Summary of Contents for Phonic Sound Ambassador 75 Deluxe

  • Page 1 Sound Ambassador 75 Deluxe Sound Ambassador 120 Deluxe Wireless Portable Sound System...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.
  • Page 3: Table Of Contents

    BASIC SETUP...........................5 CONNECTIONS AND SETTINGS....................6 WIRELESS MICROPHONE RECEIVER..................8 CD PLAYER............................8 TAPE PLAYER..........................9 OTHER IMPORTANT FEATURES....................10 APPLICATION..........................11 SPECIFICATIONS...........................12 DIMENSIONS..........................14 BLOCK DIAGRAM..........................15 Phonic reserves the right to improve or alter any information suppied within this document without prior notice. V1.0 NOV 23, 2005...
  • Page 4: Introduction

    Introduction Features We at Phonic would like to congratulate you on your All-in-one portable sound system with  purchase of our Sound Ambassador 75 Deluxe or retractable trolley and wheels 120 Deluxe wireless portable sound system. This 10" 2-way speaker system (120 Watts @ ...
  • Page 5: Optional Accessories

    Optional Accessories Basic Setup Ensure all power is turned off on the Sound UM30: UHF (16-ch) Wireless Handheld  Ambassador Deluxe. System including a HT-100 transmitter and All level controls should be set at the lowest UM-R10 receiver level to ensure no sound is inadvertently sent through the outputs when the device UM40: (16-ch)
  • Page 6: Connections And Settings

    This 3-pin XLR microphone jack and 1/4” Phone information on purchasing the wireless microphone Jack are for the addition of low and high impedance kit, please contact your nearest Phonic dealer. For microphones to the Sound Ambassador Deluxe. more information, please consult page 8.
  • Page 7 13. Power Indicators 8. Master EQ The lights just to the left of the DC input allow users to see the status of the battery. Batt. Full, This 2-band EQ allows users to adjust the high and illuminates when the Battery is at full capacity, and low frequency sounds of their main signal at 80 Hz Charging flashes when the internal battery is in the and 10 kHz, respectively.
  • Page 8: Wireless Microphone Receiver

    Wireless Microphone Receiver CD Player 1. Frequency Select – Use this to select the 1. Program – Push this button to enter a track frequency at which the wireless module will into your program memory, to play the CD in receive signals.
  • Page 9: Tape Player

    Tape Player 1. Tape Deck – when the tape deck has been 7. Rewind – Rewind the tape using this button. opened, insert a cassette (magnetic tape 8. Reverse Play – Play the “other side” of your down) here. tape, using this button. 2.
  • Page 10: Other Important Features

    Opening the Battery Cover Deluxe making stacking multiple devices a whole lot easier. Remove the screws to open the battery cover. If a replacement battery is necessary, please contact your nearest Phonic dealer. Tripod Stand Socket Flip Sound Abassador over.
  • Page 11: Application

    APPLICATION MICROPHONE SOUND MP3 PLAYER AMBASSADOR LINK MULTIPLE SOUND AMBASSADORS IN A SERIAL CHAIN SOUND SOUND AMBASSADOR AMBASSADOR Sound Ambassador 75/120 Deluxe...
  • Page 12: Specifications

    SPECIFICATIONS Sound Ambassador 75 Deluxe Sound Ambassador 120 Deluxe Woofer 10” 10” Tweeter 1” driver 1” driver Amplifier (watts), 75 Watt @ 4 ohm; 120 Watt @ 4 ohm; 50 Watt @ 8 ohm 75 Watt @ 8 ohms 1x XLR mic, 1x 1/4” mic, 1x1/4”...
  • Page 13 Recharging time 8 hours 8 hours Battery life 4-8 hours continuous use 4-8 hours continuous use CD player module, MP3 CD player module, MP3 Optional Recorder module, Audio Recorder module, Audio Cassette accessories Cassette Recorder, 2x UHF Recorder, 2x UHF wireless mics wireless mics Safety Certificate CETL, CE CETL, CE...
  • Page 14: Dimensions

    DIMENSIONS 612/24 300/11.8 612/24 350/13.8 300/11.8 350/13.8 Dimensions are shown in mm/inches Sound Ambassador 75/120 Deluxe...
  • Page 15: Block Diagram

    BLOCK DIAGRAM Sound Ambassador 75/120 Deluxe...
  • Page 16 Phonic, at its option, shall repair or replace the defective unit covered by this warranty. Please retain the dated sales receipt as evidence of the date of purchase.
