01GB01COV-AE4.book Page 1 Wednesday, July 11, 2001 12:12 PM
3-233-649-12(1)

Mobile Telephone

Operating Instructions
GB
The instructions in this manual are for the
two models CMD-J7, CMD-J70. The
CMD-J7 is the model used for illustration
purposes.
Otherwise, the model name is indicated in
the illustrations. Any differences in
operation are clearly indicated in the text,
for example "CMD-J7 only".
CMD-J7/J70
© 2001 Sony Corporation
CMD-J7

Advertisement

Table of Contents

   Related Manuals for Sony CMD-J7

   Summary of Contents for Sony CMD-J7

  • Page 1: Mobile Telephone

    Mobile Telephone Operating Instructions The instructions in this manual are for the two models CMD-J7, CMD-J70. The CMD-J7 is the model used for illustration purposes. Otherwise, the model name is indicated in the illustrations. Any differences in operation are clearly indicated in the text, for example “CMD-J7 only”.
  • Page 2 01GB01COV-AE4.book Page 2 Wednesday, July 11, 2001 12:12 PM My CMD-J7/J70 Explanation of the icons Information (Instruction purpose only.) For easy reference, please record the Icons Explanations following identification numbers for your phone and SIM Card. This information will Important...
  • Page 3: Safety Precautions

    01GB01COV-AE4.book Page 3 Wednesday, July 11, 2001 12:12 PM Safety Precautions • Do not use your phone in an aircraft, • Use only Sony-approved CMD-J7/J70 hospitals, petrol stations, or in places where batteries and accessories with your phone. • Do not touch the External Antenna mobile phones are prohibited.
  • Page 4 01GB01COV-AE4.book Page 4 Wednesday, July 11, 2001 12:12 PM Warning • Unauthorised batteries, chargers, and accessories will invalidate any approvals and warranty given for your phone and may be dangerous. • For use in the car, please connect your GSM mobile phone to an external antenna. The external antenna can be connected to your mobile phone via the appropriate accessory, e.g.
  • Page 5: Table Of Contents

    01GB01COV-AE4.book Page 5 Wednesday, July 11, 2001 12:12 PM Table of Contents Welcome to Sony CMD-J7/J70 ..7 Basic Operation ....17 What’s Included in Your Kit .
  • Page 6 01GB01COV-AE4.book Page 6 Wednesday, July 11, 2001 12:12 PM Menu Operations ....28 Messaging ......28 Sounds .
  • Page 7: Welcome To Sony Cmd-j7/j70

    01GB01COV-AE4.book Page 7 Wednesday, July 11, 2001 12:12 PM Welcome to Sony CMD-J7/J70 What’s Included in Your Attaching the Hand Strap Attach a hand strap to the phone as illustrated below. The kit should include one mobile phone, one standard battery, one charger and this manual.
  • Page 8: Quick Reference

    01GB01COV-AE4.book Page 8 Wednesday, July 11, 2001 12:12 PM Quick Reference Basic Features of Your Phone The Jog Dial The Jog Dial provides fast and easy menu navigation with only one hand. Function Operation Rotate Scrolls through menu options. Opens Phonebook in Standby Mode.
  • Page 9: The Centre Key

    01GB01COV-AE4.book Page 9 Wednesday, July 11, 2001 12:12 PM The Centre Key Manner Mode • Press the Centre Key in standby mode to • In standby mode, press and hold access the WAP mode if WAP settings are activate/deactivate the manner modes. configured.
  • Page 10: Keypad Lock

    01GB01COV-AE4.book Page 10 Wednesday, July 11, 2001 12:12 PM Keypad Lock Icon Glossary In standby mode, press the Centre Key Icon Explanation followed by to lock/unlock your keypad (including the Jog Dial). It is still possible to Network not available make emergency calls (112) as well as answer/reject an incoming call (by pressing Network signal strength (strong)
  • Page 11: Menu Overview

    01GB01COV-AE4.book Page 11 Wednesday, July 11, 2001 12:12 PM Menu Overview Icon Explanation Press the Jog Dial from standby mode to Incoming + Outgoing call barring access the main menu: Conditional Divert Unconditional Divert Messaging page 28 Active call Read Create Settings page 54...
  • Page 12: Getting Started

    01GB01COV-AE4.book Page 12 Wednesday, July 11, 2001 12:12 PM Getting Started Inserting the Battery To remove the Battery Pack First power off and wait until the display goes Pack blank. Remove the cover and pull the knob of 1 Unwrap the battery pack. the battery up to remove the battery.
  • Page 13: Charging The Battery Pack

    01GB01COV-AE4.book Page 13 Wednesday, July 11, 2001 12:12 PM 1 Remove the battery pack. Charging the Battery Pack 2 Slide the SIM card holder to the right to unlock and lift up the tray. Slide the SIM As supplied, your battery pack will not be card into the tray (the gold contacts fully charged.
  • Page 14 01GB01COV-AE4.book Page 14 Wednesday, July 11, 2001 12:12 PM Removing the charger from the phone: • Use only the Sony-specified CMD-J7/J70 battery pack and charger. • Disposal advice: Take special care in the disposal of the battery, using special facilities where available.
  • Page 15: Switching On Your Phone

    01GB01COV-AE4.book Page 15 Wednesday, July 11, 2001 12:12 PM Switching on Your Phone Connecting to the Network To switch on/off your phone, press and hold After successfully entering your PIN code, your phone searches for an available GSM Entering PIN (Personal network.
  • Page 16 01GB01COV-AE4.book Page 16 Wednesday, July 11, 2001 12:12 PM If you cannot obtain service • If you cannot obtain network service the reception strength may be too weak. Move to a higher elevation, a window or an open space and make sure that there is nothing obstructing the antenna.
  • Page 17: Basic Operation

    01GB01COV-AE4.book Page 17 Wednesday, July 11, 2001 12:12 PM Basic Operation Making Calls (Saving 4 Press the Jog Dial and select Save to save the number to the Phonebook. Phonebook Entries) If the Auto Redial option is on (see page 41) and the Dialling a Number number you have called is engaged, your phone automatically displays the Auto Redial option.
  • Page 18: Answering/ending Calls

    01GB01COV-AE4.book Page 18 Wednesday, July 11, 2001 12:12 PM Answering/Ending Calls When the Headset is connected to your phone, answer a call by pressing the Headset Press the Jog Dial (or ) to accept an button (beep). Press and hold the Headset incoming call.
  • Page 19: During A Call

    01GB01COV-AE4.book Page 19 Wednesday, July 11, 2001 12:12 PM During a call Call Hold Use Call Hold to manage two calls at the same Adjusting the Ringer/Speaker time. Volume • During an incoming call, rotate the Jog One active call Dial to adjust the ringer volume.
  • Page 20 01GB01COV-AE4.book Page 20 Wednesday, July 11, 2001 12:12 PM Send DTMF 2 } Swap to put the active call on hold and Choose this option for sending DTMF tones, connect the waiting call (in case of one e.g. when using Voicemail or other services. active call and one waiting call) Press and hold to clear the number and then...
  • Page 21: Entering Text

    01GB01COV-AE4.book Page 21 Wednesday, July 11, 2001 12:12 PM Entering Text You have the possibility to enter characters: Example: To enter “s” when creating a message: • Standard Text Entry using the keypad 1 Proceed as in Create (see page 30), then •...
  • Page 22: T9 Text Entry

    5 Press the Jog Dial to select a symbol. combination you typed. 6 Rotate the Jog Dial to select “Sony”. If For “Smart Punctuation”, just press where you your desired word is first on the list, just would add a fullstop, hyphen or apostrophe.
  • Page 23: Phonebook

    01GB01COV-AE4.book Page 23 Wednesday, July 11, 2001 12:12 PM Phonebook Phonebook Organisation Saving Phonebook Entries from Standby Mode Your Phonebook is organised in the following sections: See page 17 “Basic Operation – Making Calls • Phonebook Menu (Saving Phonebook Entries)” and page 24 “Creating Entries in the Phonebook”.
  • Page 24: Phonebook Menu

    01GB01COV-AE4.book Page 24 Wednesday, July 11, 2001 12:12 PM Phonebook Menu Call, Edit, Delete, Copy Own Number See page 26 “Editing the Phonebook”. Own Number Creating Entries The first entry in the Phonebook Menu is a place holder for your own numbers, where 1 } ‘...
  • Page 25 01GB01COV-AE4.book Page 25 Wednesday, July 11, 2001 12:12 PM FDN Phonebook • When saving the Phonebook entries to the SIM This section may contain Fixed Dialling card, the number of memory spaces depends on Numbers (SIM card dependant). To add an your SIM card.
  • Page 26: Voicemail

    01GB01COV-AE4.book Page 26 Wednesday, July 11, 2001 12:12 PM Voicemail Search } ‘ Phonebook } „ Search Press and hold for quick access to your It is possible to search By Name or By Group. Voicemail. Editing the Phonebook Set up your Voicemail Use this option for calling, editing, deleting or 1 } ‘...
  • Page 27 01GB01COV-AE4.book Page 27 Wednesday, July 11, 2001 12:12 PM • Name editing options: Editing Note The Note is like a memo pad for additional } View to see the complete name. information e.g. e-mail addresses or postal addresses in the Phonebook. } Edit Name to change the name.
  • Page 28: Menu Operations

    01GB01COV-AE4.book Page 28 Wednesday, July 11, 2001 12:12 PM Menu Operations option on option off 1 } “ Messaging } Read } Inbox (} Outbox to read sent messages.) 2 Scroll through the list of messages to Messaging select the message you want to read and press the Jog Dial to confirm.
  • Page 29 01GB01COV-AE4.book Page 29 Wednesday, July 11, 2001 12:12 PM To Delete a Message To Forward a Message Follow steps 1-3 in “Read Message” (see 1 Follow steps 1-3 in “Read Message” (see page 28) and select Forward. page 28) and select Delete. To Call Back the Sender of a 2 After selecting the message you want to Message or a Number in the...
  • Page 30 4 When creating your message, press the from step 4 above. Centre Key for the following options: • The picture image and sound message can only be sent and received among Sony mobile phones T9 On/Off supporting this feature. Change Language...
  • Page 31 01GB01COV-AE4.book Page 31 Wednesday, July 11, 2001 12:12 PM Settings Validity Period Specify how long messages are stored in the } “ Messaging } Settings service center by selecting: 1 Hour, 6 Hours, Settings allows you to customise outgoing 24 Hours, 1 Week, 4 Weeks. The default messages including the format, confirmation validity period is 1 Week.
  • Page 32 01GB01COV-AE4.book Page 32 Wednesday, July 11, 2001 12:12 PM Local Area Info } “ Messaging } Local Area Info Receive Cell broadcast messages or general messages like weather reports, traffic reports, etc. broadcast to a group of phones in a certain area.
  • Page 33: Sounds

    Assign a ringer sound to the different groups Choose Sounds to access any sound-related saved in your Phonebook. It is not possible to option in your CMD-J7/J70, for example assign a ringer melody to a single name/ ringer melodies, ringer volume, enable/ number.
  • Page 34 Event Sounds My Sounds Assign a sound to be heard at the following Select My Sounds to record own sounds using actions of your CMD-J7/J70: the phone's microphone. Choose the Receive SMS, Alarm, Scheduler Alarm, Power respective icons to Record ( ), Stop ( Up and Power Down.
  • Page 35: Settings

    01GB01COV-AE4.book Page 35 Wednesday, July 11, 2001 12:12 PM Settings Item Default Page Language SIM dependent Preferences } † Settings } Preferences Greeting Choose Preferences to personalise your phone according to your preferences, e.g. Wallpaper which language, backlight on/off, etc. Backlight When you receive your phone, it has the following default settings:...
  • Page 36 01GB01COV-AE4.book Page 36 Wednesday, July 11, 2001 12:12 PM Language Select Network } † Settings } Preferences } Language This feature gives you the option to select a Select the appropriate language. network automatically when you turn on your phone, or manually from a list of available •...
  • Page 37 01GB01COV-AE4.book Page 37 Wednesday, July 11, 2001 12:12 PM Factory Reset After entering the PIN code incorrectly three times, To perform a master reset of all of your your PIN is blocked. Enter the PUK (Personal phone's settings back to the factory settings Unblocking Key) to unblock your PIN.
  • Page 38 01GB01COV-AE4.book Page 38 Wednesday, July 11, 2001 12:12 PM Call Barring Barring PWD Some of the restrictions in the Security menu Limit calls made from your phone which can are controlled in the network e.g. Call be useful e.g. if you lend your phone to Barring.
  • Page 39 01GB01COV-AE4.book Page 39 Wednesday, July 11, 2001 12:12 PM Call Data • Charge Rate } † Settings } Call Data Select Charge Rate to set the currency and price per unit which will be used to Track or control how long you are on the calculate the call cost.
  • Page 40 01GB01COV-AE4.book Page 40 Wednesday, July 11, 2001 12:12 PM Call Settings To make a line selection in standby mode, } † Settings } Call Settings press and hold and use the Jog Dial to make your selection. 1 or 2 will appear so that Some of the following features may not be you know which line is active.
  • Page 41 01GB01COV-AE4.book Page 41 Wednesday, July 11, 2001 12:12 PM Any Key Answer Auto Answer Answer a call by pressing any key on the Automatic answer of an incoming call. Only keypad. works together with the Handsfree car kit Select Any Key Answer and use the Jog Dial accessory.
  • Page 42: Divert

    01GB01COV-AE4.book Page 42 Wednesday, July 11, 2001 12:12 PM Divert • In step 3, you also have the option to cancel or check status. Select Cancel to cancel the You may need to register for this service with divert; then wait for the network response. your Network Operator/Service Provider.
  • Page 43 01GB01COV-AE4.book Page 43 Wednesday, July 11, 2001 12:12 PM The Divert menu offers the following options: } All Data Divert all data calls (the phone will not even } All Calls ring). Divert all calls unconditionally (the phone will not even ring). } Cancel All Clear all active diverts.
  • Page 44: Call History

    01GB01COV-AE4.book Page 44 Wednesday, July 11, 2001 12:12 PM Call History • Caller ID (Caller Line Identification) is required to support Call history entries. Provides a record and quick access of up to 10 • When the Call History reaches its capacity, the of the last outgoing calls, up to 10 of the last oldest number is deleted automatically to provide incoming calls and up to 10 missed calls.
  • Page 45: Extras

    01GB01COV-AE4.book Page 45 Wednesday, July 11, 2001 12:12 PM Extras Alarm It is possible to set, switch on/off or set the Choose the Extras menu to access the Alarm to ring at the same time every day following sub-menus: Clock, Calculator, (Repeat daily).
  • Page 46: Calculator

    01GB01COV-AE4.book Page 46 Wednesday, July 11, 2001 12:12 PM Clock Chime 1 } ‡ Extras } Calculator Choose from the following Clock Chime 2 Enter a number. options: Beep, 8h-20h, Off. 3 Press to select the mathematical Set Date/Time function and then enter another number. Use the Jog Dial and keypad to enter the day, 4 Press to select = for a result.
  • Page 47: Games

    01GB01COV-AE4.book Page 47 Wednesday, July 11, 2001 12:12 PM Currency Converter Settings Games } ‡ Extras } Games 1 Press the Centre Key when the calculator Select Games from the Extras menu. During a screen is displayed. game, press the Centre Key to stop/start the 2 Select Settings and press the Jog Dial.
  • Page 48 (selection blinks). Press the Jog Dial to move break the code generated the selected piece up, down, left or right into by the CMD-J7/J70. the blank space. Rotate and then press the Press the Centre Key for help while playing...
  • Page 49: E-mail

    01GB01COV-AE4.book Page 49 Wednesday, July 11, 2001 12:12 PM E-mail Reading E-mail After selecting E-mail from the Extras menu } ‡ Extras } E-mail select Read to connect to your server and You can send and read E-mail by accessing to display a list of incoming mail.
  • Page 50 01GB01COV-AE4.book Page 50 Wednesday, July 11, 2001 12:12 PM Sending E-mail Settings After selecting E-mail from the Extras menu, To send and receive E-mail you need to set select Send and you can compose an E-mail. the following. Enter your E-mail address correctly as Enter the address of the person you indicated by your mail-server manager or want to send the E-mail.
  • Page 51 01GB01COV-AE4.book Page 51 Wednesday, July 11, 2001 12:12 PM E-mail User Name: The user name to access your mail server. Password: The password to access your mail server. E-mail Address: Your E-mail address. Details POP3 Port: The number of the port for the mail server for the POP3 port.
  • Page 52: Scheduler

    01GB01COV-AE4.book Page 52 Wednesday, July 11, 2001 12:12 PM Scheduler View View details of the event. } ™ Scheduler Display the calendar, save Edit Icon Select from a range of icons to be added to the your daily schedule and event entry.
  • Page 53 01GB01COV-AE4.book Page 53 Wednesday, July 11, 2001 12:12 PM Daily To Do List The following options are available if you select one of the To Do Items. View View details of the To Do entry. Select OK if the entry is correct. Complete Select Complete if you have completed the To Do item.
  • Page 54: Wap Browser

    01GB01COV-AE4.book Page 54 Wednesday, July 11, 2001 12:12 PM WAP Browser • As a safety measure, a Security Code may be necessary to use your browser. Use the code that With WAP (Wireless Application Protocol) it is set as your Security Code (see page 38). is possible to access a variety of information •...
  • Page 55 (number to access the gateway) 3 Enter the Security Code (default 0000) at ISP User Name: abc the prompt (see also page 38). ISP Password: sony Data Call Type: Automatic 4 Select Name to enter a name that will be displayed for your site.
  • Page 56 01GB01COV-AE4.book Page 56 Wednesday, July 11, 2001 12:12 PM 12 Select Details and then Timeout to enter The Browser Menu the default timeout value in seconds Choose WAP from the Main Menu using the specified by your Network Operator/ Jog Dial or simply press the Centre Key from Service Provider (if your Network standby mode once you have completed the Operator/Service Provider does not...
  • Page 57 01GB01COV-AE4.book Page 57 Wednesday, July 11, 2001 12:12 PM You can also access your Favourites while browsing Home: Access your home site. (see also “While Browsing”). However, you will Refresh: Refresh the displayed page. need to enter “wsp://” and then the URL to any WAP Add to sites you would like to access during a WAP session.
  • Page 58: Appendix

    01GB01COV-AE4.book Page 58 Wednesday, July 11, 2001 12:12 PM Appendix Troubleshooting Problem Possible Causes Possible Remedies Unable to Empty battery Charge the battery (see page 13). switch on Defective battery Replace the battery. Note that after several years, gradual decline is normal. icon Weak signal Move to an open space or nearer to a window.
  • Page 59 01GB01COV-AE4.book Page 59 Wednesday, July 11, 2001 12:12 PM Problem Possible Causes Possible Remedies Difficult to hear ––– Adjust earpiece volume, and reduce noise around the other party you (see page 19). Phones loses Weak signal Reconnection, or connection to another operator is network automatic.
  • Page 60: Unblocking The Sim Card

    01GB01COV-AE4.book Page 60 Wednesday, July 11, 2001 12:12 PM Unblocking the SIM Card Technical Specifications If you enter the PIN code incorrectly 3 times, E-GSM 900 Mobile Class 4 (2 Watts) the SIM card is blocked. Telephone 1 Enter the PUK and press the Jog Dial (or GSM 1800 Mobile Class 1 (1 Watt) press...
  • Page 61 01GB01COV-AE4.book Page 61 Wednesday, July 11, 2001 12:12 PM Licensing Sony reserves the right to make changes or improvements to any of the products Your CMD-J7/J70 is authorized for use in GSM 900 / 1800 networks and complies with described in this guide without prior notice.
  • Page 62: Index

    01GB01COV-AE4.book Page 62 Wednesday, July 11, 2001 12:12 PM Index Timer Any Key Answer World Clock Jog Dial Auto Answer Conference Call Auto Redial Connection Key Click Keypad Lock Backlight Data Services Battery Pack Divert Charging DTMF Language Inserting LCD Contrast Local Area Info E-mail Loudspeaker...
  • Page 63 01GB01COV-AE4.book Page 63 Wednesday, July 11, 2001 12:12 PM Select Line Phonebook Select Network Vibra Alert Creating Entries Selection Voicemail 9, 26 FDN Phonebook Signal Strength Grouping Silent Mode Making Calls SIM Application Toolkit Wallpaper Note SIM Card WAP Browser Own Number Inserting Saving Entries...
