Of Contents
PC/Macintosh 13 Connection to an external monitor 14 Connecting to video equipment 15-17 CVBS 15 S-VHS 15 Scart connection 15 Component/HDTV (Pr,Y, Pb/ Cr,Y, Cb) 16 Scart connection (RGBS) 17 English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 3: Index
6. Maintenance 28-30 Cleaning 28 Cleaning the cabinet 28 Cleaning the lens 28 Cleaning the dust filter 28 Lamp 29 Lamp replacement 29-30 Resetting the lamplife time 30 7.Troubleshooting 31-34 English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 4: Introduction
(not for USA version) Audio/Video RCA Cable Quick set up Card and Cd-rom (with Projection Safety Sheet Assistant, Warranty card, SecurityMax, User Guide, Data sheet and more.) Softbag (supplied with bSure2 Brilliance only) English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 5: Optional Accessories
1. Introduction < Optional accessories The following accessories are available via he dealer from which you purchased your Philips projector: • LCA 3116/00 - 132 W replacement lamp - 8670 931 16009 • LCA 3118/00 - 150 W replacement lamp - 8670 931 18009 •... -
Page 6: Functional Overview
OSD menu.The cursor control works with up/down and left/right button operation. Focus ring ! To adjust the focus of the projected image. Zoomring @ To adjust the size of the projected image. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 7: Controls
To adjust the vertical angle of the projector. Dust filter $ Mains inlet socket % To connect the projector to the mains. Lock slit ^ To insert an optional locking device (Kensington lock). Lamp compartment & English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 8: Remote Control
To activate the laser pointer to indicate items on the screen. Note: The laser pointer sends out a laser beam. Do not look into this beam! Laser pointer # Exit point of laser pointer. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 9: Connections
Input socket to connect to the S-Video out socket of a S-VHS video recorder, a VCR, Laser Disc player, DVD player, video camera or TV with AV output socket. This socket can be connected to a S-Video/S-VHS (Y/C) output socket. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 10: Set Up
Power/ Standby (Auto Standby). This setting can be changed in the ‘Settings’ menu Before disconnecting the mains lead, make sure that the cooling fan has stopped (about 3 minutes after the projector has been switched to Power/Standby). English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 11: Adjusting The Focus And Size Of The Image
Install two ‘AAA’ batteries as indicated inside the battery compartment. Replace the lid and snap it into place. Note The maximum range of the remote control is approximately 15 m (± 50 feet). English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 12: Installation
‘Picture format’ feature you can select one of five picture format options 4:3, 16:9, 16:9 enlarged, 4:3 on a 16:9 screen or 16:9 on a 4:3 screen. CAUTION Always switch off projector and external equipment before making any connections. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 13: Connecting To A Computer
Audio R For external monitor connection only COMPUTER COMPUTER Mac/PC Philips VGA/MAC adapter Data out Audio out PS/2 PC/Macintosh Connect the Data (out) socket of the computer to the Computer (in) socket of the projector and secure the plugs by tightening the thumb screws. -
Page 14: Connection To An External Monitor
Key lock (more) Monitor out is to be activated if an extra monitor is connected to the projector. Otherwise it should be de-activated and no special Y-cable should be connected. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 15: Connecting To Video Equipment
Scart adapter (not for USA version) S-VHS Plug an optional S-Video connection cable into the VCR and the S-Video socket of the projector. S-Video Scart adapter (not for USA version) English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 16: Component/Hdtv (Pr,Y, Pb/ Cr,Y, Cb)
Audio (in) L/R sockets of the projector. For this, use an optional audio connection cable (2). – Audio information from the Component- or HDTV-video equipment will be played via the projector speaker. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 17: Scart Connection (Rgbs)
Audio (in) L/R sockets of the projector. For this, use an optional audio connection cable (4). – Audio information from the Component- or HDTV-video equipment will be played via the projector speaker. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 18: Operation
A/V Muted No signal A/V Muted Computer selected as source Video selected as source, S-Video selected as source, Component selected as no input signal A/V muted source A/V muted English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 19: On Screen Display Menu
4:3 on a 16:9 screen Blue 16:9 on a 4:3 screen Colour tracking vivid natural Colour temperature warm cool Move pointer left or right to adjust the Red level. Green Blue English User guide bSure1 / bSure 2 Philips Multimedia Projector... - Page 20 Off 15 30 45 60 120 Auto Source Feedback Settings Display Picture Audio (previous) Start-up screen Lamp counter Auto Standby Auto Source Feedback The Start-up screen can be shown or suppressed during start-up. English User guide bSure1 / bSure 2 Philips Multimedia Projector...
-
Page 21: General Explanation
Select the next item to be adjusted in the sub menu and adjust as described above. Press Menu to close the On Screen ‘Display’. Move pointer left or right to adjust the Red level. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 22: Computer Adjustments
The Horizontal size function is used to size a computer image to make it fit the projected picture. When the OSD menu is active and the horizontal size option is selected, the level will be indicated graphically on a linear scale (slider). English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 23: Shift
The various colours (red, green and blue) can also be adjusted individually. Picture format Colour tracking Colour temperature Green Blue Move pointer left or right to adjust the Red level. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 24: Video/S-Video Adjustments
Blue The various colours (red, green and blue) can also be adjusted individually. Move pointer left or right to adjust the Red level. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 25: General Adjustments
– Key lock To de-activate all remote and local controls.To disable the keylock function keep the OK button pressed for 10 seconds; – Start-up screen To display (On) or suppress (Off) the default Philips start-up screen upon the projector’s Settings Display Picture Audio start up. -
Page 26: Loading Your Own Personal Start-Up Screen
When the image is loaded ‘Capture complete’ and ‘Please reset projector’ appear on the screen. You will now have to reset the projector. For this see ‘Resetting the projector’ hereafter. Capture complete. Please reset projector. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 27: Resetting The Projector
Note Your personal start-up screen will appear each time the projector is switched on exept when the SecurityMax™ application has been activated.The SecurityMax™ start-up screen will then appear. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 28: Maintenance
When the filter is damaged replace it with a filter of the same type (12 nc: 3122 434 0157 0). The projector power cannot be switched on again unless the filter holder is installed correctly. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 29: Lamp
When tab A is pressed the mains inlet socket will be partly closed. The lamp door therefore cannot be removed if the mains lead is not disconnected from the projector. Read the caution and warning labels on the lamp holder. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 30: Resetting The Lamplife Time
To reset keep OK key pressed for 3 seconds. Press OK for 3 seconds to reset the lamp counter. If required, select another item you wish to adjust or press Menu to exit. English User guide bSure1 / bSure 2 Philips Multimedia Projector... -
Page 31: Troubleshooting
– Keystoning is applied on a high resolution component signal. • Decrease keystoning until the image is correctly displayed. For this use the ‘Keystone correction’ option in the ‘Settings’ menu. English User guide bSure1 / bSure 2 Philips Multimedia Projector... - Page 32 • Reduce distance. the remote control – Batteries are exhausted. • Replace batteries (see ‘Inserting the batteries in the remote control’). – IR sensor is obstructed. • Remove obstacle. English User guide bSure1 / bSure 2 Philips Multimedia Projector...
-
