Summary of Contents for Eurotech EDV158
- Page 1 Tumble Dryer EDV158 Owner’s Manual SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS ............. 3 DESCRIPTION OF THE MACHINE ............4 INSTALLATION INSTRUCTIONS ............... 5 INSTRUCTIONS FOR USING THE TUMBLE DRYER ....... 8 CARE LABEL INSTRUCTIONS ..............9 THE CONTROL PANEL ................10 RECOMMENDED PROGRAMS AND TEMPERATURE SETTINGS ..11 CARE AND MAINTENANCE INSTRUCTIONS ......... -
Page 3: Important Safety Instructions
The interior of the machine should be cleaned This appliance must be connected to a grounded periodically by an authorized Eurotech service metal, permanent wiring system, or an equipment- agent. grounding terminal or lead on the appliance. -
Page 4: Description Of The Machine
DESCRIPTION OF THE MACHINE ♦ The tumble dryer is constructed in sheet steel panels with a treated and painted finish that ensures its aesthetic quality remains unaltered over time. ♦ The motor and all moving parts are designed to guarantee minimum noise levels. ♦... -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Read these instructions carefully before you install the machine. The installation should be carried out by a qualified person who is familiar with all local codes and ordinances for electrical connections. Incorrect installation may cause damage and/or injury. If the integrity of the machine is in doubt, do not use it. Call your dealer for qualified assistance. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS The power supply cord must be grounded. If the machine is to be used in a wet area, the supply must be protected by a residual current device. Connection to a permanently wired supply point must be made only by a qualified electrician. - Page 7 CONNECTING A 4-WIRE POWER CORD WARNING! Before starting this procedure, be sure the power is turned off at the breaker/fuse box. You will need a 4-wire power supply cord with four No. 10 copper wires and a matching 4-wire receptacle of NEMA Type 14-30R, as illustrated below.
-
Page 8: Instructions For Using The Tumble Dryer
INSTRUCTIONS FOR USING THE TUMBLE DRYER 1. Make sure the lint filter is free of lint (see page 12). 2. Before placing the items in the dryer, sort the laundry by type of fabric and care label instructions (see page 9). 3. -
Page 9: Care Label Instructions
CARE LABEL INSTRUCTIONS Most clothes and other washable items have permanent care labels. Read these labels carefully! Care label instructions and warnings should be followed for the best cleaning results. The table below defines the typical symbols used on fabric care labels. (Note: Some manufacturers may use slightly different symbols.) CARE LABEL SYMBOLS... -
Page 10: The Control Panel
THE CONTROL PANEL The control panel on your Eurotech tumble dryer is easy to understand and simple to operate. Simply press the On/Off button, select the program temperature (delicate or normal), and turn the Program knob to the desired setting. -
Page 11: Recommended Programs And Temperature Settings
ADDING AN ITEM If you wish to interrupt a program to add or remove an item from the dryer, simply open the door. The dryer will stop and the heating element will shut off. To resume the program, shut the door and turn the Program knob to the 12:00 position. -
Page 12: Care And Maintenance Instructions
CARE AND MAINTENANCE INSTRUCTIONS The tumble dryer does not require special care. To best ensure a long life, however, certain precautions are recommended (see page 3). CLEANING THE LINT FILTER You should clean the lint from the lint filter before every load. To do this, follow the instructions below: 1. -
Page 13: Troubleshooting
TROUBLESHOOTING Before calling for technical assistance, check that the operations described below have been carried out correctly. This will save both time and money. The machine won’t start. Make sure the door is closed securely. Make sure you pressed the START button. Make sure the indicator light is on. - Page 14 NOTES...
-
Page 15: Warranty
For warranty service, contact the dealer from whom you purchased the unit or an authorized Eurotech service agent. Service will be provided during normal business hours. Should you have a service problem that cannot be resolved locally, contact AM Appliance Group at the numbers listed below. -
Page 16: Quick Start Reference Guide
QUICK START REFERENCE (Refer to pages 9 and 10 for detailed operating instructions.) Delicate/Normal Button On/Off Button This button lets you select between a normal This button turns the power to the and low drying temperature. Press it in to machine on and off.
