Page 1
The product must be returned at the distributor/user expense, either within warranty or out. Repaired or replaced products will receive a 60 day warranty. Visit us at surebonder.com for our full line of products Operating Instructions FPC Corporation - 355 Hollow Hill Drive - Wauconda, IL 60084...
DANGER This manual contains important information about product safety. Read and understand this entire manual before operating this tool. IMPORTANT SAFETY WARNINGS: THE SAFETY WARNINGS BELOW CANNOT COVER ALL POSSIBLE SITUATIONS THAT MAY OCCUR. THESE BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO PROTECT AGAINST PERSONAL INJURY TO THE OPERATOR OR OTHER PERSONNEL IN THE AREA, AS WELL AS DAMAGE TO THE EQUIPMENT.
Page 3
IMPORTANT SAFETY WARNINGS: continued Disconnect air hose from tool: -before performing maintenance. -when clearing a jam. -when tool is not in use. -when moving it to another location. Carry tool by the handle only, not by the air hose. Inspect the tool before each use to insure all parts are operating properly. Lock the tool in a clean, dry storage area between uses.
MAINTENANCE (continued) APPLICATIONS Head Cleaning and oiling Every 10, 000 cycles the jaws of the tool should be cleaned and oiled. Disconnect the air Installing 3/32', 1/8", 5/32" & 3/16" blind rivets in various materials in production/commercial supply and air valve. To access jaws unscrew nosepiece then unscrew jaw guide. Jaws will applications.
OPERATION OPERATION Part Identification TOOL PREPARATION Oil Fill Screw Determine the size rivet that you are going to use. If Nose Housing setting 3/16" rivets no changes to the tool are Hanger necessary the 3/16” nosepiece is factory installed. Mandrel Collector For 1/8”...
Page 6
MAINTENANCE Air Supply Requirements Lubrication Use a dry, filtered air supply regulated to 75 - 100 psi (5-6 bar) . A minimum of 3.0 scfm is recommended. If the recommended operating pressure is exceeded the tool may not function It is important that the tool be properly lubricated. Every 10,000 cycles the tool should be oiled with because of built up line pressure.
