Aiwa NSX-AJ17 Service Manual
Compact disc stereo
cassette receiver
Hide thumbs
Also See for NSX-AJ17:
- Operating instructions manual (20 pages) ,
- Service manual (42 pages) ,
- Service manual (42 pages)
Advertisement
SERVICE MANUAL
COMPACT DISC STEREO
CASSETTE RECEIVER
SYSTEM
CASSEIVER
NSX-AJ17
CX-NAJ17
NSX-BL14
CX-NBL14
• This Service Manual is the "Revision Publishing" and replaces "Simple
Manual" NSX-AJ17(U)/BL14(LH), (S/M Code No. 09-001-428-8T1).
• If requiring information about the CD mechanism, see Service Manual
of AZG-1, (S/M Code No. 09-001-335-3NC).
CD
CD
MECHANISM
AZG-1 ZA3RDM
AZG-1 ZA3RNDM
S/M Code No. 09-003-428-8R1
NSX-AJ17
NSX-BL14
BASIC TAPE MECHANISM : ZZM-2 PR1NM
BASIC CD MECHANISM : AZG-1 ZA3RDM,
SPEAKER
SX-NAJ17
SX-NBL17
U
LH
AZG-1 ZA3RNDM
REMOTE
CONTROLLER
RC-ZAS02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aiwa NSX-AJ17
Summary of Contents for Aiwa NSX-AJ17
- Page 1 CX-NBL14 AZG-1 ZA3RNDM • This Service Manual is the “Revision Publishing” and replaces “Simple Manual” NSX-AJ17(U)/BL14(LH), (S/M Code No. 09-001-428-8T1). • If requiring information about the CD mechanism, see Service Manual of AZG-1, (S/M Code No. 09-001-335-3NC). S/M Code No. 09-003-428-8R1...
-
Page 2: Specifications
SPECIFICATIONS <FM tuner section> <Speaker system>SX-NAJ17<U> Tuning range 87.5 MHz to 108 MHz Speaker System 2 way, bass reflex (magnetic Usable sensitivity (IHF) 13.2 dBf shielded type) Antenna terminals 75 ohms (unbalanced) Speaker units Woofer: 120 mm (4 in.) cone type <AM tuner section>... -
Page 3: Protection Of Eyes From Laser Beam During Servicing
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING CAUTION This set employs laser. Therefore, be sure to follow carefully Use of controls or adjustments or performance of proce- the instructions below when servicing. dures other than those specified herein may result in hazardous radiation exposure. -
Page 4: Note On Before Starting Repair
NOTE ON BEFORE STARTING REPAIR 1. Forced discharge of electrolytic capacitor of power supply block When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across the electrolytic capacitors (C101, 102) even though AC power cord is removed. - Page 5 In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not. 2-2. Regarding reset There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power cord is re-inserted, or the software reset (pressing the STOP key + POWER key) is performed.
-
Page 6: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-010-381-080 CAP, ELECT 330-16V 87-A11-567-080 C-CAP,S 0.01-50 K B 8A-NFA-615-010 C-IC,M38B57MCH-E236FP 87-010-403-080 CAP, ELECT 3.3-50V 87-A21-397-010 IC,STK490-070 87-010-196-080 CHIP CAPACITOR,0.1-25 87-A21-629-010 IC,SPS-442-1-N C100 87-018-127-080 CAP TC-U 470P 87-A21-419-040 C-IC,NJM14558MD-TE2... - Page 7 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C605 87-010-179-080 CAP,CHIP S B1200P C987 87-010-197-080 CAP, CHIP 0.01 DM C606 87-010-179-080 CAP,CHIP S B1200P C993 87-010-178-080 CHIP CAP 1000P C609 87-010-213-080 C-CAP,S 0.015-50 B C995 87-010-178-080 CHIP CAP 1000P C610 87-010-213-080...
- Page 8 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION CN801 87-099-015-010 CONN,13P 6216V PT C.B FL201 8A-NFA-604-010 FL,10-BT-224GNK L101 87-A50-050-010 COIL,CLK 4.19M(COI) 87-010-387-080 CAP,E 470-25 SME<LH> LED101 87-A40-317-080 LED,SLR-342VCT31 RED 87-010-403-080 CAP, ELECT 3.3-50V<LH> S101 87-A91-555-010 SW,RTRY EC12E24504 C184 87-010-403-080 CAP, ELECT 3.3-50V<U>...
-
Page 9: Transistor Illustration
TRANSISTOR ILLUSTRATION S D G E C B E C B B C E 2SB1370 2SJ460 CSA952 DTC114ES 2SK2541 CSC4115 KTA1266 KTC3198 KTC3199 B C E KRA102 2SC3331 2SA1235 2SC2714 KRA107 2SC3052 KRC102 KRC104 CMBT5401 CMBT5551 – 9 –... - Page 10 FL (10-BT-224GNK) GRID ASSIGNMENT & ANODE CONNECTION GRID ASSIGNMENT – 10 –...
- Page 11 ANODE CONNECTION – 11 –...
- Page 12 WIRING - 1 (MAIN) -12-...
