S E R V I C E
5
I0600056
IPL, LT2116 CMA2, 2006-06, 544 88 92-01
96061008801
LT2116CMA2
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
544 88 92-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT2116CMA2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jonsered LT2116CMA2

Summary of Contents for Jonsered LT2116CMA2

  • Page 1 S E R V I C E I0600056 IPL, LT2116 CMA2, 2006-06, 544 88 92-01 96061008801 LT2116CMA2 Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar 544 88 92-01...

  • Page 2: Illustrated Parts List

    ILLUSTRATED PARTS LIST MFG. ID NO. 96061008801 CUSTOMER CATALOG NO. LT2116CMA2 PRODUCT NO. 960 61 00-88 403500 05.22.06 VB...
  • Page 3 TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 SCHEMATIC 03050_197436 (WITH LIGHTS) 12VDC STARTER AMMETER BATTERY SOLENOID (OPTIONAL) STARTER FUSE 15 AMP WHITE BLACK BLACK FBI BUZZER SWITCH CLUTCH / BRAKE ATT'MENT CLUTCH (PEDAL UP) (CLUTCH OFF) GREEN...

  • Page 4: Repair Parts

    REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 DECALS MAX + _ 90N MAX + _ 150N PART PART DESCRIPTION DESCRIPTION 532 40 03-89 Decal Warning Sym. CE 532 15 97-36 Decal Chassis Hot Muffl er 532 19 68-41 Deca;...
  • Page 5 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 ELECTRICAL 197436...
  • Page 6 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 ELECTRICAL PART DESCRIPTION 532 14 49-27 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 61-38 Switch Interlock 532 18 37-59 Harness Asm Light W/4152J...

  • Page 7: Chassis And Enclosures

    REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 CHASSIS AND ENCLOSURES 26 25 Chassis_Elite Pro_CRD_2...
  • Page 8 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 CHASSIS AND ENCLOSURES PART PART DESCRIPTION DESCRIPTION 532 17 46-20 Chassis 532 18 03-82 Bracket Exten Chassis Lh CRD 532 18 03-84 Drawbar 532 18 03-83 Bracket Exten Chassis Rh CRD...
  • Page 9 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 DRIVE drive-hydro_CRD_Laser_19...
  • Page 10 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle Hydro Gear 321-0510 532 17 00-15 Control Asm Bypass Hydro (Order parts from transaxle manu- 532 12 47-88 Spring, Retainer 1”...

  • Page 11: Steering Assembly

    REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 STEERING ASSEMBLY steering_pl.lt_60...
  • Page 12 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 STEERING ASSEMBLY PART DESCRIPTION 532 19 46-37 Steering Wheel 532 18 47-06 Front Axle Assembly 532 16 98-40 Spindle Assembly, L.H. 532 16 98-39 Spindle Assembly, R.H. 532 12 49-31...
  • Page 13 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 SEAT ASSEMBLY seat_lt.knob_7(CRD) PART PART DESCRIPTION DESCRIPTION 532 40 10-43 Seat 532 12 12-48 Bushing Snap Blk Nyl 50 Id 532 14 05-51 Bracket Pnt Pivot Fender 872 05 04-12...
  • Page 14 TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-ko.twin_16 PART PART DESCRIPTION DESCRIPTION 532 18 69-68 Control Throt/Ck 532 14 05-27 Cap Asm Fuel W/sym Vented 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 1/2...
  • Page 15 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 MOWER LIFT 17 18 lift-rh.1piece_9 PART PART DESCRIPTION DESCRIPTION 819 13 10-16 Washer 13/32 x 5/8 x 16 Ga. 532 19 84-17 Washer Asm Inner Spring W/Plunger 532 12 48-74 Spring 2-1/8"...
  • Page 16 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 BAGGER Bagger Asy (CRD)_11 PART PART DESCRIPTION DESCRIPTION 532 16 57-87 Grip Handle 532 16 52-49 Tube Handle Bagger CRD 532 16 94-84 Retainer Clip 532 12 39-76 Nut Lock 1/4 Lge Flg Gr.
  • Page 17 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 MOWER 36(92cm)_deck-elect.(CRD)_2 36 GW med/wide/std...
  • Page 18 REPAIR PARTS TRACTOR- -MODEL NO. LT2116CMA2 (96061008801), PRODUCT NO. 960 61 00-88 MOWER PART PART DESCRIPTION DESCRIPTION 532 40 01-08 Housing Asm. Mower 92 CRD 532 13 77-29 Screw Thd Roll 1/4-20 x 5/8 872 14 05-06 Bolt Rdhd Sqnk 5/16-18 unc x 3/4...
