VTech Safe & Sound DM111 User Manual

User's manual
DM111/DM111-2
TM
Safe & Sound
Digital audio monitor
POWER / LINK
Congratulations
on purchasing your new VTech product.
Before using this product, please read
Important safety instructions in this manual.
For support, shopping, and everything new
at VTech, visit our website at
www.vtechcanada.com.
Connect the monitor unit
Power outlet not
controlled by a
wall switch
Power adapter
Connect the portable unit
Power outlet not
controlled by a
wall switch
Power adapter
Before use
You may test the audio monitor before initial
use, and at regular times thereafter.
To test your audio monitor:
1. Place the portable unit and the monitor unit
in the same room to test the product.
2. Press and hold on the monitor unit until
the POWER light turns off.
3. Press and hold on the monitor unit again
until the POWER light turns on.
4. Press and hold on the portable unit the
POWER/LINK light turns off.
5. Press and hold on the portable unit again
until the POWER/LINK light turns on.
• If the portable unit is not linked to
the monitor unit, the POWER/LINK
on the portable unit will flash. Move the
portable unit closer to the monit or unit
(but not less than 1 meter / 3 feet).
Important safety instructions
When using your equipment, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury, including the following:
1. Follow all warnings and instructions marked on
the product.
2. Adult setup is required.
3. This product is intended as an aid. It is not
a substitute for responsible and proper adult
supervision and should not be used as such.
4. This product is not intended for use as a
medical monitor.
5. Do not use this product near water. For example,
do not use it next to a bath tub, wash bowl,
kitchen sink, laundry tub or swimming pool, or in
a wet basement or shower.
6. CAUTION: Use only alkaline batteries (not
included). There may be a risk of explosion if
a wrong type of battery is used for the portable
unit. Do not dispose of batteries in a fire. They
may explode. Check with local codes for possible
special disposal instructions.
7. Do not open or mutilate the batteries. Released
electrolyte is corrosive and may cause burns or
injury to the eyes or skin. The electrolyte may be
toxic if swallowed.
8. Exercise care in handling the batteries in order not
to create a short circuit with conductive materials.
9. Observe proper polarity orientation between the
batteries and metallic contacts.
10. Use only the adapters included with this product.
Incorrect adapter polarity or voltage can seriously
damage the product.
Monitor unit power adapter: Input 117V AC 60
Hz; output: 6V AC 300 mA
Portable unit power adapter: Input 100-120V AC
60 Hz; output: 6V DC 400 mA
11. The power adapters are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
if it is plugged into a ceiling, under-the-table or
cabinet outlet.
12. Unplug this product from the wall outlet before
cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
13. Unplug the power cords before replacing the batteres.
14. Do not cut off the adapters to replace them with
other plugs, as this causes a hazardous situation.
15. Do not allow anything to rest on the power cords.
Do not install this product where the cords may
be walked on or crimped.
16. This product should be operated only from the type
of power source indicated on the marking label. If
you are not sure of the type of power supply in your
home, consult your dealer or local power company.
17. Do not overload wall outlets or use an extension cord.
18. Do not place this product on an unstable table,
shelf, stand or other unstable surfaces.
Positioning the audio monitor
Place the portable unit within the operating
range of the monitor unit. We recommend the
portable unit is at least 1 meter (3 feet) away
from the monitor unit to avoid audio feedback.
If you still experience audio feedback, move the
portable unit and the monitor unit farther apart.
At least 1 meter (3 feet)
Operating range
The operating range of the audio monitor
is up to 300 meters (1000 feet) outdoors
or 50 meters (160 feet) indoors. The actual
operating range may vary depending on
the environmental conditions, and other
interferences such as walls, doors, and other
obstructions.
Overview
Monitor unit overview
1
2
3
1 – POWER light
2 –
(On/off)
Press and hold to turn on or off the
monitor unit.
3 – Microphone
light
4 – Power jack
19. This product should not be placed in any area
where proper ventilation is not provided. Slots
and openings in the back or bottom of this
product are provided for ventilation. To protect
them from overheating, these openings must
not be blocked by placing the product on a soft
surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or
heat register.
20. Never push objects of any kind into this product
through the slots because they may touch
dangerous voltage points or create a short circuit.
Never spill liquid of any kind on the product.
21. To prevent fire or shock hazard, do not expose
this product to water or any type of moisture.
22. To reduce the risk of electric shock, do not
disassemble this product, but take it to an authorized
service facility. Opening or removing parts of the
product other than specified access doors may
expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock
when the product is subsequently used.
23. You should test the sound reception every time you
turn on the units or move one of the components.
24. Periodically examine all components for damage.
25. Be aware of possible loss of privacy while using
public airwaves. Conversations may be picked
up by other nursery monitors, cordless phones,
scanners, etc.
26. Children should be supervised to ensure that
they do not play with the product.
27. The product is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
SAVE THESE INSTRUCTIONS
Cautions
1. Use and store the product at a temperature
between 32 F and 104 F.
o o
2. Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to
a heating source.
3. The batteries should not be exposed to excessive
heat such as bright sunshine or fire.
4. Make sure the monitor unit and the adapter cord
are always out of reach of children, at least 1
meter (3 feet) away from the baby or crib, to avoid
a possible strangulation hazard.
5. Other electronic products may cause
interference with your audio monitor. Try
installing your audio monitor as far away
from these electronic devices as possible:
wireless routers, radios, cellular telephones,
intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Portable unit overview
1
2
3
4
5
6
1 – Visual sound indicator
2 – POWER/LINK light
it 3 – LOW BATTERY light
Par ent Un
baby' s safety world
4 – (Volume down)
Press to decrease the speaker volume.
5 – (On/off)
Press and hold to turn on or off the
portable unit.
6 – Speaker
Listen to sounds transmitted from the
monitor unit.
7 –
(Volume up)
Press to increase the speaker volume.
8 – Belt clip
9 – Battery compartment cover
10 – Power jack
Monitor unit light
4
POWER light
POWER
• Lights off when the monitor
unit is off.
• Lights on in green when the
monitor unit is on.
6. Never place the monitor unit inside the baby's
crib or playpen.
7. Never cover the monitor unit or portable unit(s)
with anything such as a towel or a blanket.
Precautions for users of implanted cardiac
pacemakers
Cardiac pacemakers (applies only to digital
cordless devices):
Wireless Technology Research, LLC (WTR), an
independent research entity, led a multidisciplinary
evaluation of the interference between portable
wireless devices and implanted cardiac pacemakers.
Supported by the U.S. Food and Drug Administra-
tion, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches
from the pacemaker.
• Should NOT place wireless devices directly over
the pacemaker, such as in a breast pocket, when
it is turned ON.
WTR's evaluation did not identify any risk to
bystanders with pacemakers from other persons
using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards
regarding electromagnetic fields (EMF). If handled
properly and according to the instructions in this
user's manual, the product is safe to be used based
on scientific evidence available today.
Parts checklist
• Monitor unit (DM111 BU/DM111-2 BU)
• Portable unit (DM111 PU/DM111-2 PU)
(1 for DM111 and 2 for DM111-2)
• Power adapter for monitor unit
• Power adapter for portable unit
(1 for DM111 and 2 for DM111-2)
• User's manual
Connect
• Use only the portable unit power adapter
and the monitor unit power adapter
supplied with this product.
• The portable unit power adapter and
monitor unit power adapter are intended
for a vertical or floor mount position. The
prongs are not designed to hold the plug
in place if it is plugged into a ceiling,
under-the-table, or cabinet outlet.
• Make sure the portable unit, the monitor
unit and the power adapter cord are out of
reach of children.
• Both the monitor unit and the portable unit
are on once connected to the power supply.
Portable unit light
POWER/LINK light
POWER / LINK
• Lights off when the portable unit
is off.
• Lights on in green when the
portable unit is on and linked
to the monitor unit.
• Flashes in green when there
7
is no link between the monitor
unit and portable unit, or when
8
the portable unit is out of range
from the monitor unit.
9
Visual sound indicator
10
The visual sound indicator shows
the sound level detected from
the monitor unit. It also shows
the volume level during speaker
volume setting.
Sound level detected from the
monitor unit is indepedent from the
volume level set at the portable unit.
• Green lights indicate a
moderate sound level detected
from the monitor unit; or
• Level 1 to Level 3 of the
speaker volume setting.
• Red lights indicate a higher
sound level detected from the
monitor unit; or
• Level 4 to Level 5 of the
speaker volume setting.
LOW BATTERY light
LOW BATTERY
• Flashes in red when the
battery is low.
Using your audio monitor
Power on or off the monitor unit
To turn on the monitor unit:
• Press and hold until the POWER light
turns on.
To turn off the monitor unit:
• Press and hold until the POWER light
turns off.
Power on or off the portable unit
To turn on the portable unit:
until the POWER/LINK
• Press and hold
light turns on.
To turn off the portable unit:
• Press and hold unit the POWER/LINK
light turns off.
