SERVICE MANUAL
COMPACT DISC
STEREO SYSTEM
SYSTEM
NSX-AJ22
• This Service Manual is the "Supplement" and replaces "Simple Manual"
(S/M Code No. 09-007-423-4T5).
• This Service Manual contains information about the difference between
NSX-AJ22 (U) and NSX-AJ20 (U). If requiring the other information, see
Service Manual of NSX-AJ20/SZ20 (U,LH),
(S/M Code No.09-001-423-4R1).
• If requiring information about the CD mechanism, see Service Manual
of AZG-1, (S/M Code No. 09-001-335-3N8).
NSX-AJ22
BASIC TAPE MECHANISM : ZZM-3 PR1NM
BASIC CD MECHANISM : AZG-1 ZD3RDM
CD
SPEAKER
CASSEIVER
CX-NAJ22
SX-NAJ33
S/M Code No. 09-008-423-4S1
REMOTE
CONTROLLER
SX-R140
RC-ZAS02
U
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aiwa NSX-AJ22
Summary of Contents for Aiwa NSX-AJ22
- Page 1 • This Service Manual is the “Supplement” and replaces “Simple Manual” (S/M Code No. 09-007-423-4T5). • This Service Manual contains information about the difference between NSX-AJ22 (U) and NSX-AJ20 (U). If requiring the other information, see Service Manual of NSX-AJ20/SZ20 (U,LH), (S/M Code No.09-001-423-4R1).
-
Page 2: Specifications
SPECIFICATIONS <FM tuner section> <General> Tuning range 87.5 MHz to 108 MHz Power requirements 120 V AC, 60 Hz Usable sensitivity (IHF) 13.2 dBf Power consumption 85 W Antenna terminals 75 ohms (unbalanced) Power consumption in standby mode 15 W with power-economizing <AM tuner section>... -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-010-247-080 CAP, ELECT 100-50V 87-010-380-080 CAP, ELECT 47-16 M 87-A21-355-010 IC,STK490-140 87-010-381-080 CAP, ELECT 330-16V 87-A21-419-040 C-IC,NJM14558MD-TE2 87-010-197-080 CAP, CHIP 0.01-25 K B 87-A21-401-040 C-IC,M61503FP 87-010-403-080 CAP, ELECT 3.3-50V... - Page 4 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C456 87-010-197-080 CAP, CHIP 0.01-25 K B C961 87-010-152-080 C-CAP,S 8P-50 CH C460 87-010-196-080 CHIP CAPACITOR,0.1-25 C963 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z C461 87-012-158-080 C-CAP,S 390P-50 CH C971 87-010-381-080 CAP, ELECT 330-16V C462 87-012-158-080...
-
Page 5: Transistor Illustration
REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C155 87-010-404-040 CAP,E 4.7-50 SME S343 87-A90-164-080 SW,TACT SKQAB(N) C156 87-010-404-040 CAP,E 4.7-50 SME S344 87-A90-164-080 SW,TACT SKQAB(N) C361 87-010-178-080 CHIP CAP 1000P-50 K B S345 87-A90-164-080 SW,TACT SKQAB(N) C362 87-010-178-080 CHIP CAP 1000P-50 K B... -
Page 6: Wiring - 1 (Main)
WIRING – 1 (MAIN) – 6 –... - Page 7 SCHEMATIC DIAGRAM – 1 (MAIN 1 / 2 : AMP) – 7 –...
- Page 8 SCHEMATIC DIAGRAM – 2 (MAIN 2 / 2 : TUNER) – 8 –...
-
Page 9: Wiring - 2 (Front)
WIRING – 2 (FRONT) – 9 –... -
Page 10: Schematic Diagram - 3 (Front)
SCHEMATIC DIAGRAM – 3 (FRONT) – 10 –... - Page 11 WIRING – 3 (PT) – 11 –...
-
Page 12: Schematic Diagram - 4 (Pt)
SCHEMATIC DIAGRAM – 4 (PT) – 12 –... -
Page 13: Ic Block Diagram
IC BLOCK DIAGRAM – 13 –... -
Page 14: Mechanical Parts List
MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION 8A-NF9-211-010 HLDR,PWB PT HI 8A-NF9-074-010 WINDOW,DISP U J22 8A-NF9-010-110 KEY,ASSY OPE 1 WAY 8A-NF9-020-110 KEY,CD 8A-NF9-026-110 KEY,ENTER 86-NF6-211-010 HLDR,IC T1.6 8A-NF9-619-010 PT,ANF-9 U HI 8A-NF9-073-010 CABI,REAR USM J22 COLOR NAME TABLE Basic color symbol Color... -
Page 15: Tape Mechanism Exploded View
TAPE MECHANISM EXPLODED VIEW 1 / 1 TERMINAL, TERMINAL,LB1 IC, EW732 IC, EW732 P.C.B – 15 –... -
Page 16: Tape Mechanism Parts List
TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 8Z-ZM3-227-010 BELT,MAIN M3 8Z-ZM3-233-010 SPR-T,BRG M3 8Z-ZM3-235-010 BELT,MAIN L 84-ZM2-227-310 SPR-C,AZIMUTH 8Z-ZM1-235-010 PULLEY,MOT 87-A90-403-110 HEAD,RPH MS15R 87-045-347-010 MOT,SHU2L 70 87-A90-404-010 HEAD,EH LE15B 8Z-ZM1-232-010 GEAR,IDL FF/REW 8Z-ZM3-239-010... -
Page 17: Accessories / Package List
SPEAKER PARTS LIST SX-NAJ33 (YUSL) REF. NO. PART NO. KANRI DESCRIPTION 1 8A-NSK-001-010 PANEL,FR 2 8A-NSK-003-010 GRILLE,FRAME ASSY 3 8A-NSK-007-010 PROTECTOR,TWA 4 87-NSH-612-010 SPKR,CERAMIC ASSY 5 87-NS7-611-010 CORD,SPKR 6 8A-NSJ-602-010 SPKR,W 130 7 8A-NSK-604-010 SPKR,TW 60 SPEAKER PARTS LIST SX-R140 (YUSC) REF. - Page 18 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9820543 0251431 Printed in Singapore...
