Surebonder 9615 Operating Instructions

Upholstery stapler

Advertisement

Quick Links

WARRANTY
If you have any problems with this tool, please call FPC
Corporation toll-free at 1-800-860-3838 before returning it to the
place of purchase.
FPC Corporation warrants this stapler to be free from defects in material and
workmanship, under normal conditions of use and when used in accordance
with FPC operating instructions, for a period of 90 days from the date of
purchase by the user. Within the 90 days warranty FPC at its option shall
repair or replace stapler. The stapler must be returned at the distributor/user
expense, either within warranty or out. Repaired or replaced staplers will
receive a 60 day warranty. USER MUST BE USING THE PROPER STAPLES
FOR THIS WARRANTY TO BE VALID. WARRANTY IS VOID IF INCORRECT
TYPE OF STAPLES ARE USED.
SUREBONDER®
1/4" Crown
Upholstery Staples
Staple Length
1/4" - 1/4" Crown Heavy Duty Galvanized Staples Qty. 1000
5/16" - 1/4" Crown Heavy Duty Galvanized Staples Qty. 1000
3/8" - 1/4" Crown Heavy Duty Galvanized Staples Qty. 1000
7/16" - 1/4" Crown Heavy Dut y Galvanized Staples Qty. 1000
1/2 - 1/4" Crown Heavy Duty Galvanized Staples
5/8" - 1/4" Crown Heavy Duty Galvanized Staples Qty. 1000
FPC Corporation - 355 Hollow Hill Drive - Wauconda, IL 60084
Phone: (847) 487- 4583
website: www.surebonder.com
3/8"
Narrow Crown
22
Gauge
Part #
350-38G
350-38G
350-38G
350-34G
Qty. 1000
350-78G
350-58G
Fax: (847) 487-0174
e-mail: sales@surebonder.com
Model 9615 Upholstery Stapler
Read Safety Rules and Instructions Carefully;
Save this manual for Future Reference
0308
3/8"
Narrow Crown
SUREBONDER
300
Upholstery Staples
1/4" thru 5/8"
and most 22 gauge 3/8" crown staples
Operating Instructions
®
Uses
22
®
Gauge
Series

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9615 and is the answer not in the manual?

Questions and answers

Summary of Contents for Surebonder 9615

  • Page 1 ® WARRANTY Model 9615 Upholstery Stapler If you have any problems with this tool, please call FPC Corporation toll-free at 1-800-860-3838 before returning it to the place of purchase. FPC Corporation warrants this stapler to be free from defects in material and...
  • Page 2 IMPORTANT SAFETY WARNINGS: THE SAFETY WARNINGS BELOW CANNOT COVER ALL POSSIBLE SITUATIONS THAT MAY OCCUR. THESE BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO PROTECT AGAINST PERSONAL INJURY TO THE OPERATOR OR OTHER PERSONNEL IN THE AREA, AS WELL AS DAMAGE TO THE EQUIPMENT. READ AND UNDERSTAND THESE WARNINGS BEFORE USING EQUIPMENT.
  • Page 3 (Closing the staple magazine while The Surebonder 9615 Pneumatic Stapler is designed to use 3/8" crown fine wire Upholstery staples are loaded engages the spring-load mechanism, so it will take slightly more pressure to staples in1/4”,5/16”, 3/8", 7/16", 1/2", and 5/8"...
  • Page 4: Specifications

    Staple Specs: 3/8” Crown 22 gauge Upholstery Staples 1/4”, 5/16”, 3/8", 7/16", 1/2", and 5/8" leg lengths Adjustable Exhaust 1/4” Male Quick Rubber Grip Release Connector Track Release Lever Trigger Contact Safety Staple magazine Mechanism 9615 Parts List Staple viewer...
