Scorpio SR-i500 User Manual

Fm 2-way security system
Hide thumbs Also See for SR-i500:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual and Installation Instructions
Enlarged version

Setting Clock Time

1.
Enter the programming mode.
2.
Press button #4 repeatedly until the
3.
Press button #1 to select and enter clock setting mode.
4.
Press button #1 to scroll through 'hour', 'minute', 'am/pm' settings. The selected
item will be flashing.
5.
Press button #2 to adjust the setting of the selected item.
6.
Press button #4 to save setting and exit, or press button #3 to abort.

Setting Alarm Clock

1.
Enter the programming mode.
2.
Press button #4 repeatedly until
3.
Press button #1 to select and enter alarm clock setting mode
4.
Press button #1 to scroll through 'alarm on/off', 'hour', 'minute', 'am/pm'
settings. The selected item will be flashing.
5.
Press button #2 to adjust the setting of the selected item.
6.
Press button #4 to save setting and exit, or press button #3 to abort.
FCC Notice
This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device
must accept any interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this device.
14435 N. Scottsdale Rd #500
Scottsdale, AZ 85254
Technical Assistance (480)951-1109
icon begins to flash.
icon begins to flash.
Aritronix Ltd
SR-i500
FM 2-Way Security System

INSTALLATION MANUAL

AND USER'S GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR-i500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scorpio SR-i500

Summary of Contents for Scorpio SR-i500

  • Page 1: Installation Manual

    Press button #2 to adjust the setting of the selected item. Press button #4 to save setting and exit, or press button #3 to abort. SR-i500 Setting Alarm Clock FM 2-Way Security System Enter the programming mode.

  • Page 2: Optional Accessories

    Selecting Auto/Manual Arming Enter the programming mode. Scroll to the icon and Press Button #1 to enter the Standard Features arming selection screen. The LCD will display the current setting ([Act] or [PAS]) and the siren will chirp two or three times. To program follow these steps: •...

  • Page 3: Mounting The Components

    rogramming Instructions There are two types of programm ing mode: Components List 1) Programming the Transceiver- To program the transceiver the MCM do es not have to be installed or be within range. The program mable modes for the Transceiver are: MCM (Main Control Module) •...
  • Page 4 Checking Motorcycle Status and Violation Display with Time Stamp Routing the Antenna Wire Press button #4. The back light and the memory screen will be displayed. If the The MCM includes an 18” antenna wire. The first 12” is a coaxial wire; the remaining 6” is alarm was not triggered, all the sensor icons will come on and the # 0 0 will be the actual antenna wire.
  • Page 5 Sensor Memory Display Fuse When the system is disarmed the turn signals will flash to indicate if there has To Battery (+) been an alarm trigger. The lights will flash once to indicate that the system has been disarmed, additional flashes indicate that the following trigger has occurred: Accessory 1 flash then 1 additional flash...
  • Page 6 Operating Instructions If the perimeter sensor triggers a full alarm cycle, the LCD displays icon. (Note: The turn signal lights will not flash for a perimeter sensor trigger). With the optional back up system installed, the LCD displays icon if the main Press button #1, siren chirps 3 times and the turn signal lights flash 1 time.
