- Page 1 CRANE SCALE SAFETY PERIODIC MAINTENANCE MANUAL Safe Rigging, Loading and Operation Including Suggested Inspection and Maintenance Procedures MODEL SERIAL NUMBER Measurement Systems International w w w . m s i s c a l e s . c o m...
- Page 2 M S I C R A N E S C A L E M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L...
-
Page 3: Table Of Contents
It must be recognized that this is a manual of suggestions for the crane scale operator’s use. It is the responsibility of the owner to make personnel aware of all federal, state and local rules and codes and to make certain that operators are properly trained. -
Page 4: Safe Operating Guidelines
1. Do not make lifts beyond rated load capacity of the crane scale, sling chains, rope slings, etc. 2. Do not operate the crane scale if ropes, slings, cables, chains, etc. show any sign of defects or excessive wear. 3. Before moving the load, make certain that load slings, load chains or other lifting devices are fully seated in the saddle of the crane scale hook with hook latch closed. -
Page 5: Safe Loading And Rigging Guidelines
A falling load may cause serious injury or death. The crane scale hook must always support the load. The load must never be supported by the latch. Never lift more than the crane scale's assigned Working Load Limit rating. -
Page 6: Loading Procedure "Do's" & "Don'ts" - Illustrations
OFF-AXIS LOADING. DO NOT PUSH OR PULL A LOADED SCALE AND DO NOT PULL LATERALLY ON THE HOOK WITH SCALE LOADED. DO NOT SIDE LOAD, BACK LOAD OR TIP LOAD A CRANE SCALE HOOK. INCORRECT INCORRECT INCORRECT BACK LOAD TIP LOAD... - Page 7 M S I C R A N E S C A L E M S I C R A N E S C A L E Loading the Scale Hook with two sling legs. • USE BOTTOM SHACKLE WITH HOOK FOR TWO SLING LEG LOADING. •...
-
Page 8: Recommended Inspection Procedures
M S I C R A N E S C A L E Reversed Shackle Add Washers to Shackle Off Center Loading GOOD PRACTICE POOR PRACTICE WASHERS TO CENTER THE LOAD. Scale Hook with Latches Scale Hook with Latches CORRECT INCORRECT ALWAYS MAKE SURE THE HOOK THE LATCH MUST NEVER SUPPORT... -
Page 9: Load Train Visual Inspection Suggestions
• Magnetic Particle or Dye Penetrant crack detection of all components of the load train assembly should be conducted annually. If the crane scale hook, shackle or lifting eye are painted, visual inspection should take this coating into consideration. Surface variations can disclose evidence of heavy or severe use that requires more detailed analysis. -
Page 10: Shackle Field Inspection Areas
M S I C R A N E S C A L E Shackle Field Inspection Areas CHECK FOR WEAR CHECK CHECK FOR WEAR AND STRAIGHTNESS WEAR CHECK THAT PIN IS SEATED CHECK SHACKLE FOR OPENING Shackle with Excessive Wear Improper Replacement of Pins in Shackle •... -
Page 11: Overloaded Shackle
M S I C R A N E S C A L E M S I C R A N E S C A L E Overloaded Shackle BENT PIN AND ELONGATED BOW. Shackle Eye with Twist CHECK FOR EAR ALIGNMENT. -
Page 12: Scale Hook Inspection
M S I C R A N E S C A L E Scale Hook Inspection CHECK FOR SPREADING CHECK FOR CRACKS AND TWISTING CHECK FOR WEAR AND DEFORMATION CHECK FOR WEAR, CRACKS AND TWISTING Scale Hook with 10 Degree Maximum Twist •... -
Page 13: Field Inspection And Repair
• Never repair, alter, rework, or reshape any load bearing component by welding, heating, burning or bending. Recommended Preventive Maintenance Initial Inspection Prior to use, all crane scale hook and shackle or lifting eyes should be inspected Frequent and Periodic Inspection Inspection procedures and record keeping requirements for... - Page 14 Inspect scale hook, shackle and lifting eye with magnetic particle and/or dye penetrant annually, or more often in severe operating conditions. Annual inspection of load sensor by an authorized MSI Distributor is strongly recommended. WARNING! Loads imposed on this product should never exceed the maximum rated capacity shown and apply only to uniform direct tension loading.
-
Page 15: Notes
M S I C R A N E S C A L E M S I C R A N E S C A L E Notes M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L... - Page 16 Measurement Systems International Integrated System Solutions for Industrial Weighing and Process Control 14240 Interurban Avenue South STE 200 Seattle, Washington 98168-4661 U.S.A. 206 433-0199 Fax: 206 244-8470 • Web: www.msiscales.com Email: info@msiscales.com • © 2003 by Measurement Systems International, Inc. PUB.243-08-94D Printed in U.S.A.
