Color Monitor
USER GUIDE
MANUEL D'UTILISATION
MODEL : 790SC
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
Avant d'utiliser ou de régler cet appareil pour la première
fois, lisez attentivement ce manuel d'instructions.
Advertisement
Table of Contents
Related Manuals for LG 790SC
Summary of Contents for LG 790SC
-
Page 1: Color Monitor
Color Monitor USER GUIDE MANUEL D'UTILISATION MODEL : 790SC Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service. -
Page 2: Fcc Compliance Statement
- Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by LG Electronics Inc. for compliance could void the user's (or your) authority to operate the equipment. Only peripherals (digital input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may... - Page 3 Environmental Labelling of Personal Computers ? @ @ @ ? @ @ @ ? @ @ ? f ? @ @ @ @ @ @ @ @ @ @ @ @ @ e ? ? O 2 @ @ 6 K ? g ? O 2 @ @ @ @ 6 K ? g ? @ @ @ W 5 O 2 @ @ 6 K g...
- Page 5 TCO’95 Environmental Requirements...
- Page 6 Shipping Package The packaging material can be recycled, or you can save it to return the monitor to a service center for repair or disposal. CFC Compounds in Distribution Packaging Cushioning material used for shipping finished monitors are not manufactured with nor do they contain any CFC compounds. Design for Disassembly/Recycling These monitors have been designed for easy end-of-life disassembly and recycling.
-
Page 7: Table Of Contents
Table of Contents Introduction ....................Features Monitor Registration Notice ......................Trademark Acknowledgments ..............Important Precautions ....................On Safety On Installation ....................A4 On Cleaning ....................A4 On Repacking ....................A4 Connecting the monitor ........Connecting to any IBM VGA PC Compatible System Connecting to an Apple Macintosh II, Centris and Quadra......A7 Location and Function of Controls .................... -
Page 8: Features
Introduction Thank you for purchasing a high resolution monitor. It will give you high resolution performance and convenient reliable operation in a variety of video operating modes. Features The monitor is a 17 inches (15.9 inches viewable ) intelligent, @ @ @ @ @ @ @ @ @ @ @ @ g ? @ @ @ @ @ @ @ @ @ @ @ @ g ? @ @ @ @ @ @ @ @ @ @ @ @ g ? @ @ @ @ @ @ @ @ @ @ @ @ g ? -
Page 9: Monitor Registration
Serial No. Notice All rights reserved. Reproduction in any manner, in whole or in part, is strictly prohibited without the written permission of LG Electronics Inc. Trademark Acknowledgments LG is a trademark of LG Electronics Inc. IBM is a registered trademark and VGA is a trademark of International Business Machines Corporation. -
Page 10: Important Precautions
Important Precautions This unit has been engineered and manufactured to assure your personal safety, but improper use can result in potential electrical shock or fire hazard. In order not to defeat the safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing. -
Page 11: On Installation
Do not add accessories that have not been designed for this monitor. @ @ @ @ @ @ @ @ @ @ @ @ g ? @ @ @ @ @ @ @ @ @ @ @ @ g ? @ @ @ @ @ @ @ @ @ @ @ @ g ? @ @ @ @ @ @ @ @ @ @ @ @ g ? @ @ @ @ @ @ @ @ @ @ @ @ g ? -
Page 12: Connecting The Monitor
Connecting the Monitor On the back of the monitor are two plug-in connections; one for the AC power cord, and the others for the signal cable from the video card. AC Power Connection One end of the AC power cord is connected into the AC power connector on the back of the monitor. -
Page 13: Connecting To Any Ibm Vga Pc Compatible System
Connecting to any IBM VGA PC compatible system Figure 3 shows the signal cable connections from the monitor to the Video Graphics Array (VGA) port typical in an IBM PC or PC compatible. This also applies to any graphics video card for PC-CAD or workstation that has a 15 pin high density (3 row) D-Sub connector. -
Page 14: Connecting To An Apple Macintosh Ii, Centris And Quadra
Connecting to an Apple Macintosh II, Centris and Quadra Figure 4 shows the connection to an Apple Macintosh, using a separately purchased adapter. Power OFF both the monitor and the PC. Locate the appropriate MAC to VGA adapter block at your local computer store. -
Page 15: Location And Function Of Controls
Location and Function of Controls Location and Function of Controls Front View Power ON/OFF Button Power (DPMS) Digital Control Panel Indicator Contrast Adjustment Control Brightness Adjustment Control Rear View ID Label Power ON/OFF Switch of the Monitor D-Sub Signal Connector AC Power Socket Note : Turn on the monitor using the ON/OFF switch on the rear of the monitor. -
Page 16: Control Panel Function
Control Panel Function Front Panel Controls OSD Enter Button OSD Exit Button Power (DPMS) Indicator Power ON/OFF Button OSD Select /Adjustment Button Contrast Adjustement Control Brightness Adjustement Control Control Function Use this button to start/enter and exit from OSD Enter Button the On Screen Display (OSD). -
Page 17: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating parameters of the monitor are quick and easy with the On Screen Display Control system, using only the Enter button and Adjustment Control buttons. A quick example is given below to familiarize you with the use of the controls. -
Page 18: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description Horizontal Position... -
Page 19: Osd Adjust
OSD Adjust Description Side Pincushion To correct the bowing in and out of the image. G E O M E T R Y Trapezoid 6 8 . 7 k H z / 8 5 H z E N T E R : S E L : To correct geometric distortion. - Page 20 OSD Adjust Description Horizontal Moire Reduce horizontal moire when interference patterns of dark steady wary I M A G E lines appear on your screen. The moire 6 8 . 7 k H z / 8 5 H z adjustments may affect the focus of the E N T E R : S E L : screen.
- Page 21 OSD Adjust Description 9300 9300K To appear the display’s color temperature. Slightly bluish white. C O L O R 6 8 . 7 k H z / 8 5 H z 7200 7200K E N T E R : E N T E R : S E L : S E L : To appear the display’s color temperature.
- Page 22 OSD Adjust Description Horizontal Position This item lets you adjust the OSD horizontal position. O S D A D J U S T 6 8 . 7 k H z / 8 5 H z E N T E R : S E L : Vertical Position This item lets you adjust the OSD vertical...
- Page 23 OSD Adjust Description Degauss Used to demagnetize the picture to give a move account image and color. M I S C E L L A N E O U S 6 8 . 7 k H z / 8 5 H z E N T E R : S E L : Information...
-
Page 24: Video Memory Modes
Video Memory Modes The monitor has 38 memory locations for display modes, 12 of which are factory preset to popular video modes. Factory Preset Timing Signal Chart Video Sync Mode1 Mode2 Mode3 Mode4 Mode5 Mode6 Symbol VESA Polarity Frequency 31.469 31.469 43.269 53.674... - Page 25 Factory Preset Timing Signal Chart Video Sync Mode7 Mode8 Mode9 Mode10 Mode11 Mode12 Symbol VESA APPLE Polarity Frequency 63.974 91.146 93.750 100.00 49.725 68.681 Total Period 15.632 10.971 10.666 10.000 20.111 14.560 Data Period 11.797 8.127 7.901 7.407 14.525 11.520 Blanking 3.835 2.844...
-
Page 26: User Modes
User Modes Modes 1-26 are empty and can accept new video data. If the monitor detects a new video mode that has not been present before or is not one of the preset modes, it stores the new mode automatically in one of the empty modes starting with mode 1. -
Page 27: Energy Saving Design
Energy Saving Design This monitor complies with the EPA's Energy Star program, which is a program designed to have manufacturers of computer equipment build circuitry into their products to reduce power consumption during time of non-use. This monitor also goes into its energy saving mode if you exceed the monitor's operating limits, such as the maximum resolution of 1600x1200 or the frequency refresh rates of 30-100kHz horizontal or 50-200Hz vertical. -
Page 28: Low Radiation Compliance (Mpr Ii)
Low Radiation Compliance (MPR II) This monitor meets one of the strictest guidelines available today for low radiation emissions, offering the user extra shielding and an antistatic screen coating. These guidelines, set forth by a government agency in Sweden, limit the amount of emission allowed in the Extremely Low Frequency (ELF) and Very Low Frequency (VLF) electromagnetic range. -
Page 29: Troubleshooting
Troubleshooting Self diagnostics message. The signal cable is not connected. @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g... -
Page 30: Service
Service Unplug the monitor from the wall outlet and refer servicing to qualified service personnel when : The power cord or plug is damaged or frayed. @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g... -
Page 31: Specifications
Specifications Sync Signal Types Type H. Sync V. Sync Green Separate Sync H. Sync V. Sync Composite Sync H/V Sync Sync On Green H/V Sync (N.C : No Connection) Signal Connector Pin Assignment Signal(D-Sub) Green Blue Ground Self-Test Red Ground Green Ground Blue Ground Ground... - Page 32 @ @ @ @ @ @ @ @ @ @ @ @ g @ @ @ @ @ @ @ @ @ @ @ @ g Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc.
-
Page 33: Monitor Limited Warranty
United States and Canada LG Electronics U.S.A., Inc. will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase.
