Insignia NS-B4111 Quick Installation Manual

Read these instructions carefully before using this product, and retain
them in a safe place for reference.
Features
Top
1 Handle 5 Function (RADIO/CD/AUX)
2 CD door 6 Power (ON/OFF)
3 Volume control 7 Tuning control
4 FM antenna 8 CD door open (push tab)
Back
+ - +
1.5V x 8 UM 2 or
-
"C" size or LR14 +
- +
+
- +
1 AUX IN jack
2 Battery compartment
3 AC input
NS-B4111_09-0103_QSG_V2_EN.indd 1 NS-B4111_09-0103_QSG_V2_EN.indd 1
Front
1 Speaker
2 CD play/pause button
3 CD stop button
4 CD skip next button
5 CD track display
6 CD skip previous button
7 AM/FM button
Setting up your CD player
Connecting AC power
1 Connect the provided AC power cord to the AC input socket on
the CD player.
2 Plug the cord into a household AC power socket.
Installing batteries
1 Insert eight C alkaline batteries (not included) into the battery
compartment as indicated by the diagram within the
-
compartment.
-
+
-
2 Securely close the battery compartment cover.
- +
Notes: Battery power is used only when AC power is disconnected.
Replace all batteries at the same time with the same battery type.
Do not mix battery types.
When CD player is stored unused for a long time, remove the
batteries to prevent damage.
Setting the clock
1 Turn off your CD player, then press
TIME SET. The hour digits fl ash. Set
time under Standby mode.
2 Press
then press TIME SET. The minute
digits fl ash.
3 Press
then press TIME SET. The clock is set.
4 To view the clock, turn on your CD
player, then press DISPLAY.
NOTE: While the boombox is in standby mode running on battery
power, your batteries will continue to slowly drain, although
8 Speaker
the clock's time will be saved. To prevent battery drain, turn the
9 Time set button
boombox completely off by sliding the power switch (although
10 Display button
your clock setting will be lost).
11 Repeat button
Using your CD player
12 Random button
Warning: Use of any controls, adjustments, or procedures other
13 Standby button
than those specifi ed herein may result in hazardous radiation
exposure.
Using the radio
1 Slide the FUNCTION selector to RADIO, then press AM/FM to
select AM or FM mode.
2 Turn the TUNING control until you locate the station you want.
If you tune to an FM station broadcasting in stereo, the stereo
indicator turns on. "ST" will appear in the upper-right of the LCD
screen when stereo is on.
• For optimum FM reception, make sure that the FM
(telescopic) antenna is fully extended and vertical.
• For optimum AM reception, rotate the CD player to orient its
built-in antenna until you get the strongest signal.
Using the CD player
The CD player can play standard audio CDs and audio CDs created
on a computer's CD-R/CD-RW drive.
1 Slide the FUNCTION selector to CD, then lift the CD door and
insert a CD with the label facing up. Make sure that the CD is
correctly mounted on the spindle and locked in place.
Quick Installation Guide
NS-B4111 CD Boombox
or to adjust the hour,
or to adjust the minute,
