Waldorf PC8140G Installation And Operation Manual
Gas pasta cooker 800 series
Hide thumbs
Also See for PC8140G:
- Installation and operation manual (25 pages) ,
- Installation and operation manual (25 pages)
Subscribe to Our Youtube Channel
Related Manuals for Waldorf PC8140G
Summary of Contents for Waldorf PC8140G
- Page 1 I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Gas Pasta Cooker PC8140G PCL8140G Date Purchased Serial Number Dealer Service Provider For use in GB &...
- Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited E.Mail: vsales@moffat.com.au Main Office: (tel): +61 (03) 9518 3888 (fax): +61 (03 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281 CANADA Serve Canada...
-
Page 3: Table Of Contents
Contents PC(L)8140G GAS PASTA COOKER (Single Tank - 40 Ltr) Introduction .................... 2 Specifications ..................3 Model Numbers Covered in this Specification General Optional Accessories Gas Supply Requirements Gas Connection Water Supply Requirements Dimensions ....................5 Installation ....................6 Installation Requirements Unpacking Location Clearances... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your WALDORF GAS PASTA COOKER and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf appliance, there are two important things you can do. -
Page 5: Specifications
Specifications Model Numbers Covered in this Specification PC[1]8140G GAS PASTA COOKER (Single Tank - 40 Ltr) NOTE: [1]: - Back Options; - Standard Models. - Low Back Models. General A commercial heavy duty, gas fired high performance Pasta Cooker designed for pasta cooking commercial high production output, using LPG (Propane) or Natural Gas. -
Page 6: Gas Connection
Specifications Gas Connection Gas supply connection point is located 152mm from left hand side, 36mm from rear of appliance, 124mm from floor and is entered from beneath appliance. An optional rear connection is available. Connection is ” BSP male. Water Supply Requirements A cold water supply must be connected to water inlet connection (R "... -
Page 7: Dimensions
Dimensions PC(L)8140G... -
Page 8: Installation
Waldorf pasta cookers are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering gas and fire safety. -
Page 9: Clearances
Installation All air for burner combustion is supplied from beneath appliance. Legs must always be fitted and no obstructions placed beneath or around base of appliance, as obstructions will cause incorrect operation and / or failure of appliance. Components having adjustments protected (e.g. paint sealed) by manufacturer are only to be adjusted by an authorised service agent. -
Page 10: Gas Connection
Gas Connection NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED SERVICE PERSON. Waldorf Pasta Cookers do not require an electrical connection, they function totally on gas supply only. It is essential that gas supply is correct for appliance to be installed and that adequate supply pressure and volume are available. -
Page 11: Water Connection
Installation Turn ‘OFF’ mains gas supply and bleed gas out Burner Operating of appliance gas lines. Pressure Test Point Turn ‘ON’ gas supply and appliance. Verify operating pressure remains correct Check pilot flame size. (Re-adjust if required Gas Control Valve by changing pilot injector. -
Page 12: Operation
(e.g. paint sealed) manufacturer should not be adjusted by the user / operator. WALDORF 'Pasta Cookers have been designed to provide simplicity of operation and 100% safety protection. Warning EVER OPERATE APPLIANCE WITH ONTROL ALVE BETWEEN LAME AND... -
Page 13: Before Use
Operation Before Use Warning REAT CARE MUST BE TAKEN BY OPERATOR TO USE THE PASTA COOKER SAFELY TO GUARD AGAINST RISK OF INJURY AND FIRE DO NOT LEAVE PASTA COOKER UNATTENDED DURING OPERATION DO NOT OVER FILL WATER IN PASTA COOKER ABOVE UPPER FILL LEVEL MARK ... -
Page 14: Lighting Pilot Burner
Operation Lighting Pilot Burner Caution Do NOT ignite burner if tank is empty (No Water). Ensure tank is filled to correct level before igniting main burner. With pasta cooker tank full of water, pilot burner can be lit. Check gas supply is turned ‘On’ at mains supply. Depress and rotate gas control knob to ‘PILOT’... -
Page 15: Cleaning And Maintenance
Cleaning and Maintenance General Warning DO NOT USE FLAMMIBLE SOLVENTS AND CLEANING AIDS ON OR IN CLOSE PROXIMITY OF PASTA COOKER HOT. WHILST COOKER IS STILL Caution Always turn ‘Off’ gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. -
Page 16: After Each Use
Cleaning and Maintenance Locking Slide Locking Slide Fig 6 Fig 5 After Each Use Warning HOT WATER WILL SCALD - DO NOT RUSH THIS JOB. Clean interior of pan regularly after each use. Do not use wire brushes on pan. Clean using a mild detergent and a hot water solution using soft cloth or a soft bristled brush. -
Page 17: Weekly Cleaning
Cleaning and Maintenance Weekly Cleaning Warning DO NOT ATTEMPT TO MOVE PASTA COOKER WHILST COOKER IS FULL OF WATER. BEFORE ATTEMPTING TO MOVE PASTA COOKER, ENSURE THAT ALL WATER HAS BEEN DRAINED FROM TANK. REFER TO INFORMATION ON PREVIOUS PAGE ON HOW TO DRAIN WATER FROM PASTA COOKER. -
Page 18: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 19: Wiring Schematic
Wiring Schematic PC8140G Pasta Cooker... -
Page 20: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure Caution Ensure Appliance is isolated from gas supply before commencing servicing. NOTE: These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. ... - Page 21 Gas Conversion and Specifications Gas Regulator NOTE, Pin rotated for Natural Gas NOTE: Gas regulator supplied convertible between Natural Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and NOTE, Pin rotated is NOT to be adjusted. for LPG Gas Type Labels On completion of gas conversion, replace gas type labels located at:- - Rear of unit, above gas connection.
-
Page 22: Gas Specifications
Gas Conversion and Specifications Gas Specifications - Australia / New Zealand Only: Natural Gas. LP Gas (Propane) Main Burner Injectors Ø 3.10mm Ø 1.90mm 0.62 0.35 Pilot Burner Injectors Ø 1.55mm Ø 1.55mm Low Fire Screw 2 turns out (c.c.w.) Fully In (c.w.) Fully Out (c.c.w.) Fully Out (c.c.w.) -
Page 23: Replacement Parts List
Regulator (RV48CLM) - (Natural Gas/LPG - convertible) - ¾” BSP female. Gas Conversion Kits Gas Type to Convert to: Model Australia / New Zealand Only UK Only Nat. Gas Nat. Gas PC8140G 232061 232060 232061 232060 Accessories (Optional) 228793 Plinth Kit.
