Page 1: Parts Manual
Parts Manual ZM3816 BF / 966582001 Only for US and AUS/NZ Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. - Page 2 When you need spare parts or support in service questions, warranty issues, etc., please consult the following professional: This Parts Manual belongs to the machine with the Engine Transmission manufacturing number: Manufacturing Number The machine’s manufacturing number can be found on the printed plate affixed to the engine compartment.
-
Page 3: Table Of Contents
CONTENTS FRAME ..............4 WHEELS / TIRES ........... 14 ENGINE PLATE ............6 BRAKE / DECK LIFT ..........16 STEERING ............... 8 MOWER DECK / CUTTING DECK ......18 IGNITION ..............10 SEAT ..............20 HYDRAULIC PUMP / MOTOR ....... 12 DECALS .............. -
Page 4: Frame
FRAME... - Page 5 FRAME ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 525 454705 ..1 ..FRAME TUBE, LH BLK 22.. 539 102587 ..9 ..GROMMET, BUMPER 525 454905 ..1 ..FRAME TUBE, RH BLK 23.. 575 661305 ..1 ..PANEL, SEAT SUPPORT BLK 574 356405 ..1 ..
-
Page 6: Engine Plate
ENGINE PLATE Torque to 55-75 ft-lbs... - Page 7 ENGINE PLATE ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 532 120616 ..3 ..HHFS -16 x 1 THD FRM 11.. 539 115270 ..1 ..BUSHING, METAL 539 112899 ..3 ..NUT -18 HEX FLG NYLOC 12.. 574 355805 ..1 ..PLATE, ENGINE BLK 539 976937 ..1 ..
-
Page 8: Steering
STEERING... - Page 9 STEERING ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 539 120899 ..2 ..GRIP 16.. 539 108396 ..2 ..BOLT, HEX -18 x 2½ TPBLT 539 120160 ..2 ..LEVER, UPPER 17.. 539 990196 ..2 ..NUT, -18 HEX 539 117949 ..1 ..
-
Page 10: Ignition
IGNITION... - Page 11 IGNITION ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 539 120193 ..1 ..FENDER, RH 21.. 539 121486 ..1 ..HOSE, ¼ x 2 539 120192 ..1 ..FENDER, LH 22.. 539 110068 ..1 ..BATTERY CABLE, NEGATIVE 539 101080 ..4 ..
-
Page 12: Hydraulic Pump / Motor
HYDRAULIC PUMP / MOTOR... - Page 13 HYDRAULIC PUMP / MOTOR ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 539 112899 ..10 ..NUT -18 HEX FLG NYLOC 11.. 539 116689 ..2 ..ROD END COUPLER 539 120152 ..1 ..HYDRO, RH 12.. 539 991073 ..2 ..NUT -24 HEX JAM LH 539 120153 ..1 ..
-
Page 14: Wheels / Tires
WHEELS / TIRES 17 18... - Page 15 WHEELS / TIRES ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 516 001902 ..2 ..CASTER TIRE ASSY 13.. 539 112660 ..2 ..BEARING, FLANGED 539 976998 ..2 ..ZERK 14.. 539 115566 ..2 ..HHB -18 x 1 NYLOC 539 102484 ..4 ..
-
Page 16: Brake / Deck Lift
BRAKE / DECK LIFT 10 11... - Page 17 BRAKE / DECK LIFT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 525 580402 ..1 ..HANDLE, LIFT 15.. 539 101224 ..2 ..SPRING 574 356802 ..1 ..SHAFT, LIFT 16.. 539 990188 ..6 ..WASHER SAE FLT 525 580201 ..2 ..
-
Page 18: Mower Deck / Cutting Deck
MOWER DECK / CUTTING DECK... - Page 19 MOWER DECK / CUTTING DECK ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 576 414501 ..1 ..DECK w/ SAFETY DECALS 32.. 539 990629 ..1 ..HCS -16 x 2¼ 532 195185 ..2 ..ARM, SUSPENSION REAR 33.. 539 990122 ..2 ..
-
Page 20: Seat
SEAT... - Page 21 SEAT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 522 598901 ..1 ..SEAT 532 197661 ..1 ..HANDLE, SEAT SLIDE 574 356305 ..1 ..PLATE, SEAT BLK 532 198200 ..1 ..SPRING, SEAT SLIDE 539 132140 ..1 ..SWITCH, SEAT N/C 539 112899 ..2 ..
-
Page 22: Decals
DECALS... - Page 23 16.. 539 913010 ..1 ..DECAL, BLADE WARNING 539 109897 ..1 ..DECAL, SERVICE 17.. 575 926801 ..1 ..DECAL, McCULLOCH RT 539 105745 ..1 ..DECAL, BATTERY WARNING 18.. 575 926802 ..1 ..DECAL, McCULLOCH FT 539 108385 ..1 ..DECAL, DO NOT TOW 19..
- Page 24 P/N 115 359627R2 03/18/10...
