Jonsered BV32 Spare Parts Manual

Jonsered BV32 Spare Parts Manual

Jonsered bv32 blower spare parts
Hide thumbs Also See for BV32:
1
2
3
4
5
6
7

Advertisement

Table of Contents

BV32
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
S E R V I C E
Note !
To identify correct part number, check trimmer type at the
end of the serial number decal.
Example of serial number; 02134N401525-2
The -2 tells it is a type 2.
02 means it was build in 2002.
The 134 means it was built on the 134th day of that year.
The 401525 is the individual serial number for that particular
unit.
I0200082
IPL, BV32, 2002-08, 106 29 58-61
106 29 58-61

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BV32 and is the answer not in the manual?

Questions and answers

Related Manuals for Jonsered BV32

Summary of Contents for Jonsered BV32

  • Page 1 S E R V I C E I0200082 IPL, BV32, 2002-08, 106 29 58-61 BV32 Spare parts Note ! Ersatzteile To identify correct part number, check trimmer type at the end of the serial number decal. Pièces détachées Example of serial number; 02134N401525-2...
  • Page 2 PARTS LIST NO. MODEL: 530068885 -- 8/07/02 PARTS LIST REPLACES PAGE NO. BV32 Note: Illustrations may differ from actual models due to design changes 530068885--9/13/01 WARNING All repairs, adjustments and maintenance not de- scribed in the Operator’s Manual must be per-...
  • Page 3 PARTS LIST NO. MODEL: 530068885 -- 8/07/02 PARTS LIST REPLACES PAGE NO. BV32 Note: Illustrations may differ from actual models due to design changes 530068885--9/13/01 Part Part TYPE 1 TYPE 1 Description Description 530094712 Handle 530019158 Crankshaft Seal 530026994 Front Isolator...

  • Page 4: Parts List

    PARTS LIST NO. MODEL: 530068885 -- 8/07/02 PARTS LIST REPLACES PAGE NO. BV32 Note: Illustrations may differ from actual models due to design changes 530068885--9/13/01 32 40 WARNING All repairs, adjustments and maintenance not de- scribed in the Operator’s Manual must be per- formed by qualified ser- vice personnel.
  • Page 5 PARTS LIST NO. MODEL: 530068885 -- 8/07/02 PARTS LIST REPLACES PAGE NO. BV32 Note: Illustrations may differ from actual models due to design changes 530068885--9/13/01 Part Part TYPE 2 TYPE 2 Description Description 530010960 Assy--Connecting Rod 530069863 Kit--Handle 530069232 Kit--Rope...

  • Page 6: Carburetor Assembly

    PARTS LIST NO. MODEL: 530068885 -- 8/07/02 PARTS LIST REPLACES PAGE NO. BV32 Note: Illustrations may differ from actual models due to design changes 530068885--9/13/01 KEY NO. PART NO. DESCRIPTION 530095116 Collection Bag W/Strap 530095117 Collection Bag Elbow Tube 530069270 Vacuum Tube Ass’y...
  • Page 7 530068885 -- 8/07/02 PARTS LIST REPLACES PAGE NO. BV32 Note: Illustrations may differ from actual models due to design changes 530068885--9/13/01 LSERVICE REFERENCE 1. Starter Pulley -- When ordering a new starter pulley for your unit, please measure your existing pulley as shown by the dimensions in the illustrations below and order accordingly.
