IMPORTANT MANUAL
PART'S MANUAL
MODEL NUMBER:
627
P

SNOW THROWER

Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
Always Wear Eye Protection During Operation
585 23 03-27
ES
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P627ES and is the answer not in the manual?

Questions and answers

Related Manuals for Poulan Pro P627ES

Summary of Contents for Poulan Pro P627ES

  • Page 1: Snow Thrower

    IMPORTANT MANUAL Do Not Throw Away PART'S MANUAL WARNING: MODEL NUMBER: Read the Owner's Manual and fol low all Warnings and Safety In struc tions. Fail ure to do so can result in serious injury. SNOW THROWER Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.

  • Page 2: Auger Housing / Impeller Assembly

    REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) AUGER HOUSING / IMPELLER ASSEMBLY 2 (EXPLODED) 01.07.032-A NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
  • Page 3 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 532 18 41-05 IMPELLER 584 64 83-01 GEARBOX ASSEMBLY 532 18 89-09 BEARING 585 09 32-01 IMPELLER PULLEY 532 44 24-38 DISCHARGE BASE...
  • Page 4 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 532 41 52-71 AUGER HOUSING 27 532 40 77-27 SCRAPER BAR 872 27 05-05 CARRIAGE BOLT 5/16−18 X .625 532 15 53-77 NUT 5/16−18...
  • Page 5 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 532 42 04-78 AUGER BEARING 532 41 19-39 BEARING PLUG 532 17 95-82 SCREW 5/16−18 X 1.00 01.07.024-B PART DESCRIPTION 532 43 59-51...
  • Page 6 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) CONTROL PANEL / CHUTE PART DESCRIPTION 532 44 36-24 CHUTE WELDMENT 532 18 45-11 DEFLECTOR WELDMENT 532 42 03-25 DEFLECTOR SEAL 532 18 41-14 STRAP 532 19 19-38 KNOB BLACK...
  • Page 7 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) CONTROL PANEL / CHUTE 01.09.010-C PART DESCRIPTION 532 42 82-72 LEVER/CABLE ROTATOR ASSEMBLY 817 54 10-08 SCREW 10-24 X .625 532 42 06-78 ROTATOR HEAD 532 40 59-32 ROTATOR PIVOT BRACKET...
  • Page 8 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) HANDLES PART DESCRIPTION 532 42 10-69 PLOW HANDLE LH 532 42 10-70 PLOW HANDLE RH 532 42 91-48 PANEL BRACKET LH 532 42 91-49 PANEL BRACKET RH 532 19 95-13...
  • Page 9 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) HANDLES 01.08.021-A PART DESCRIPTION 585 19 88-02 CONTROL PANEL 581 77 98-01 LH CONTROL LEVER 581 77 97-01 RH CONTROL LEVER 584 80 90-01 INTERLOCK CONTROL ROD 585 00 47-03...
  • Page 10 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) HANDLES PART DESCRIPTION 584 80 87-01 ROD IMPELLER CONTROL 584 80 88-01 ROD TRACTION CONTROL 532 18 04-45 SHIFTER ROD TOP 532 18 77-16 SHIFTER ROD BOTTOM 532 18 04-47...
  • Page 11 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) HANDLES PART DESCRIPTION 532 18 33-52 CONSOLE PANEL 532 18 44-71 SCREW 10−24 X .625 532 17 52-62 SCREW 10−24 X 1.25 01.10.001-B PART DESCRIPTION 532 41 62-88 INTERLOCK SPRING...
  • Page 12 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) DRIVE ITEM 42 EXPLODED 14 15 01.02.013-F NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty.
  • Page 13 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) DRIVE PART PART DESCRIPTION DESCRIPTION 532 19 88-75 SPEED SELECTOR ASSEMBLY 532 17 53-44 BEARING 817 54 10-08 THRED ROLLING SCREW 532 17 86-13 WHEEL HUB 10-24 X .500 874 76 05-14 SCREW 5/16-18-.875...
  • Page 14 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) DRIVE 01.03.005-C PART DESCRIPTION 532 18 82-26 AXLE ASSEMBLY (assy of 1a,1b) 532 17 93-52 AXLE SHAFT 532 18 42-06 ROLL PIN 3/16 532 40 26-91 SPROCKET 532 44 49-49...

  • Page 15: Chassis / Engine / Pulleys

    REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) CHASSIS / ENGINE / PULLEYS PART DESCRIPTION 532 43 60-67 COMPLETE LCT ENGINE PW2HK18650178E 532 42 92-75 FRAME 01.00.034-A 532 15 04-06 BOLT 3/8-16 532 42 88-67 SCREW 5/16-18 X .750...
  • Page 16 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) CHASSIS / ENGINE / PULLEYS 19 20 01.21.003-F PART PART DESCRIPTION DESCRIPTION 532 40 80-07 IMPELLER BELT 532 40 00-26 WASHER 532 41 97-44 TRACTION BELT 532 05 92-89 WASHER...
  • Page 17 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) WHEELS PART DESCRIPTION 581 18 53-01 WHEEL ASSEMBLY LH 581 18 54-01 WHEEL ASSEMBLY RH 01.06.018-A NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

  • Page 18: Bag Of Parts

    REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) BAG OF PARTS PART DESCRIPTION 532 19 85-63 POWER CORD 532 16 96-75 RETAINER PIN 532 42 91-12 WRENCH 873 80 06-00 LOCKNUT 3/8−16 819 13 13-16 WASHER 3/8 532 19 20-90 SHEAR BOLT 1/4−20 X 1−3/4...
  • Page 19 REPAIR PARTS SNOW THROWER - - MODEL NUMBER P627ES (96198004402) DECALS PART DESCRIPTION 532 18 10-37 DECAL, DANGER 532 18 10-35 DECAL, DANGER, DEFLECTOR 532 18 10-42 DECAL, DANGER 532 18 10-33 DECAL, INSTRUCTION 581 43 01-01 DECAL, CON RT SPD/LEV/PWST...
  • Page 20 REPAIR PARTS SNOW THROWER - MODEL P627ES (96198004402) COMPLETE ENGINE-532436067 GENII 208 HOP SNOW ENGINE SERVICE KIT PW2HK18650178EABGJOQUVYE1M PW2HK18650178PABGOQUVE1M PW2HK18650178EABGOQUVE1M PW2HK18650178ZABGOQUVZE7M 10 10A *Included with part# 40 Electric Start Only NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
  • Page 21 REPAIR PARTS SNOW THROWER - MODEL P627ES (96198004402) COMPLETE ENGINE-532436067 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 43 65-61 HEATER BOX ASSEMBLY-SNOW 26A 532 42 05-85 FLYWHEEL ASSEMBLY, MANUAL 532 43 65-63 MUFFLER ASSEMBLY-SNOW START-SNOW 532 43 65-64...

  • Page 22: Limited Warranty

    In the event you have a claim under this Warranty, you must return the product to an authorized service dealer. Should you have any unanswered questions concerning this Warranty, please contact: In Canada contact: Poulan Poulan Outdoor Products Customer Service Dept.
