2. Cycle power on AnyLink by removing – then re-inserting the
3-pin connector in the INPUT jack.
3. AnyLink's LED will turn on. Wait 5 seconds and AnyLink will
sound three tones
4. Release the stick back to neutral position. AnyLink should sound
• •
two tones
as shown in the chart below.
CHANNEL 1
CHANNEL 2
CHANNEL 3
CHANNEL 4
5. Check all controls. If all channels from the Tx are not properly
mapped, or Alternate Channel Mapping is no longer desired,
repeat steps 1 through 4 to return all channels back to factory
defaults, at which point AnyLink will sound one tone * after power
is re-applied.
NOTE: If the Alternate Channel Mapping mode cannot be entered
for any reason, changing the servo connections at the Tactic Rx to
properly match the controls of the Tx could still allow AnyLink to
function properly with your Tx (but is not possible with Micro Tx-R
aircraft).
6
• • •
.
to indicate the order of channels has been changed
ALTERNATE CHANNEL MAPPING
FUTABA, HITEC
Elevator
Throttle
Aileron
Rudder
JR, SPEKTRUM, GRAUPNER
Aileron
Elevator
Throttle
Rudder
