- Page 1 IPL, LT2114, 96011029301, 2011-02, Tractor LT2114 Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar...
-
Page 2: Illustrated Parts List
ILLUSTRATED PARTS LIST MFG ID NO. 96011029301 CUSTOMER CATALOG NO. LT2114 PRODUCT NO. 960 11 02-93 QC12YC 796031 394358 532 13 82-55 532 19 32-14 532 19 39-57 442150 532 44 24-37... -
Page 3: Wheels And Tires
TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 DECALS 27 PART PART DESCRIPTION DESCRIPTION 532 19 68-41 Decal, Warning Engine Symbols 532 18 21-66 Decal, Mower Cut finger Symbol 532 14 50-05 Decal, Bat Dan/Poi P/L Symbols 532 18 04-32 Decal, 100 Dba 532 44 21-50 Decal, RPL. - Page 4 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 SCHEMATIC 38 SCH03 BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY...
- Page 5 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 ELECTRICAL 32...
- Page 6 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 ELECTRICAL 32 KEY PART NO. NO. DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 66-89 Box Battery Fender 532 17 61-38...
-
Page 7: Chassis And Enclosures
TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 CHASSIS AND ENCLOSURES 39 chassis-stlt_elite value_4... - Page 8 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 CHASSIS AND ENCLOSURES 39 KEY PART NO. NO. DESCRIPTION 532 17 46-19 Chassis 532 17 65-54 Drawbar 532 15 52-72 BumperHood/Dash 532 19 35-10 Dash 872 14 06-08...
- Page 9 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 DRIVE 40...
- Page 10 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 DRIVE 40 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 16 56-70 Transaxle Peerless 206-545C 532 14 24-32 Screw Hex Wsh Hi-Lo 532 14 66-82...
-
Page 11: Steering Assembly
TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 STEERING ASSEMBLY 41 steering_pl.lt_68_r2... - Page 12 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 STEERING ASSEMBLY 41 KEY PART NO. NO. DESCRIPTION 532 18 67-80 Wheel Steering Opp. Sears Blk 532 41 81-68 Axle Asm 532 16 98-40 Spindle Asm LH 532 16 98-39...
- Page 13 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 ENGINE 24...
- Page 14 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 ENGINE 24 KEY PART NO. NO. DESCRIPTION 532 17 05-51 Control Th/ch Flag 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 1/2 532 43 86-18 Engine B&S Model No. 31A507-2391-B1...
-
Page 15: Mower Deck
TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 MOWER DECK 44 190 191 38-7_deck-manual_26... - Page 16 TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 MOWER DECK 44 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 19 25-56 Mower Housing Assembly 532 41 01-90 Rod, Brake RH 872 14 05-06...
-
Page 17: Seat Assembly
TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 SEAT ASSEMBLY 42 seat_lt.bolt_1 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 40 10-42 Seat 532 13 43-00 Spacer Split 28 x 96 Yel Zinc... -
Page 18: Mower Lift
TRACTOR - - MODEL NO. LT2114 (96011029301), PRODUCT NO. 960 11 02-93 MOWER LIFT 45 16 17 lift-rh.1piece_27 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 40 50-07 Plunger Asm. Lift Lever 873 35 08-00 Nut Jam Hex 1/2-13 unc... - Page 19 02.15.11 BAD...
