SP SW
SW
Ref. No.
Part No.
Description
1-670-018-11 SP SW BOARD
*
***********
< CONNECTOR >
CNS106 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
< DIODE >
D120
8-719-911-19 DIODE 1SS119
D121
8-719-911-19 DIODE 1SS119
< RESISTOR >
R168
1-249-415-11 CARBON
R169
1-249-417-11 CARBON
R170
1-249-419-11 CARBON
R172
1-249-421-11 CARBON
< SWITCH >
S105
1-762-751-11 SWITCH, TACTILE (SHIFT)
S131
1-762-751-11 SWITCH, TACTILE (1/u)
S132
1-762-751-11 SWITCH, TACTILE (DISPLAY)
S133
1-762-751-11 SWITCH, TACTILE (PRESET TUNING +)
S134
1-762-268-11 SWITCH, ROTARY (SPEAKERS)
S139
1-762-751-11 SWITCH, TACTILE (FM/AM)
S146
1-762-751-11 SWITCH, TACTILE (PRESET TUNING -)
**************************************************************
1-670-017-11 SW BOARD
*
********
< CAPACITOR >
C113
1-164-159-11 CERAMIC
C114
1-164-159-11 CERAMIC
C118
1-164-159-11 CERAMIC
< DIODE >
D104
8-719-046-39 DIODE SEL5821A-TH15
D105
8-719-046-39 DIODE SEL5821A-TH15
D106
8-719-046-39 DIODE SEL5821A-TH15
< RESISTOR >
R124
1-249-411-11 CARBON
R136
1-249-413-11 CARBON
R137
1-249-411-11 CARBON
R140
1-249-415-11 CARBON
R144
1-249-417-11 CARBON
R148
1-249-419-11 CARBON
R152
1-249-421-11 CARBON
R156
1-249-425-11 CARBON
R166
1-249-411-11 CARBON
R167
1-249-413-11 CARBON
R173
1-249-421-11 CARBON
R174
1-249-419-11 CARBON
R175
1-249-415-11 CARBON
R176
1-249-413-11 CARBON
R177
1-249-411-11 CARBON
R178
1-249-417-11 CARBON
TUNER
Remark
680
5%
1/4W F
1K
5%
1/4W F
1.5K
5%
1/4W F
2.2K
5%
1/4W F
0.1uF
50V
0.1uF
50V
0.1uF
50V
330
5%
1/4W
470
5%
1/4W F
330
5%
1/4W
680
5%
1/4W F
1K
5%
1/4W F
1.5K
5%
1/4W F
2.2K
5%
1/4W F
4.7K
5%
1/4W F
330
5%
1/4W
470
5%
1/4W F
2.2K
5%
1/4W F
1.5K
5%
1/4W F
680
5%
1/4W F
470
5%
1/4W F
330
5%
1/4W
1K
5%
1/4W F
Ref. No.
Part No.
S103
1-762-751-11 SWITCH, TACTILE (INPUT MODE)
S104
1-762-751-11 SWITCH, TACTILE (RDS-PTY)
S107
1-762-751-11 SWITCH, TACTILE (5.1 INPUT)
S108
1-762-751-11 SWITCH, TACTILE (RDS-EON)
S111
1-762-751-11 SWITCH, TACTILE (EQ ON/OFF)
S115
1-762-751-11 SWITCH, TACTILE (SOUND FIELD-GENRE)
S119
1-762-751-11 SWITCH, TACTILE (SOUND FIELD-MODE)
S123
1-762-751-11 SWITCH, TACTILE (SOUND FIELD-ON/OFF)
S135
1-762-751-11 SWITCH, TACTILE (<)
S136
1-762-751-11 SWITCH, TACTILE (∧)
S137
1-762-751-11 SWITCH, TACTILE (>)
S140
1-762-751-11 SWITCH, TACTILE (SET UP)
S141
1-762-751-11 SWITCH, TACTILE (CURSOR MODE)
S142
1-762-751-11 SWITCH, TACTILE (MEMORY)
S143
1-762-751-11 SWITCH, TACTILE (FM MODE)
S144
1-762-751-11 SWITCH, TACTILE (TUNING +)
S145
1-762-751-11 SWITCH, TACTILE (TUNING -)
S147
1-762-751-11 SWITCH, TACTILE (∨)
**************************************************************
1-670-000-11 TUNER BOARD
*
C1
1-162-207-31 CERAMIC
C2
1-126-961-11 ELECT
C3
1-126-960-11 ELECT
C4
1-162-306-11 CERAMIC
C5
1-162-291-31 CERAMIC
C6
1-164-068-11 CERAMIC
C7
1-164-062-11 CERAMIC
C381
1-164-159-11 CERAMIC
C382
1-161-494-00 CERAMIC
CNS304 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CNS305 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
IC1
8-759-450-86 IC BU1922
L1
1-410-521-11 INDUCTOR 100uH
R1
1-247-807-31 CARBON
R2
1-247-807-31 CARBON
R3
1-249-385-11 CARBON
X1
1-579-900-21 VIBRATOR, CRYSTAL (4.33MHz)
**************************************************************
– 86 –
Description
< SWITCH >
***********
< CAPACITOR >
22PF
5%
2.2uF
20%
1uF
20%
0.01uF
20%
560PF
10%
82PF
5%
47PF
5%
0.1uF
0.022uF
30%
< CONNECTOR >
< IC >
< COIL >
< RESISTOR >
100
5%
100
5%
2.2
5%
< VIBRATOR >
Remark
50V
50V
50V
16V
50V
50V
50V
50V
25V
1/4W
1/4W
1/6W F
