NS-KP04_10-1285_MAN_V4_English.fm Page 1 Tuesday, December 28, 2010 9:36 AM
User Guide
DVD and CD+G Karaoke Player/Recorder
NS-KP04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-KP04 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Insignia NS-KP04

Summary of Contents for Insignia NS-KP04

  • Page 1 FINAL FOR PRINT NS-KP04_10-1285_MAN_V4_English.fm Page 1 Tuesday, December 28, 2010 9:36 AM User Guide DVD and CD+G Karaoke Player/Recorder NS-KP04...

  • Page 2: Table Of Contents

    NS-KP04_10-1285_MAN_V4_English.fm Page 2 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Contents Introduction............3 Important safety instructions .

  • Page 3: Introduction

    One-year limited warranty ......... .37 Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-KP04 represents the state of the art in karaoke player/recorder design, and is designed for reliable and trouble-free performance. Important safety instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 4 NS-KP04_10-1285_MAN_V4_English.fm Page 4 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert you to the presence of uninsulated dangerous voltage within your player’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 5 NS-KP04_10-1285_MAN_V4_English.fm Page 5 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder 9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.

  • Page 6: Features

    NS-KP04_10-1285_MAN_V4_English.fm Page 6 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Features Package contents • DVD and CD+G Karaoke Player/Recorder • Remote control • AAA batteries (2) • Microphone • AC/DC power adapter • AV cable (RCA type) •...

  • Page 7: Front

    NS-KP04_10-1285_MAN_V4_English.fm Page 7 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Front DV D/L INE IN DV D/USB /SD MIC VO LUM E MA STE R V OL UM E MA X MA X RE MO TE...
  • Page 8 NS-KP04_10-1285_MAN_V4_English.fm Page 8 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Item REMOTE SENSOR LINE IN jack USB port SD card slot ECHO BALANCE www.insigniaproducts.com Description Receives signals from the remote control. Do not block.

  • Page 9: Back

    NS-KP04_10-1285_MAN_V4_English.fm Page 9 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Back Jack AUDIO OUT L/R VIDEO OUT COAXIAL S-VIDEO MIC1/MIC2 DC IN www.insigniaproducts.com MIC1 MIC2 DC IN 12V VIDEO OUT COAXI AL S-VID EO...

  • Page 10: Remote Control

    NS-KP04_10-1285_MAN_V4_English.fm Page 10 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Remote control Jack RECORD Number buttons WIDE www.insigniaproducts.com RECORD DVD/LINE IN DVD/USB/SD PROG MUTE WIDE ANGLE TOP MENU SUBTITLE SETUP MENU ENTER ZOOM AUDIO...
  • Page 11 NS-KP04_10-1285_MAN_V4_English.fm Page 11 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Jack ANGLE SETUP ENTER ZOOM PLAY/PAUSE SLOW GOTO KEY– REPEAT DVD/LINE IN DVD/USB/SD PROG MUTE SUBTITLE www.insigniaproducts.com Description During DVD playback, press to change the viewing angle if multiple angles are available.
  • Page 12 NS-KP04_10-1285_MAN_V4_English.fm Page 12 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Jack TOP MENU MENU AUDIO STEP STOP PREV NEXT FLAT KEY+ www.insigniaproducts.com Description During DVD playback, press to open the title menu and select a title and chapter.

  • Page 13: Setting Up Your Karaoke System

    NS-KP04_10-1285_MAN_V4_English.fm Page 13 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Setting up your karaoke system Connecting the power cord To connect the power cord: • Plug the small connector on the AC/DC power adapter into the DC IN jack on the back of your karaoke system, then plug the other connector into a power outlet.

  • Page 14: Playing The Audio Through An Analog Sound System

    NS-KP04_10-1285_MAN_V4_English.fm Page 14 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Playing the audio through an analog sound system You can connect the included analog sound system. When you connect a sound system, the audio from your karaoke system plays through the sound system.

  • Page 15: Turning The Screen On Or Off

    NS-KP04_10-1285_MAN_V4_English.fm Page 15 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Turning the screen on or off To turn the screen on or off: • Press SCREEN ON/OFF on the front of your karaoke system.

  • Page 16: Selecting The Equalizer Mode

    NS-KP04_10-1285_MAN_V4_English.fm Page 16 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Selecting the equalizer mode To select the equalizer mode: • Press EQ repeatedly. You can select Standard, Classic, Rock, Jazz or POP. Adjusting the echo effect To adjust the echo effect: •...

  • Page 17: Selecting The Audio Output Mode For The Internal Speakers

    NS-KP04_10-1285_MAN_V4_English.fm Page 17 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Selecting the audio output mode for the internal speakers Note To select the audio output mode for a connected sound system, see “Selecting the audio output mode for a connected sound system”...

  • Page 18: Selecting The Audio Output Mode For A Connected Sound System18

    NS-KP04_10-1285_MAN_V4_English.fm Page 18 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Selecting the audio output mode for a connected sound system To select the audio output mode for a connected sound system: 1 Press SETUP. The on-screen menu opens.

  • Page 19: Playing From A Usb Flash Drive

    NS-KP04_10-1285_MAN_V4_English.fm Page 19 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder 4 Press PLAY/PAUSE Playing from a USB flash drive To play from a USB flash drive: 1 Insert a USB flash drive into the USB port on the front of your karaoke system.

  • Page 20: Displaying Playback Information

    NS-KP04_10-1285_MAN_V4_English.fm Page 20 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Displaying playback information Playback information includes: • Media type and track number of the file that is playing • Elapsed time • Speaker status (on or off ) •...

  • Page 21: Repeating A Chapter, Title, Or Track

    NS-KP04_10-1285_MAN_V4_English.fm Page 21 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Repeating a chapter, title, or track To repeat a chapter, title, or track: • During playback, press REPEAT. • For discs, you can select repeat chapter, repeat title, repeat all, or repeat off.

  • Page 22: Selecting A Dvd Title And Chapter With The Title Menu

    NS-KP04_10-1285_MAN_V4_English.fm Page 22 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder MP3/WMA/CD/JPEG 2 Use the arrow buttons and number buttons to enter title/folder number and chapter/track number of the chapter/track you want to play. 3 Repeat Step 2 to enter additional selections. A program can have as many as 16 selections.

  • Page 23: Adjusting Video Settings

    NS-KP04_10-1285_MAN_V4_English.fm Page 23 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Adjusting video settings To adjust video settings: 1 Press SETUP. The on-screen menu opens. 2 Press to highlight 3 Press to highlight an option, then press settings.

  • Page 24: Selecting The Aspect Ratio

    NS-KP04_10-1285_MAN_V4_English.fm Page 24 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Selecting the aspect ratio Note You can also press WIDE to select the aspect ratio. To select the aspect ratio: 1 Press SETUP. The on-screen menu opens.

  • Page 25: Viewing A Video Frame By Frame

    NS-KP04_10-1285_MAN_V4_English.fm Page 25 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Viewing a video frame by frame To view a video frame by frame: • During video playback, press STEP. Each time you press STEP, the video advances one frame.

  • Page 26: Selecting The On-Screen Menu Language

    NS-KP04_10-1285_MAN_V4_English.fm Page 26 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder 5 Press ENTER to confirm your selection. 6 Press to return to the previous screen, or press SETUP to close the menu. Selecting the on-screen menu language To select the on-screen menu language: 1 Press SETUP.

  • Page 27: Changing The Dvd Parental Control Password

    NS-KP04_10-1285_MAN_V4_English.fm Page 27 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Changing the DVD parental control password To change the DVD parental control password: 1 Press SETUP. The on-screen menu opens. 2 Press to highlight...

  • Page 28: Setting Dvd Parental Controls

    NS-KP04_10-1285_MAN_V4_English.fm Page 28 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Setting DVD parental controls To set DVD parental controls: 1 Press SETUP. The on-screen menu opens. 2 Press to highlight 3 Press to highlight PASSWORD, then press password setting.

  • Page 29: Selecting The Tv System For A Connected Tv

    NS-KP04_10-1285_MAN_V4_English.fm Page 29 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder 9 Press the number buttons to enter the password, then press ENTER. The parental locks are turned on. 10 Press to return to the previous screen, or press SETUP to close the menu.

  • Page 30: Resetting All Settings To The Factory Defaults

    NS-KP04_10-1285_MAN_V4_English.fm Page 30 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Resetting all settings to the factory defaults To reset all settings to the factory defaults: 1 Press SETUP. The on-screen menu opens. 2 Press...

  • Page 31: Viewing Jpegs

    NS-KP04_10-1285_MAN_V4_English.fm Page 31 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Viewing JPEGs To view JPEGs: 1 Insert a disc, USB flash drive, or SD memory card that contains JPEG files. 2 Press DVD/USB/SD. The media list opens.

  • Page 32: Troubleshooting

    NS-KP04_10-1285_MAN_V4_English.fm Page 32 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Troubleshooting Problem Power source No power No power when plugged in Remote control The remote control does not work No picture No sound The picture is not clear or jumpy www.insigniaproducts.com...

  • Page 33: Maintaining

    NS-KP04_10-1285_MAN_V4_English.fm Page 33 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Problem CD+G Karaoke The disc does not play No song lyrics appear on the TV screen Maintaining Storing discs • Do not store discs in a place that is exposed to direct sunlight or heat.

  • Page 34: Specifications

    NS-KP04_10-1285_MAN_V4_English.fm Page 34 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder Specifications Specifications are subject to change without notice. Measurements and weights may vary slightly. Audio CD/DVD player Compatible discs Microphone AC power Dimensions (H × W× D)

  • Page 35: Legal Notices

    NS-KP04_10-1285_MAN_V4_English.fm Page 35 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder CD+G Stands for “Compact Disc plus Graphics. ” A CD+G has a video track that displays the song lyrics in sync with the music. The lyrics usually change color as when they are to be sung.
  • Page 36 NS-KP04_10-1285_MAN_V4_English.fm Page 36 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder www.insigniaproducts.com...

  • Page 37: One-Year Limited Warranty

    Products and parts replaced under this warranty become the property of Insignia and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges.
  • Page 38 • Damage due to incorrect operation or maintenance • Connection to an incorrect voltage supply • Attempted repair by anyone other than a facility authorized by Insignia to service the Product • Products sold as is or with all faults •...
  • Page 39 NS-KP04_10-1285_MAN_V4_English.fm Page 39 Tuesday, December 28, 2010 9:36 AM Insignia NS-KP04 DVD and CD+G Karaoke Player/Recorder www.insigniaproducts.com...
  • Page 40 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2010 BBY Solutions, Inc. All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
