Summary of Contents for Digihome DTR0207
- Page 1 Digital Television Recorder Twin Terrestrial Tuner Model DTR0207 MENU PAU SE Instruction manual To obtain the best performance and ensure years of trouble-free use. please read this instruction manual completely.
-
Page 2: Table Of Contents
INDEX SAFETY INFORMATION....................................2 FUNCTIONS ........................................4 REMOTE CONTROL ....................................... 4 GETTING STARTED ....................................... 4 FRONT AND BACK PANEL .................................... 5 CONNECTION DIAGRAMS .................................... 6 REMOTE CONTROL & FUNCTIONS ................................7 MENU INTERFACE ......................................9 FIRST TIME INSTALLATION ..................................9 MAIN MENU........................................ -
Page 3: Safety Information
SAFETY INFORMATION Mains supply This equipment is designed to operate from a 220-240 Volt, 50Hz AC mains supply. Other power sources may damage it. Check that the rating label on the equipment says 230V AC ( ~ ) before you plug it in for the first time. - Page 4 Safe use and care of your audio equipment We have designed and made this product to meet European safety standards, but as with any electrical equipment you must take care to get the longest working life from it and stay safe. Here are a few tips to help you do this.
-
Page 5: Functions
Important Safety warnings • To prevent electric shock, do not remove any cover. • If anything goes wrong, don't try and fix it yourself, get a qualified service agent to look at it. • Do not expose this equipment to dripping or splashing or place any objects filled with liquids, such as vases, on the equipment. -
Page 6: Front And Back Panel
FRONT AND BACK PANEL FRONT PANEL MENU PAUSE PAUSE MENU MENU MENU ON/OFF RECORD UP/ DOWN LEFT/RIGHT BACK PANEL DO NOT REMOVE AUX SCART LEFT ANTENNA 1 ANTENNA 2 RS 232 OPTICAL OUT ANTENNA 1 ANTENNA 2 AC IN TV SCART RIGHT CVBS 1. -
Page 7: Connection Diagrams
CONNECTION DIAGRAMS NOTE: This set top box supports Free To View only. There is no provision for a CAM or Pay To View card. -
Page 8: Remote Control & Functions
REMOTE CONTROL & FUNCTIONS LIB. TIMERS GUIDE INFO TEXT BACK PQRS WXYZ MENU FAV. SUBT. WIDE PIP- PIP+ SWAP USING THE CONTROLS ON THE FRONT PANEL You can enter the main menu by pressing the menu button on the front of the unit. Then navigate through the menus with the four arrow buttons on the front of the unit and make a selection with the OK button. - Page 9 BUTTON FUNCTION 1. Standby ON / Standby 2. 8 Search Forward 3. LIB. Library of recordings 4. Timers Timer Setup Record key 6. Info Information Bar 7. Direction buttons / OK Navigation / Skip 2 minutes (left/right) 8. Back / Exit Exit 9.
-
Page 10: Menu Interface
MENU INTERFACE FIRST TIME INSTALLATION When the box is switched on from stand-by mode and if there is no channel stored in the database, First Time Installation Menu window is displayed on the screen. In this window, set the TV type with “3/4”... -
Page 11: Navigating Channel List
1.1. NAVIGATING CHANNEL LIST In the channel table “5/6” moves the selection to the previous or next .To exit menu and watch a specific channel highlight it using, “5/6” then press OK key while the "SELECT" option at the bottom of the screen is highlighted. -
Page 12: Programme Guide (7 Days Epg)
2. PROGRAMME GUIDE (7 DAYS EPG) Electronic Program Guide appears on the screen. It is able to get Information of the channel - programs weekly by means of 7- DAY–EPG. All programs of channels are displayed. current program highlighted and there is brief information about the programs of the channel, such name, short/extended... -
Page 13: Select Channel
2.1.1. SELECT CHANNEL In EPG menu, using this option, you can switch to channel of the programme that is selected. 2.1.2. RECORD / DELETE TIMER In EPG menu, after you have selected a programme, press the OK button and select the “Record” option in the menu which appears and press the OK button again. -
Page 14: Split Record
2.1.6. SPLIT RECORD If you select a programme to be recorded, with this feature, if there is another part of the programme available, it will also be set automatically to be recorded. For example in the following picture you see the programme with a red underline, which following episode is also underlined. -
Page 15: Timers
NOTE: If there is still a conflict and you leave this menu by pressing the OK button, you will see this warning message: “There are still conflicts!”. In timer menu, you can see this conflict as the picture below. A warning triangle will appear nearby the programmes which cause a conflict. These programmes will be recorded partly or not at all. -
Page 16: Recordings Library
To add a Timer press YELLOW button on the remote and the, “Add Timer “ windows appears. Channel: “3/4” keys will navigate the user through the TV or Radio list. Date: By using either “3/4” or “0,1,2…,9” keys start date is entered. Start: By using either “3/4”... -
Page 17: Play Options
Red bar: indicates the used space of the recordings on the hard disk. Yellow bar: displays the approximate capacity required for the timers currently set. Green bar: shows the free space on the hard disk. 4.1. PLAY OPTIONS 4.1.1. PLAY FROM START Plays the recording from the beginning. -
Page 18: Edit Recordings
EDIT RECORDINGS While the “Edit recordings” option is highlighted, using the 3/4” buttons come to the list of recordings on the right of this menu. Select one of them, which should be archived and press the OK button. You will come to the following menu: Here, only the “Start recording at”... -
Page 19: Chapter Options
DURATION: Set the duration of the appeareance of the “Edit recording title” menu main title on the screen. If you press the Menu button during playback, you will enter the “Chapter options and in this menu, you could set any point as a chapter. So, the user is be able to skip frames which should not be archived. -
Page 20: Setup
5. SETUP The adjustments in this menu are: 5.1. RECORDINGS The internal hard drive can store up to 40 hours of digital TV broadcast (depending on the data rate of the recorded programme, which is set automatically by the broadcaster). Because the PVR has a Twin Tuner it is possible to record two events and watch two programmes at the same time. -
Page 21: Format Disk
Unplayed: If this option is set to "EXCLUDED" any unplayed recordings will NOT be deleted. If this option is set to "INCLUDED", unplayed recordings WILL be deleted. 5.1.3. FORMAT DISK On rare occasions the Hard Disk may malfunction, in most cases formatting the Hard Disk will restore normal operation however ALL the data stored on the Hard Disk will be lost. -
Page 22: Recording Format
Recording Format HDD recording is done using the variable bit rate format (VBR) for more efficient recording. The following phenomena may occur. With the variable bit rate format, the remaining amount which can be recorded may increase or decrease relative to the display of the remaining amount of HDD space. •... -
Page 23: Configuration
5.2. CONFIGURATION You can configure the settings of your set top box. Select Configuration from Setup menu and press OK to enter this menu. Press the BACK button on the remote to exit 5.2.1. TV TYPE Digital terrestrial television channels can broadcast programmes in a widescreen format which must be output differently to normal and widescreen TV sets. -
Page 24: Receiver Upgrade - Oad
5.2.7. RECEIVER UPGRADE - OAD Over Air Download (OAD): To ensure that your STB always has the most up todate information. Please ensure that after use it is set to its standby mode. The automatically powers up at 3.00 A.M. each day and searches for any new information which may be broadcast and will download this to your receiver automatically. -
Page 25: Language
5.3. LANGUAGE In this menu the user can adjust the preferred language. Language is changed by pressing OK key. Menu: shows the language of the system Preferred These settings will be used if available. Otherwise the current settings will be used. Ø... -
Page 26: First Time Installation
5.4.3. FIRST TIME INSTALLATION Use this option to load default settings, which had been set at the factory. To install factory settings, highlight ‘First Time Installation’ menu and press OK key, then you will be asked to confirm deleting all channels and settings. - Page 27 Ø Current event name next event name, and their start and end times. Ø Program duration bar Ø Program mode (TV or Radio) Ø Channel number Ø Name of the channel The second press of the info button brings up a box containing a brief description of the currently viewed programme.
-
Page 28: Time Shifting (Pause Live Recording)
SWAP Main window and PIP window change their places. TIME SHIFTING (PAUSE LIVE RECORDING) Pause Live Recording is a feature that enables you to pause a live broadcast if, say the phone rings you can go back to the same spot that you were at when you left. - Page 29 WIDE TV sets are available with screens of the standard (4:3) format and widescreen (16:9) format. When you first installed your receiver you specified the format of the connected TV (this can now be altered if necessary; see Configuration)Digital terrestrial television broadcasts are also made in both standard and widescreen formats.
-
Page 30: Software Upgrade Through Rs232
8. SOFTWARE UPGRADE THROUGH RS232 The object of this manual is to give necessary information and details to the user to upgrade the software of the receiver through RS232. The list of the necessary equipment is as follows: Receiver and TV PC with “Hyper Terminal”... -
Page 31: Notes
9. NOTES POWER: The receiver should be plugged into a 220-240 V AC 50Hz supply only. LEADS: Ensure the power supply lead, and all other leads, are positioned so they are not likely to be walked on or pinched by things placed on or against them. Pay particular attention to the power lead, where it enters the mains plug and where it comes out of the receiver. -
Page 32: Trouble Shooting Guide
10. TROUBLE SHOOTING GUIDE Problem Possible Reason What to do The Led indicator Mains cable is Check if the main cable is not does not glow not connected plugged into the power socket. Check the Aerial and scart No picture or sound No signal or weak signal. -
Page 33: Technical Specifications
11. TECHNICAL SPECIFICATIONS GENERAL CHARACTERISTICS Supply Voltage 220 - 240 V AC ~ 50Hz Input Frequency 470 Mhz - 862 Mhz Maximum Power consumption 21 W Standby Power Consumption 13 W Operating temperature 5ºC to +45ºC Storage temperature -15ºC to +55ºC Humidity 25 to 75 % rel Physical dimensions... - Page 34 REMOTE CONTROL Operating Distance 10 m Max. Batteries 2x1.5V Micro (R-03/AAA) TUNERS 2 xRF In IEC-type, female (75Ohm) 2 x RF Out (loop through) IEC-type, male (75Ohm) HARD DISK Hard Disk capacity 80 GB FRONT PANEL Display Standby ON/OFF, Menu, Record, Pause, OK, Remote Control Keys Menu Up/Down, Menu Left/Right.
-
Page 35: Important Notice
12. IMPORTANT NOTICE: DIGITAL SWITCHOVER AND YOUR TV EQUIPMENT WHAT YOU NEED TO DO TO ENJOY WATCHING TV DURING AND FOLLOWING DIGITAL SWITCHOVER Starting in 2008* and ending in 2012, television services in the UK will go completely digital, TV region by TV region. - Page 36 A. Information on disposal geared towards private users (households). Within the scope of European Union Caution: if you would like to throw away this device, please do not throw it into an ordinary bin! The used electrical and electronic devices need to be separately recycled and in conformance with the laws in force in terms of treatment, recovery and recycling of those devices.
