- Page 1 SMARTMAN 300A SMARTMAN 300A User's Manual Manual de Usuario SMARTMAN 700A...
- Page 2 SMARTMAN 300A SMARTMAN 700A ALL-IN-ONE INTELLIGENT AUDIO SYSTEMS SISTEMAS INTELIGENTES DE AUDIO TODO-EN-UNO ENGLISH........I ESPAÑOL..
-
Page 3: Table Of Contents
USER'S MANUAL CONTENTS INTRODUCTION..............1 FEATURES................1 SYSTEM OVERVIEW.............2 SETTING..............3 SPECIFICATIONS..............4 APPENDIX DIMENSIONS..............1 Phonic preserves the right to improve or alter any information within this document without prior notice. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS The apparatus shall not be exposed to dripping or splashing and that no objects with liquids, such as vases, shall be placed on the apparatus. The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable. -
Page 5: Introduction
Phonic. Everything, from the cone pulp formula and the curvature of the tweeter’s titanium membrane to the characteristic of the magnetic field, is uniquely Phonic, uniquely Smartman. Smartman’s state-of-the-art woofer has a distinctly high BL force factor and a long-throw extension which produce marvelously deep and defined bass traditionally unattainable in small enclosures. -
Page 6: System Overview
SYSTEM OVERVIEW Smartman 300A and 700A share the same connection interface and controls. LEVEL Knob Adjust the input level. PEAK Indicator This indicator lights when the input signal hits the peak. Combo Input Connector This connector accepts both XLR and ¼” phone jack connectors for either balanced or unbalanced connectors. -
Page 7: Setup Example
Distance Distance Distance Shorter than +44.5ms +44.5ms +44.5ms Smartman 703A Smartman 700D Smartman 700A Smartman 700A Smartman 700D Smartman 700A Shorter than +44.5ms +44.5ms +44.5ms Delay Offset +89ms Delay Offset Delay Offset 222.5 133.5 44.5 SMARTMAN 300A / SMARTMAN 700A... -
Page 8: Specifications
3 PU Handles 418 x 292 x 252 mm 635 x 375 x 372.5 mm Dimensions (HxWxD) (16.5'' x 11.5'' x 9.9'') (25” x 14.8” x 14.7”) Net Weight 9.5 kg (21 lbs) 19 kg (41.9 lbs) SMARTMAN 300A / SMARTMAN 700A... -
Page 9: Service And Repair
Phonic, at its option, shall repair or replace the defective unit covered by this warranty. Please retain the dated sales receipt as evidence of the date of purchase. -
Page 10: Manual Del Usuario
MANUAL DEL USUARIO CONTENIDO INTRODUCCIÓN..................1 CARACTERÍSTICAS...................1 RESUMEN DEL SISTEMA............3 EJEMPLO CONFIGURACIÓN............4 ESPECIFICACIONES................16 APÉNDICE DIMENSIONES.................1 Phonic se reserva el derecho de mejorar o alterar cualquier información dentro de este documento, sin previo aviso. SMARTMAN 300A / SMARTMAN 700A... - Page 11 SMARTMAN 300A / SMARTMAN 700A...
-
Page 12: Introducción
Phonic. Todo, desde la pulpa de cono, a la curvatura de la membrana de titanio del tweeter, a las características del campo magnético, todo es de Phonic y solo para el Smartman. El Woofer del Smartman representa una verdadera punta de la tecnología;... -
Page 13: Resumen Del Sistema
RESUMEN DEL SISTEMA Smartman 300A y 700A comparten la misma interfaz y los mismos controles de conexión. Perillas de Ajuste de Nivel Ajustan el nivel de entrada. Indicador de Máximo/pico. Este indicador se ilumina cuando la señal de entrada alcanza el máximo nivel. -
Page 14: Ejemplo Configuración
Distancia Mas corto que +44.5ms +44.5ms +44.5ms Smartman 703A Smartman 700D Smartman 700A Smartman 700A Smartman 700D Smartman 700A Mas corto que +44.5ms +44.5ms +44.5ms Retraso +89ms Compensado Retraso Compensado Retraso Compensado 222.5 133.5 44.5 SMARTMAN 300A / SMARTMAN 700A... -
Page 15: Especificaciones
418 x 292 x 252 mm 635 x 375 x 372.5 mm Dimensiones (HxWxD) (16,5 '' x 11,5 '' x 9.9 '') (25” x 14.8” x 14.7”) Peso Neto 9.5 kg (21 libras) 19 kg (41.9 lbs) SMARTMAN 300A / SMARTMAN 700A... - Page 16 Phonic, a su propia opinión, reparará o cambiará la unidad defectuosa que se encuentra dentro de esta garantía.
- Page 17 292 / 11.5 350 / 13.8 333 / 13.1 553 / 21.8 350 / 13.8 333 / 13.1 SMARTMAN 300A Measurements are shown in mm/inches 553 / 21.8 Todas las medidas están mostradas en mm/pulgadas. SMARTMAN 300A / SMARTMAN 700A...
