- Page 1 Hardware Reference Guide hp business desktops d325 Slim Tower Model Document Part Number: 338159-001 July 2003 This guide provides basic information for upgrading this computer model.
- Page 2 The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.
-
Page 3: Table Of Contents
Guidelines for Installing Ultra ATA Devices ......B–1 Hardware Reference Guide www.hp.com... - Page 4 Shipping Preparation ........... F–3 Index www.hp.com Hardware Reference Guide...
-
Page 5: Product Features
Product Features Standard Configuration Features The HP d325 Slim Tower features may vary depending on the model. For a complete listing of the hardware and software installed in the computer, run the Diagnostics for Windows utility. Instructions for using this utility are provided in the Troubleshooting Guide on the Documentation Library CD. -
Page 6: Front Panel Components
DVD-ROM, DVD-R/RW, or CD-RW/DVD Combo Drive) Diskette Eject Button (optional) Hard Drive Activity Light Diskette Drive (optional) USB (Universal Serial Bus) Ports Diskette Drive Activity Light (optional) Headphone Jack Optical Drive Eject Button Microphone Connector Power Button www.hp.com Hardware Reference Guide... -
Page 7: Rear Panel Components
The monitor must be connected to the monitor connector on the installed AGP card for proper operation. If the monitor is not connected to the correct connector, it will not function properly. Hardware Reference Guide www.hp.com... -
Page 8: Easy Access Keyboard
Used to open the Start menu in Microsoft Windows. Used in combination with other keys to perform other functions. 9 Ctrl Key Used in combination with another key; its effect depends on the application software you are using. *Keys available in select geographic regions. www.hp.com Hardware Reference Guide... -
Page 9: Customizing The Easy Access Buttons
Windows Logo Key + r Launches the Run dialog box. Windows Logo Key + u Launches the Utility Manager. Windows Logo Key + Tab Activates the next Taskbar button. Hardware Reference Guide www.hp.com... -
Page 10: Special Mouse Functions
Each computer has a unique serial number that is located on the top cover or the back panel of the computer. Keep this number available for use when contacting customer service for assistance. Serial Number Location www.hp.com Hardware Reference Guide... -
Page 11: Hardware Upgrades
Appendix E, “Electrostatic Discharge” this guide for additional information on preventing electrostatic discharge. Ä CAUTION: Before removing the computer access panel ensure that the computer is turned off and that the power cord is disconnected from the electrical outlet. Hardware Reference Guide www.hp.com... -
Page 12: Unlocking The Smart Cover Lock
Forgotten password Ä CAUTION: The Smart Cover FailSafe Key is a specialized tool available from HP. Be prepared; order this key before you need one. To obtain a FailSafe Key: ■ Contact an authorized HP reseller or service provider. Order PN 166527-001 for the wrench-style key or PN 166527-002 for the screwdriver bit key. - Page 13 1. Turn off the computer and any external devices. Removing the Smart Cover Lock Screws 2. Remove the Smart Cover Lock. To reattach the Smart Cover Lock, secure the lock in place with the tamper-proof screws. Hardware Reference Guide www.hp.com...
-
Page 14: Removing The Computer Access Panel And Front Bezel
3. Disconnect the power cord from the power outlet and the computer, and disconnect any external devices. Ä CAUTION: Before removing the computer access panel, ensure that the computer is turned off and that the power cord is disconnected from the electrical outlet. www.hp.com Hardware Reference Guide... - Page 15 4. Remove the thumbscrew on the back of the computer stand 1. 5. Lift the computer off the stand 2, then lay the computer on its side. Removing the Computer from the Computer Stand Hardware Reference Guide www.hp.com...
- Page 16 6. Locate the cover latch. Pull up and hold the latch 1 to release the computer access panel. 7. Slide the computer access panel back 2 about 0.5 inch (1.25 cm), then lift the access panel up and off the chassis. Removing the Computer Access Panel www.hp.com Hardware Reference Guide...
- Page 17 To reassemble the computer, reverse the above procedure. ✎ To re-install the front bezel, insert the two bezel bottom tabs, then rotate the front bezel forward to snap the three tabs on the top of the bezel in place. Hardware Reference Guide www.hp.com...
-
Page 18: Installing Additional Memory
184-pin 2.5 volt DDR-SDRAM DIMMs with appropriate MHz-compliant CAS Latency: ❏ unbuffered PC 2100 266 MHz-compliant CAS Latency 2 or 2.5 (CL = 2 or CL = 2.5) ❏ unbuffered PC 2700 333 MHz-compliant CAS Latency 2.5 (CL = 2.5) www.hp.com Hardware Reference Guide... - Page 19 The PC1600 (200 MHz) and PC3200 (400 MHz) may work, but are not supported. ✎ The system may not start using unsupported DIMMs. Refer to the Computer Setup (F10) Utility Guide for information on how to determine the processor bus frequency of a specific computer. Hardware Reference Guide www.hp.com...
-
Page 20: Preparing The Computer
3. Disconnect the power cord from the power outlet and disconnect any external devices. 4. Remove the computer access panel and front bezel. Ä CAUTION: Check the position of all cables and wires before raising or lowering the Easy Access drive bay to prevent damage. 2-10 www.hp.com Hardware Reference Guide... - Page 21 Removing a DDR-SDRAM DIMM 1. Press out on both latches of the DIMM socket at the same time. This releases the module and partially pushes it out of the socket. 2. Lift the module from the socket. Hardware Reference Guide www.hp.com 2-11...
- Page 22 2. Push the module down into the socket, ensuring that the module is fully inserted and properly seated. Make sure the latches are in the closed position 3. 2-12 www.hp.com Hardware Reference Guide...
-
Page 23: Removing Or Installing An Expansion Card
3. Disconnect the power cord from the power outlet and disconnect any external devices. 4. Remove the access panel and lay the computer on its side with the opening to internal parts where the access panel was located facing up. Hardware Reference Guide www.hp.com 2-13... - Page 24 Releasing the Slot Cover Lock 6. Inside the computer, locate the correct vacant expansion slot on the system board and remove the corresponding slot cover. 2-14 www.hp.com Hardware Reference Guide...
- Page 25 2 to maneuver the card out of the computer. Be sure not to scrape the card against the other components. Removing an Expansion Card from a Standard Expansion Socket Hardware Reference Guide www.hp.com 2-15...
- Page 26 CAUTION: After removing an expansion card, you must replace it with a new card or cover the open slot at the rear of the computer (for example, with a metal slot cover or a piece of duct tape) for proper cooling of internal components during operation.) 2-16 www.hp.com Hardware Reference Guide...
- Page 27 When installing an expansion card, press firmly on the card so that the whole connector seats properly in the expansion card slot. 11. If you are replacing an expansion card, store the old card in the anti-static packaging that contained the new card. Hardware Reference Guide www.hp.com 2-17...
- Page 28 Hardware Upgrades 12. Slide the slot cover lock down toward the expansion card brackets and slot covers to secure them in place. Securing the Expansion Cards and Slot Covers 2-18 www.hp.com Hardware Reference Guide...
-
Page 29: Specifications
Specifications HP d325 Slim Tower Desktop Dimensions Height 14.4 inches 36.57 cm Width 3.95 inches 10.3 cm Depth (depth will increase if the computer is 15.1 inches 38.35 cm equipped with a port security bracket) Approximate Weight 21 lb 9.53 kg... - Page 30 Specifications HP d325 Slim Tower Power Supply Operating Voltage Range 90–132 VAC 180–264 VAC Rated Voltage Range 100–127 VAC 200–240 VAC Rated Line Frequency 50–60 Hz 50–60 Hz ✎ This system utilizes a passive power factor corrected power supply when used in the 230V mode.
-
Page 31: B Hard Drive Installation Guidelines
Using the Cable-Select Feature with Ultra ATA Devices Optional drives and optional drive cables are available from HP in kits. The configuration of the drive employs a cable-select feature that identifies the drive as device 0 (primary drive) or device 1 (secondary drive). - Page 32 ■ Install guide screws to ensure that the drive lines up correctly in the drive cage. HP has provided extra guide screws installed in the front of the computer chassis behind the front bezel. Some options use M3 metric hardware. HP-supplied metric screws are black.
-
Page 33: Battery Replacement
Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water. ■ Replace the battery only with the HP spare designated for this product. Ä CAUTION: Before replacing the battery, it is important to back up the computer CMOS settings. - Page 34 Lift the battery out of its holder. Removing a Coin Cell Battery (Type 1) b. Slide the replacement battery into position, positive side up. The battery holder automatically secures the battery in the proper position. www.hp.com Hardware Reference Guide...
- Page 35 To release the battery from its holder, squeeze the metal clamp that extends above one edge of the battery. b. When the battery pops up, lift it out. Removing a Coin Cell Battery (Type 2) Hardware Reference Guide www.hp.com...
- Page 36 7. Reset the date and time, your passwords, and any special system setups, using Computer Setup. Refer to the Computer Setup (F10) Utility Guide. 8. If you normally lock the Smart Cover Lock, use Computer Setup to relock the lock and enable the Smart Cover Sensor. www.hp.com Hardware Reference Guide...
-
Page 37: D Security Lock Provisions
Security Lock Provisions Installing a Security Lock The security locks displayed below and on the following page can be used to secure the computer. Installing a Cable Lock Hardware Reference Guide www.hp.com... - Page 38 Security Lock Provisions Installing a Padlock www.hp.com Hardware Reference Guide...
-
Page 39: E Electrostatic Discharge
Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis. Wrist straps are flexible straps with a minimum of 1 megohm +/- 10 percent resistance in the ground cords. To provide proper ground, wear the strap snug against the skin. Hardware Reference Guide www.hp.com... - Page 40 If you do not have any of the suggested equipment for proper grounding, contact an HP authorized dealer, reseller, or service provider. ✎ For more information on static electricity, contact an HP authorized dealer, reseller, or service provider. www.hp.com Hardware Reference Guide...
-
Page 41: F Routine Computer Care And Shipping Preparation
Using cleaning products may discolor or damage the finish. ❏ Occasionally clean the air vents on the front and back of the computer. Lint and other foreign matter can block the vents and limit the airflow. Hardware Reference Guide www.hp.com... -
Page 42: Optical Drive Precautions
Avoid using any type of solvent, such as alcohol or benzene, which may damage the finish. Safety If any object or liquid falls into the drive, immediately unplug the computer and have it checked by an authorized HP service provider. www.hp.com Hardware Reference Guide... -
Page 43: Shipping Preparation
7. Pack the system components and external devices in their original packing boxes or similar packaging with sufficient packing material to protect them. ✎ For environmental nonoperating ranges, see Appendix A, “Specifications” in this guide. Hardware Reference Guide www.hp.com... - Page 44 2–5 optical drive F–2 CTRL key 1–4 shipping preparation F–3 Ulta ATA installation B–1 DIMMs (dual inline memory modules) guidelines 2–8 hard drive installing 2–10 2–11 2–12 activity light 1–2 diskette drive installation guidelines B–1 Hardware Reference Guide www.hp.com Index-1...
- Page 45 2–1 connector 1–3 slim tower, removing 2–5 special functions 1–6 Smart Cover FailSafe key 2–2 numeric keys 1–4 lock 2–2 removing 2–3 specifications A–1 optical drive status lights 1–4 ATA B–2 eject button 1–2 Index-2 www.hp.com Hardware Reference Guide...
- Page 46 Index Universal Serial Bus (USB) 1–2 upgrades guidelines 2–1 USB 1–3 Windows Logo key 1–4 1–5 Hardware Reference Guide www.hp.com Index-3...
