- Page 1 S E R V I C E I0600036 IPL, LT2115 A, 2006-03, 544 40 90-01 96011018200 LT2115A Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar 544 40 90-01...
- Page 2 ILLUSTRATED PARTS LIST MODEL NO. 96011018200 CUSTOMER CATALOG NO. LT2115A PRODUCT NO. 960 11 01-82 401433 11.14.05 VB PRINTED IN THE U.S.A.
-
Page 3: Repair Parts
REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 SCHEMATIC 03054 (197428) AMMETER (OPTIONAL) WHITE IGNITION SWITCH BLUE IGNITION SWITCH POSITION CIRCUIT “MAKE” M+G+A1 B+A1 RUN/OVERRIDE B+A1 L+A2 START B + S + A1 BATTERY FUSE... - Page 4 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 DECALS PART DESCRIPTION 532 18 04-32 Decal 100 DB/CE 532 19 68-41 Decal Warning Eng. Sym 532 18 95-53 Decal Hood RH/LH 532 40 13-70 Decal Replacement 532 18 88-35 Decal Fender 532 18 57-73 Decal Ins.
- Page 5 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 ELECTRICAL 197428...
- Page 6 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 ELECTRICAL PART DESCRIPTION 532 14 49-27 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 66-89 Box Battery 532 17 61-38 Switch Interlock...
- Page 7 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 CHASSIS AND ENCLOSURES chassis_elite sv_pro_14...
- Page 8 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 CHASSIS AND ENCLOSURES PART DESCRIPTION 532 17 46-19 Chassis Weldment 532 17 65-54 Drawbar 532 15 52-72 Bumper Hood/Dash 532 19 48-22 Dash P/L 872 14 06-08 Bolt Carriage 3/8-16 x 1...
- Page 9 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 DRIVE drive-hydro.stlt_66...
- Page 10 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 DRIVE PART DESCRIPTION - - - - - - - - Transaxle Hydro Gr 322-0510 (Order parts from transaxle manu- facturer) 532 19 25-02 Rod Shift Fender STLT...
-
Page 11: Steering Assembly
REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 STEERING ASSEMBLY steering_pl.lt_59... - Page 12 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 STEERING ASSEMBLY PART DESCRIPTION 532 19 46-37 Wheel Steering 532 17 51-31 Axle Asm 532 16 98-40 Spindle Asm LH 532 16 98-39 Spindle Asm RH 532 12 49-31 Bearing Race Thrust Harden 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
- Page 13 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-kohler_43...
- Page 14 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 ENGINE PART DESCRIPTION 532 17 08-05 Control, Throttle/Choke 817 72 04-08 Screw, Hex Thd Cut 1/4-20 x 1/2 - - - - - - Engine, Kohler, (Order parts from engine manufacturer) No.
- Page 15 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 SEAT ASSEMBLY seat_lt.knob_18 PART DESCRIPTION 532 18 87-13 Seat 532 14 05-51 Bracket Pivot Seat 532 14 50-06 Clip Push-In 873 80 06-00 Nut Hex w/Ins. 3/8-16 unc 532 12 41-81 Spring Seat Cprsn 2 250 Blk Zi 817 00 06-16 Screw 3/8-16 x 1.5 SMGML...
- Page 16 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 MOWER LIFT PART DESCRIPTION 532 19 84-17 Washer Asm Inner Spring W/ Plunger 532 19 80-70 Shaft Asm. Lift 532 18 88-22 Pin Groove 812 00 00-02 E Ring #5133-62 819 21 16-21 Washer 21/32 x 1 x 21 Ga.
-
Page 17: Mower Deck Parts
REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 MOWER DECK 42_D_man-t-path_stlt_3... - Page 18 REPAIR PARTS TRACTOR - MODEL NO. LT2115A (96011018200), PRODUCT NO. 960 11 01-82 MOWER DECK PART DESCRIPTION 532 16 58-92 Deck Asm MWR 42"weldment 872 14 05-06 Bolt Rdhd Sqnk 5/16-18 unc x 3/4 532 13 80-17 Bracket Asm Fr Sway Bar 38/42 532 16 54-60 Bracket Asm Deck 42"sway Bar...
