OEM-500i/SR-i300

Motorcycle Security System

INSTALLATION MANUAL

AND USER'S GUIDE

FCC Notice

This device complies with Part 15 of FCC rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) This device

must accept any interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this device.

Aritronix Ltd

14435 N. Scottsdale Rd #500

Scottsdale, AZ 85254

Technical Assistance (480)951-1109

Table of Contents

Do you have a question about the OEM-500i and is the answer not in the manual?

Page 1: Installation Manual
OEM-500i/SR-i300 Motorcycle Security System INSTALLATION MANUAL AND USER’S GUIDE FCC Notice This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference that may cause undesired operation.
Page 2: Optional Accessories
A button & B Button at the same time Arm in Transport Mode Standard Features • 3 Channel waterproof remote transmitter C Button • Ultra low power drain MCM Arm without Perimeter Sensor • Built-in Analog Devices ADXL202 accelerometer • Ignition protection •...
Page 3: Components List
Operating Instructions Components List Arming (audible) MCM (Main Control Module) Press the A button, siren chirps 3 times and the turn signal lights flash 1 time. System is armed. Remote Transceiver Disarm (audible) Press the A button, siren chirps 1 time and the turn signal lights flash. System is disarmed. Arming (silent) Press the B button, turn signal lights flash 1 time.
Page 4 Color Codes: Mounting the Components Ground (-) Tail Light Left Turn Signal Right Turn Signal Select a suitable location under the seat or in a side cover. Mount the MCM using Velcro Honda Green wire Brown wire Orange wire Blue wire or cable ties.
