Instruction Manual
FLOWMAX-120
Installation, operating, commissioning and maintenance instructions.
Water heaters for other than recreational vehicle installation
for model
Condensing water heater
116,000 BTU
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FLOWMAX Technologies FLOWMAX-120
Summary of Contents for FLOWMAX Technologies FLOWMAX-120
-
Page 1: Instruction Manual
Instruction Manual for model FLOWMAX-120 Condensing water heater 116,000 BTU WARNING If the information in these instructions is not followed exactly, a fire or explosion may result, causing property damage, personal injury or death. -Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other appliance. -
Page 3: Table Of Contents
CONTENTS Pages 1. General information 1.1 General warnings 1.2 Product conformity 2. Technical characteristics 2.1 Technical data 2.2 Dimensions 2.3 Internal parts of the water heater 2.4 Water circuit 2.5 Circulation pump head/flow graph 2.6 Printed circuit board – Technical characteristics 2.7 Control panel 3. - Page 4 CONTENTS Pages 6. Maintenance (authorized personnel) 6.1 General warnings 6.2 Maintenance 6.3 Water heater inspection 6.4 Accessing the water heater 6.5 Flushing out the primary side 6.6 Draining the central heating and domestic hot water system 6.7 Maintenance operations 6.8 Wiring diagrams 6.9 D.H.W Sensor Connection 6.10 Troubleshooting 6.11 Diagnostics...
-
Page 5: General Information
GENERAL INFORMATION 1. GENERAL INFORMATION 1.1 General warnings – Installation Read all safety warnings in the “Instruction Manual”. The additional safety issues outlined below must also be followed completely when installing this FLOWMAX Combination Water heater. Failure to remove or maintain the area free of combustible material, gasoline and other flammable liquids or vapours can result in severe personal injury, death or substantial property damage. - Page 6 GENERAL INFORMATION Never operate the heater unless it is vented to the outdoors and has adequate air supply to avoid risks of improper operation, fire, explosion or asphyxiation. DO NOT install this water heater directly on a carpeted floor. A fire hazard may result. The water heater shall be installed on a metal or wood panel extending beyond the full width and depth of the water heater by at least 3 inches (76.2mm) in any direction or, if the water heater is installed in an alcove or closet, the entire floor shall be covered by the panel.
- Page 7 GENERAL INFORMATION The “operating instructions” chapter of this manual must be read carefully as it provides information on the operation and the operating limits of the appliance. • After the removal of all the packaging, check that the appliance has not been damaged. In case of doubt, do not attempt to use the product but refer to the supplier.
- Page 8 GENERAL INFORMATION Important: Carbon Monoxide Detectors Many jurisdictions require the installation of carbon monoxide detectors in building where a side wall vented fuel burning appliance is installed. Installers must abide by local code requirements regarding the installation of CO detectors. The use of a certified carbon monoxide detector is recommended but not required by FLOWMAX.
- Page 9 GENERAL INFORMATION...
- Page 10 GENERAL INFORMATION...
- Page 11 GENERAL INFORMATION...
- Page 12 GENERAL INFORMATION...
-
Page 13: Product Conformity
FLOWMAX Technologies will not be held responsible for any misinterpretation of this manual resulting from the inaccurate translation of same. FLOWMAX Technologies will not be held responsible for the consequences in the case of non-observance of the instructions contained in this manual or in the case where actions not specifically described herein... -
Page 14: Technical Characteristics
TECHNICAL CHARACTERISTCS 2. TECHNICAL CHARACTERISTICS 2.1 Technical data Model FLOWMAX - 120 Heat Input max kW - BTU/hr 34-116013 kW - BTU/hr 10-34121 Heat Input min Heat Output max (122/86° F) kW - BTU/hr 36.64-123670 Heat Output max - 167/140° F kW - BTU/hr 33.42-116724 Heat Output min - 167/140°... -
Page 15: Dimensions
TECHNICAL CHARACTERISTCS 2.2 Dimensions 12.3 12.2 LEGEND HEATING INLET Ø 3/4 " HEATING OUTLET Ø 3/4 " Ø 1/2 " Ø 1/2 COLD WATER INLET " Ø 1/2 HOT WATER OUTLET " CONDENSATE DRAIN Ø 0.98 in... -
Page 16: Internal Parts Of The Water Heater
TECHNICAL CHARACTERISTCS 2.3 Internal parts of the water heater LEGEND PRIMARY CONDENSING HEAT EXCHANGER PREMIX BURNER UNIT (GAS MANIFOLD + BURNER) CONDENSATE DRAIN PIPE IONISATION ELECTRODE IGNITION ELECTRODE VENTURI IGNITION TRANSFORMER ELECTRONIC GAS VALVE " 10. SAFETY VALVE 3/4 11. AUTOMATIC AIR VENT VALVE 12. -
Page 17: Water Circuit
TECHNICAL CHARACTERISTCS 2.4 Water circuit LEGEND PRIMARY CONDENSING HEAT EXCHANGER PREMIX BURNER UNIT (GAS MANIFOLD+BURNER) CONDENSATE DRAIN PIPE IONISATION ELECTRODE IGNITION ELECTRODE VENTURI IGNITION TRANSFORMER ELECTRONIC GAS VALVE " 10. SAFETY VALVE 3/4 11. AUTOMATIC AIR VENT VALVE 12. HEATING SAFETY THERMOSTAT 13. -
Page 18: Circulation Pump Head/Flow Graph
TECHNICAL CHARACTERISTCS 2.5 Circulation pump head/flow graph Water flow (US gpm) Pump head I, II, III Pump speed Boiler losses... -
Page 19: Printed Circuit Board - Technical Characteristics
TECHNICAL CHARACTERISTCS ® 2.6 DIGITECH printed circuit board – SM20021 Technical characteristics Adjustments possible by service personnel only Standard (86-167° F) / reduced (77-104° F) central heating temperature • Water hammer prevention function • Central Heating timer - (adjustable from 0 to 7,5 minutes) •... -
Page 20: Installation (Authorized Personnel)
INSTALLATION INSTRUCTIONS 3. INSTALLATION (authorized personnel) 3.1 Reference standard Install in accordance with local building and electrical codes. This appliance meets the requirements of: Standard(s) – American National Standard/CSA Standard for Gas Water Heaters Volume III, Storage Water Heaters With Input Ratings Above 75,000 Btu per Hour, Circulating and Instantaneous. -
Page 21: Unpacking
INSTALLATION INSTRUCTIONS 3.2 Unpacking ■ The materials (cardboard) used for packing the appliance are fully recyclable. ■ It is recommended that the packing material is only removed prior to installing the water heater. The manufacturer will not be held responsible for damage caused by incorrect storage of the product. ■... -
Page 22: Installation Water Heater
INSTALLATION INSTRUCTIONS 3.3 Installing the water heater appliance must installed ■ exclusively on a flat vertical solid wall capable of supporting its weight. The water heater should be fitted within ■ the building unless otherwise protected by a suitable enclosure i.e. garage or outhouse. -
Page 23: Water Connections
INSTALLATION INSTRUCTIONS 3.4 Water connections In order to safeguard the heat exchanger and circulation pump, especially in case water heater replacement, recommended that the system is hot- flushed remove impurities (especially oil and grease) from the pipes and radiators. Make sure that the domestic water and central heating pipes are not used to ground the electrical system. -
Page 24: Domestic Hot Water Circuit/Hard Water Warning/ Condensate Drain
INSTALLATION INSTRUCTIONS 3.5 Domestic hot water circuit/ Condensate Drain Warning/ Hard Water If this water heater is installed in an application where the supply water is hard, it must be treated with either a water softener and filtration, which removes the hardness, or by using sequestering agents that reduce the amount of scale deposits. -
Page 25: Space Heating
INSTALLATION INSTRUCTIONS maximum condensate discharge of 2 gpm from the water heater. The end drain pipe must not be submerged in water or blocked in any way. The condensate pump must be installed with an overflow safety switch that detects downstream clogs and ■... -
Page 26: Schematic Of Piping Installation
INSTALLATION INSTRUCTIONS 3.6 Schematic of Piping Installation... - Page 27 INSTALLATION INSTRUCTIONS...
-
Page 28: Gas Connection
INSTALLATION INSTRUCTIONS 3.7 Gas Connection 3.7.1 Gas Piping Guidelines Follow all local codes and/or the most recent edition of the National Fuel Gas Code (ANSI Z223.1/NFPA 54) in the USA or the Natural Gas and Propane Installation Code in Canada (CAN/CSA B149.1). 3.7.2 Gas Supply Lines Pressures The minimum and maximum inlet gas pressures are Natural Gas Min. -
Page 29: Electrical Connections
INSTALLATION INSTRUCTIONS 3.8 Electrical connections 3.8.1 General warnings Follow the electrical code requirements of the local authority having jurisdiction. In the absence of such requirements, follow the latest edition of the National Electrical Code (NFPA 70) in the U.S. or the latest edition of CGA C22.1 Canadian Electrical Code –... - Page 30 INSTALLATION INSTRUCTIONS ■ The power supply cable must be replaced by a qualified electrician. If the cable is damaged in any way, switch off the appliance and have the cable replaced by a suitably qualified electrician; When using an electrical appliance, a few fundamental rules must be observed: Do not touch the appliance with damp or wet parts of the body or when barefoot.
- Page 31 INSTALLATION INSTRUCTIONS 3.8.3 Remote control connection Connect the power supply to the terminal board inside the control panel as follows: a. Switch off the power supply at the main switch. b. Remove the front case panel of the water heater. c.
-
Page 32: Venting Connections
INSTALLATION INSTRUCTIONS 3.9 Venting Improper venting of combination water heater can result in excessive levels of carbon monoxide which can result in severe personal injury or death. This combination water heater must be vented in accordance with the “Venting of Equipment” section of the latest edition of the ANSI Z223.1 / NFPA 54 Natural Gas Code and/or the “Venting systems and air supply for appliances”... - Page 33 INSTALLATION INSTRUCTIONS Intake Vent Pipe Materials PVC, CPVC or ULC S636 pipe and fittings and ABS pipe and fittings can be used for combustion air intake • on FLOWMAX products. Transition cement must be used if ABS pipe is connected to the PVC appliance adaptors. •...
- Page 34 INSTALLATION INSTRUCTIONS...
- Page 35 INSTALLATION INSTRUCTIONS...
- Page 36 INSTALLATION INSTRUCTIONS...
- Page 37 INSTALLATION INSTRUCTIONS...
- Page 38 INSTALLATION INSTRUCTIONS...
-
Page 39: Commissioning The Appliance (Authorized Personnel)
INSTALLATION INSTRUCTIONS 4. COMMISSIONING THE APPLIANCE 4.1 General warnings The following operations must be carried out by professionally qualified personnel, registered in accordance with current legislation. The water heater leaves the factory pre-set and tested for burning either natural Gas or PROPANE. Nevertheless, when starting the water heater for the first time, make sure that the information on the rating plate corresponds to the type of gas being supplied to the water heater. -
Page 40: Filling The System
INSTALLATION INSTRUCTIONS 4.2 Filling the system Check the properties of the water supply and install the appropriate treatment devices if the mains water has a hardness rating more than 14.5 gpg (250 mg/L) i order AIR VENT VALVE to prevent scaling and eventual damage to the D.H.W AIR VENT VALVE PLUG heat exchanger. -
Page 41: Flushing The System
INSTALLATION INSTRUCTIONS 4.3 Flushing the system Failure to flush and add inhibitor to the system will invalidate the appliance operation. All systems must be thoroughly drained and flushed out using additives – corrosion inhibitors and flushing agents/descalers. All flushing must be done for new and retrofit installs. Warning: Failure to clean the system and add adequate inhibitor invalidates the warranty. -
Page 42: Starting Up The Water Heater
INSTALLATION INSTRUCTIONS 4.5 Starting up the water heater Once the system has been filled, proceed as follows: Table n° 1 • Check that the exhaust vent is free of obstructions and correctly connected to Gas type the water heater; Natural Gas - G20 9.18 •... -
Page 43: Parameters Table
REGULATION INSTRUCTIONS 5. REGULATING THE APPLIANCE 5.1 Parameters table PARAMETER PARAMETER N° TYPE OF OPERATION FUNCTION VALUE Instantaneous (95-140° F) Water heater with storage tank Selects the type of water heater B. w/storage tank Comfort (+45° F) D.H.W. Temperature 95-160 ° F Natural gas Selects the type of gas Sets the central heating... -
Page 44: Setting The Parameters
REGULATION INSTRUCTIONS 5.2 Setting the parameters To modify the preset values of the parameters reported in the previous table, open the parameter settings menu as follows: 1. Place the On/Off switch in the OFF position. O FF 120 60 Hz 2. - Page 45 REGULATION INSTRUCTIONS 1 – T ARAMETER YPE OF WATER HEATER 6. Use buttons ‘+’ and ‘-‘ to modify the value of the parameter: 120 60 Hz 00 = Instantaneous water heater 01 = Storage water heater 02 = Storage water heater ‘comfort’ (+ 45 ° F) 03 = D.H.W.
- Page 46 REGULATION INSTRUCTIONS 4 – C ARAMETER ENTRAL HEATING PUMP 6. Use buttons ‘+’ and ‘-‘ to modify the value of the parameter: 120 60 Hz 00 = standard (3” overrun) 01 = permanent (always running) 7. Press and release button ‘S’ to confirm. The parameter number (4) will appear on the display.
- Page 47 REGULATION INSTRUCTIONS 7 – C ARAMETER ENTRAL HEATING PUMP OVERRUN TIMER 6. Use buttons ‘+’ and ‘-‘ to modify the value of the parameter within 120 60 Hz prescribed limits 00 = 0 x 5” = 0” 90 = 90 x 5” = 450” (7.5 min) The default value is 36 = 180”...
- Page 48 REGULATION INSTRUCTIONS 13 – D.H.W ARAMETER PRIORITY 6. Use buttons ‘+’ and ‘-‘ to modify the value of the parameter: 120 60 Hz 00 = off 01 = on (default = 120”) 7. Press and release button ‘S’ to confirm. The parameter number (13) will appear on the display.
- Page 49 REGULATION INSTRUCTIONS 17 – M ARAMETER INIMUM PEED ETTING 6. Use buttons ‘+’ o ‘-’ to modify the value of the parameter between: 120 60 Hz min = 33 Hz ; max = value of parameter 18 The default value is : - 55 Hz for Natural Gas;...
- Page 50 REGULATION INSTRUCTIONS 21 – I ARAMETER GNITION EQUENCE ETTING 1 1 0 6. Use buttons ‘+’ o ‘-’ to modify the value of the parameter 120 60 Hz between: min = value of parameter 17; max = value of parameter 18. The default value is: - 110 Hz for Natural Gas;...
-
Page 51: Gas Data
REGULATION INSTRUCTIONS 5.3 Gas data 5.3.1 Technical data tables Table no.1 - CO Values Gas type Natural gas - G20 9.18 Liquid Propane Gas - G 31 10.3 Table no.2 - Frequency Gas type Minimum (Hz) Maximum (Hz) Natural gas - G20 Liquid Propane Gas - G 31 NATURAL GAS G20 LIQUID PROPANE GAS G31... -
Page 52: Maintenance (Authorized Personnel)
MAINTENANCE INSTRUCTIONS 6. MAINTENANCE (authorized personnel) 6.1 General Warnings All maintenance operations must be carried out by professionally qualified personnel, authorized by FLOWMAX. The frequency of water heater maintenance is recommended to be carried out once a year. In order to guarantee the long life of the appliance and in accordance with the current gas safety regulations, only use original spare parts Before carrying out any type of maintenance operation, disconnect the appliance from the electrical supply and shut off the gas valve. - Page 53 MAINTENANCE INSTRUCTIONS ■ Check that the seal of the room-sealed chamber is undamaged and positioned correctly. ■ Check the primary heat exchanger and clean if necessary. ■ Check the maximum and minimum modulation pressures and the modulation itself. ■ Check the condition and operation of the ignition and gas safety systems. If necessary, remove and clean the scaling from the ignition and flame detection electrodes, paying particular attention to replace them at the correct distance from the burner.
-
Page 54: Accessing The Water Heater
MAINTENANCE INSTRUCTIONS 6.4 Accessing the water heater All maintenance operations require one or more of the water heater casing panels to be removed. The side panels can only be removed after the front panel has been removed. Front panel: Remove the fixing screws at the lower edge of the front panel. -
Page 55: Draining The Central Heating And Domestic Hot Water System
MAINTENANCE INSTRUCTIONS 6.6 Draining the central heating system If the need arises to drain the system, this can be done as follows: Switch the system to “WINTER” mode and ignite • the water heater. Switch off the power supply to the water heater. •... -
Page 56: Maintenance Operations
MAINTENANCE INSTRUCTIONS 6.7 Maintenance operations primary heat exchanger Before carrying out any cleaning or part replacement operations, ALWAYS turn off the ELECTRICITY, WATER and GAS supplies to the water heater. premix burner unit FLOWMAX will not be held responsible for damage to any of the water heater’s components caused by non-compliance with this instruction. - Page 57 MAINTENANCE INSTRUCTIONS Cleaning the D.H.W heat exchanger (see fig. 1) D.H.W. heat exchanger • Close the shut-off valve and drain the domestic hot water circuit and central heating circuit of the water heater; • Use a 4 mm Allen key to unscrew the four screws securing the heat exchanger to the multiplex unit;...
- Page 58 MAINTENANCE INSTRUCTIONS Safety thermostat (see fig. 1) • Disconnect the connecting wire; • Unscrew fixing screws remove thermostat; • Replace the thermostat and re-assemble the components following the above procedure in reverse order; • Switch on the electricity, water and gas supplies and restart the appliance.
- Page 59 MAINTENANCE INSTRUCTIONS Electric fan (see fig. 1) • Remove and dismantle the entire burner unit (see venturi 6.6.1 “Cleaning the burner unit”). • Use an 8 mm wrench to unscrew the four nuts securing the electric fan to the gas manifold and then remove the electric fan, noting the positions of the washer and diaphragm.
- Page 60 MAINTENANCE INSTRUCTIONS Circulating pump (motor body) (see fig. 1) • Close the shut-off valves and drain the central heating circuit of the water heater; circulating Use a 5 mm Allen key to unscrew the four screws pump • securing the motor body to the impeller body; •...
- Page 61 MAINTENANCE INSTRUCTIONS Modulation circuit board (see fig. 1-2) • Open the control panel (see 6.4 “Accessing the water heater”); electric fan circuit board • Disconnect all the connectors, remove the regulating knobs, unscrew the four fixing screws and modulation circuit board remove the modulation circuit board;...
- Page 62 MAINTENANCE INSTRUCTIONS Primary heat exchanger (see fig. 1) • Close the shut-off valves and drain the central heating circuit of the water heater; primary heat flue connection exchanger • Switch off the power and gas supply to the water chamber heater;...
-
Page 63: Wiring Diagrams
MAINTENANCE INSTRUCTIONS 6.8 Wiring diagrams PRINTED CIRCUIT BOARD KOND DT - SK11003 COD. 76702LA PRINTED CIRCUIT BOARD DIGITECH - SM20021 EXHAUST FAN type RG 128 IG: Main Switch PA: Air Pressure switch TS: Safety thermostat fusibile 2A brown TF: Thermo Fuse 216°F TF max: Thermo Fuse 320°... - Page 64 MAINTENANCE INSTRUCTIONS Connecting the room thermostat (Option) Connect the wires to the terminal board inside the instrument panel as follows: (Example with WEEK digital weekly chronostat): a. switch off the power supply at the main switch. b. remove the front case panel of the water heater. c.
- Page 65 MAINTENANCE INSTRUCTIONS Connecting the remote controller the outside temperature sensor (option) Connect the wires to the terminal board inside the instrument panel as follows: a. switch off the power supply at the main Outside temperature switch. sensor (option) b. remove the front case panel of the water heater.
- Page 66 MAINTENANCE INSTRUCTIONS Remote control and zone valves wiring For the installation of a zone valve p.c.b, it is necessary to access the main p.c.b for electrical connection (see 6.3 “Accessing the water heater” ) and to activate the parameter no. 16 (see 5.1 “Parameters table”).
- Page 67 MAINTENANCE INSTRUCTIONS Remote control, zone valves and telephone control wirings...
- Page 68 MAINTENANCE INSTRUCTIONS Regulating the Flow temperature in accordance with the outdoor temperature The outdoor sensor has to be connected directly to circuit board SM 20021. The sensor can thus be managed in one of two ways: In case of remote controller + outdoor temperature sensor installation, the climatic compensation curve is set by •...
-
Page 69: Sensor Connection
MAINTENANCE INSTRUCTIONS 6.9 D.H.W. Sensor connection Fig. 1 PRINTED CIRCUIT BOARD CVI-M SM20021 HOT WATER SENSOR LEAD MAX. LENGHT 8 mt. REMOTE DHW CYLINDER FLOW FILLING LOOP REMOTE DHW CYLINDER RETURN... -
Page 70: Troubleshooting
INSTALLATION INSTRUCTIONS 6.10 Troubleshooting ERROR PROBLEM POSSIBLE CAUSE REMEDY CODE WITH NO IGNITION CHECK MAINS SUPPLY. NO GAS. IGNITION ELECTRODE BROKEN OR GROUNDED. REPLACE PART. GAS VALVE MALFUNCTION REPLACE PART REGULATE MECHANICAL MECHANICAL MINIMUM ADJUSTMENT (ON GAS MINIMUM OR SLOW IGNITION. VALVE) SET TOO LOW OR SLOW IGNITION ADJUSTMENT SET TOO LOW. -
Page 71: Diagnostics
INSTALLATION INSTRUCTIONS 6.11 Diagnostics ■ Error codes: Ionization Lock Out Safety Thermostat Tripped / Air Pressure Switch Tripped Flue Gas Thermostat Tripped Low Water Pressure Alarm 120 60 Hz Heating Sensor Malfunction D.H.W Sensor Malfunction D.H.W Storage Cylinder Sensor Malfunction Air Pressure Switch Tripped Electric Fan Malfunction Parameter Programming Request... - Page 72 FLOW CHART...
- Page 73 FLOW CHART...
- Page 74 FLOW CHART...
- Page 75 FLOW CHART...
- Page 76 FLOW CHART...
- Page 77 FLOW CHART...
- Page 78 FLOW CHART...
- Page 79 FLOW CHART...
- Page 80 FLOW CHART...
-
Page 81: Parts List
PARTS LIST 6.12 Parts List / Available from FLOWMAX Main components CODE DESCRIPTION 20086LA ISOTERMIQUE 5+1 COMBUSTION CHAMBER BACK PANEL 21044LA PRIMARY EXCHANGER 5+1 PREMIX 0.70 24060LA PUMP STAR S 21 KU RSL-PL6 UL/CSA 25-00274 PUMP UPS 15-58 CACAO ETL MOLEX-PN98282128 25-00045 EXPANSION VESSEL 6 lt. - Page 82 PARTS LIST Multiplex FLOWMAX CODE DESCRIPTION 30-000-15 PLATE EXCHANGER 28 P 24060LA PUMP STAR S 21 KU RSL-PL6 UL/CSA 25-00274 PUMP UPS 15-58 CACAO ETL MOLEX-PN98282128 26127LA PUMP MANIFOLD – M.PLEX 2006 26134LA D.H.W. OUTLET CONNECTION - INSTANTANEOUS M.PLEX 06 26283LA D.COLD WATER/HTG FLOW CONNECTION W/N-R.V.
-
Page 83: Warranty
FLOWMAX Technologies Inc. Cost of returning the goods to FLOWMAX Technologies Inc. is by others. All warranty parts are to be prepaid by the customer. No warranty will be in effect until the equipment is paid for in full. Warranty on all equipment sold to customer may be suspended, at FLOWMAX Technologies Inc.’s discretion, until the customer’s account is in good standing. - Page 84 Terms and Conditions of Sale E-mail: info@flowmaxtechnologies.com 19. The warranty cannot be considered as a guarantee of workmanship of an installer connected with the installation of the condensing water heater or as imposing a liability of any nature for unsatisfactory performance as a result of faulty workmanship in the installation, which liability is expressly disclaimed.
-
Page 85: Warranty Registration Form
Date of Purchase _________________________ Date of Start up_________________________ Installers Gas Certification Number and Name________________________________________ Purchased From: Company Name_________________________________________________________________ Contact Name__________________________________________________________________ Signature______________________________ Date__________________________________ To ensure your warranty protection, please complete and return this form to FLOWMAX Technologies Inc. attention Product Registration. -
Page 86: Warranty Part Request Form
Warranty Parts Request Form E-mail: info@flowmaxtechnologies.com Please complete the following information and return it with the part request Sold To: Address Phone # Fax # Item Requested Water Heater Model No. Water Heater Serial No. Date of Purchase Date of Start-Up Comments Credit will be issued upon receipt of completed form and inspection of defective part. - Page 88 FLOWMAX Technologies 209 Citation Drive, unit 5 & 6 Concord, Ontario, L4K 2Y8 Tel; 905-264-1414 Fax; 905-264-1147 E-mail: info@flowmaxtechnologies.com Web Site: www.flowmaxtechnologies.com...
